CravenSpeed Pro Series Installation Manual

Mini smartphone mount

MINI Smartphone Mount Pro Series | Ver 0.9

CRMC-1000-R130

MINI Smartphone Mount

Pro Series

Installation Guide

Thank you for purchasing the MINI Smartphone Mount Pro Series from CravenSpeed. This

kit is designed to allow the driver to position a smartphone for heads-up view, without needing to

handle the device. Pro Series mounts allow you to customize your view by adjusting the

extension arm to the angle that suits you. This kit is made from the highest grade materials and

is guaranteed to be free from defects.

Once installed, simply snap in your mobile device and away you go! You will now be able to

position the device for Horizontal or Vertical viewing quickly and easily!

PLEASE NOTE: This CravenSpeed Pro Series Mount is only compatible with 3rd Generation

MINIs

This mount is also available in a right-hand drive configuration. The installation instructions are

the same for both units. If the right-hand unit is mounted in a left-hand drive MINI, care must be

taken so that the module arm mounting screw does not contact the dashboard. This can be

alleviated by flipping the screw around so that the button-head is facing the dash allowing for

more clearance.

1. Hidden behind some round caps there are two screws holding the gauge cluster in place, one

on either side. Use a T15 torx driver to remove them.

Table of Contents

Do you have a question about the Pro Series and is the answer not in the manual?

Page 1: Installation Guide
Pro Series mounts allow you to customize your view by adjusting the extension arm to the angle that suits you. This kit is made from the highest grade materials and is guaranteed to be free from defects.
Page 2 2. Pull the gauge cluster towards you and depress the lock-tab to remove the electrical plug from the rear of the unit.
Page 4 3. Remove the 3 phillips screws on the back of the housing.
Page 5 4. Place the “U” bracket in place and tighten it down using the provided screws. (Note: These screws are slightly thicker than the OEM screws) Once the bracket is secure (no wiggle), do not over-tighten as this will just strip out the plastic housing.
Page 6 Monday - Friday between 8am and 4:30pm Pacific Time and we would be happy to give you a hand. We love pictures too! If you have some nice photos of our products that you would like to share with us you can email them to: support@cravenspeed.com CravenSpeed, 14010-A SW 72nd Avenue, Portland, OR, 97224, 503.505.6886 www.cravenspeed.com...
