Installation and Owner's Manual

HYBRIDFLUSH AEF-801 SERIES

AUTOMATIC/MANUAL FLUSH VALVE SYSTEM

FOR WATER CLOSETS (TOILETS) AND URINALS

Advanced Modern Technologies Corporation

19800 Nordhoff Place, Chatsworth, CA 91311

Tel: (818) 883-2682 Toll Free: (800) 874-7822 Fax: (818) 883-2620

www.amtcorporation.com

REV. 07/16

Table of Contents

Need help?

Do you have a question about the HYBRIDFLUSH AEF-801 SERIES and is the answer not in the manual?

Questions and answers

Summary of Contents for AMTC HYBRIDFLUSH AEF-801 SERIES

Page 1 Installation and Owner’s Manual ® HYBRIDFLUSH AEF-801 SERIES AUTOMATIC/MANUAL FLUSH VALVE SYSTEM FOR WATER CLOSETS (TOILETS) AND URINALS Advanced Modern Technologies Corporation 19800 Nordhoff Place, Chatsworth, CA 91311 Tel: (818) 883-2682 Toll Free: (800) 874-7822 Fax: (818) 883-2620 www.amtcorporation.com REV. 07/16...
Page 2 ® ® retrofit AMTC , Sloan and/or Zurn exposed type manual flushometers. The AEF-801 is interchangeable between urinals and water closets (toilet) and provides for a “true mechanical override” option through the use of the flush handle or push button. This patented “hybrid” design gives the user the ability to flush the fixture by infrared sensor activation or mechanically by using the flush handle or push button.
Page 3: Important Note
® ® ® fixture. Either for an AMTC /Sloan or Zurn valve body. 4. When installing unit on a poorly draining urinal or toilet bowl it is highly recommended that the angle stop on the flushometer be throttled back to the point where the water drains faster than the water being flushed to prevent overflow.
Page 4: Installation Instructions
Installation Instructions All Installation Tools Included STEP 1 STEP 2 Using the Flathead Screwdriver turn the Using the Installation Wrench loosen and remove Control Stop Screw of the Flushometer to the the Top Cover, Inside Cover, Relief Valve, and right (clockwise) to completely shut of the Diaphragm.
Page 5: Switch Adjustments
Push Button Conversion Instructions Installation Wrench Use to disassemble and convert 1. Use the Installation Wrench to remove the handle into push button. handle assembly from the flushometer 2. Disassemble the handle assembly using the middle part of the Installation Wrench. 3.
Page 6: Replacing Batteries
Sensor Angle Adjustment Latch Screw INSIDE VIEW Latch OUTSIDE VIEW Sensor Window 0 Degrees 8 Degrees Angle Adjustment Screw Directions: 1. Loosen the Latch using the provided Allen Wrench and remove the Sensor Window. 2. Using a small Phillips Head Screwdriver slowly turn the Angle Adjustment Screw clockwise to increase the sensor angle downward or counter-clockwise to decrease the angle.
Page 7 ® HYBRIDFLUSH Accessories (SOLD SEPARATELY) Push Button Conversion Kit (PBCK) The Push Button Conversion Kit (PBCK) includes a push button and spring that replaces the existing flush handle and spring to convert it into a mechanical push button. ® By using the push button with the HYBRIDFLUSH system the user is able to flush the urinal or toilet manually even when the batteries ®...
Page 8: Parts Diagram
Parts Diagram 15-2 15-1 Refer to Page 10 for Diaphragm/Repair Kit Reference Chart...
Page 9: Parts List
Parts List ® ® HYBRIDFLUSH SENSOR OPERATED FLUSH VALVE SYSTEM PARTS Ball Relief Valves for HYBRIDFLUSH PICTURE PART # DESCRIPTION PICTURE PART # DESCRIPTION Ball Relief Valve Assembly for SC801 Screw for Top Plastic Cover DI-BRV-U05 ® HYBRIDFLUSH - Urinal 0.5gpf Ball Relief Valve Assembly for PC801 Plastic Cover for Housing...
Page 10 Diaphragm/Repair Kit Reference Chart ® ® Diaphr agm Assemblies for HYBRIDFLUSH Silicone Diaphragm Assemblies for HYBRIDFLUSH PICTURE PART # DESCRIPTION PICTURE PART # DESCRIPTION Diaphragm Assembly for Silicone Diaphragm Assembly for DI-H-U05 DI-SH-U05 ® ® HYBRIDFLUSH - Urinal 0.5gpf HYBRIDFLUSH - Urinal 0.5gpf Diaphragm Assembly for Silicone Diaphragm Assembly for...
Page 11: Care And Maintenance
Manual flush is too long manual). Threading on valve body may be damaged. Check if valve body is AMTC/Sloan or Zurn. Use correct locking ring to match Locking ring does not fit valve body correctly valve body being used. Locking ring may be damaged. Replace locking ring.
Page 12: Warranty
Warranty AMTC WARRANTS ITS PRODUCTS TO BE FREE OF DEFECTS IN MATERIAL AND WORKMANSHIP FOR A PERIOD OF FIVE (5) YEARS FROM DATE OF PURCHASE, WHEN PROPERLY INSTALLED AND UNDER NORMAL USE AND SERVICE. THESE PROVISIONS DO NOT INCLUDE THE BATTERIES SHIPPED WITH THE PRODUCTS.
