ALCOVE - SLIDING
Alcove Shower System Installation Guide for Liner Style & Accent Liner Style Showers
Congratulations on the purchase of your new shower system.
This guide will give you the instructions on the installation of your new shower.
Natural Travertine Stone Appearance
All of our stone products are custom made and hand-crafted to look and feel like authentic
travertine. As you may know, travertine is a form of limestone that has been under pressure for
thousands of years. The product of long-ago hot and cold springs and waterfalls, travertine is a
beautifully banded and colored stone with a unique character. Among its most appealing
characteristics are the interesting craters and depressions, created by streams of water that
flowed through the stone.We have taken great care in reproducing the appearance of genuine
travertine stone, giving you a beautiful and authentic shower.
Installation time may vary depending on your experience, complexity of shower,
and "Pre Installation Preparation Work" which may include: plumbing relocation,
drain location and bathroom demolition.
Prior to demolition, scheduling a contractor or building your shower, double check that you
have all the parts from the factory. Some applications may require a licensed plumber or
contractor. Do not use any product spec sheets to begin installation before receiving product.
These spec sheets are for reference only. Use actual product measurements only.
The diagrams throughout this guide illustrate a 36" x 36" shower. Depending on the size of the
shower purchased, actual parts may vary in size from the diagrams shown.
Our goal is to help you achieve a quick and successful shower installation.
See the clock in each section for estimated installation time.
Missing or damaged hardware and tiles should be reported within 24 hours
of receiving this shipment - If you need assistance call 1.800.454.2284,
Monday thru Friday, 7:15am - 4:00pm, Friday (PST)
G_00912-S-80S-7.17 Rev C
Advertisement
Related Manuals for American Bath Factory Sistine Stone Sliding
Summary of Contents for American Bath Factory Sistine Stone Sliding
- Page 1 ALCOVE - SLIDING Alcove Shower System Installation Guide for Liner Style & Accent Liner Style Showers Congratulations on the purchase of your new shower system. This guide will give you the instructions on the installation of your new shower. Natural Travertine Stone Appearance All of our stone products are custom made and hand-crafted to look and feel like authentic travertine.
- Page 2 CHECK YOUR SHIPMENT AGAINST APPROPRIATE PACKING LIST Make sure you have received all the items necessary for the installation. This will also familiarize you with all the parts and hardware you will need to install your shower. Package contents are dependent upon which package you ordered.
-
Page 3: Optional Items
OPTIONAL ITEMS FAUCETS SHAMPOO BOX SHOWER BENCH TIME REQUIRED PRE-INSTALLATION TEAR DOWN 8-16 HRS This shower system is designed to be installed on a bare floor. It is necessary for any existing shower to be completely removed. Tear out and remove all old material to expose the 2 x 4 wall studs. Clean up the shower area, removing all dust and old material from the area. TIME REQUIRED DRY-FITTING THE PAN ½... - Page 4 TIME REQUIRED 2 x 4 STUDS ALIGNMENT & POSITIONING ½ to 1 HR Using the pan and wall panels, you will be able to check to make sure your 2 x 4 studs are in the needed position and supported adequately. You will see in (diagram 2) extra 2 x 4 studs are added to the door and glass side thresholds for extra strength.
- Page 5 TIME REQUIRED SETTING PAN ½ HR 1. Now that the drain is installed into the pan dry fit the pan and drain for alignment, check to make sure the 2” drain pipe is in the center of the pan drain hole. (diagram 2) Use the drain collar #5 by itself;...
- Page 6 TIME REQUIRED PAN & WALL THRESHOLD TRIM 1/2 - 1 HR A - Pan Threshold 1. Locate the left pan rail and the right pan rail (diagram 9) pan rails silicone 2. Dry fit onto the front of the metal pan 3.
- Page 7 TIME REQUIRED WALL PANEL/LINER INSTALLATION 3-4 HR A - Inspecting Wall Panels/Liners Inspecting panels at this point will give you confidence that the wall panels are straight and square from the factory. When installing wall panels, you may need to make adjust- ments to the panels to accommodate for unevenness of your existing walls.
- Page 8 TIME REQUIRED WALL PANEL/LINER INSTALLATION (continued) 3-4 HR C - Installing Panels 9. Remove all dust and dirt with a clean dry cloth. This will increase the bond to the 100% RTV silicone. 10. Start with the bottom panel apply a generous amount of 100% RTV silicone to the cement board and to the back side of the wall panel.
- Page 9 TIME REQUIRED SLIDING GLASS DOOR INSTALLATION 1/2 - 1 HR Our glass is tempered to make for a very strong door, the tempering gives maximum strength from impact on the surface, unfortunately this make the glass very vulnerable to breakage from impacts to the bottom and top edges of the glass panel. Do not rest the top or bottom of glass panels on hard floor or objects, always keep corner pads on glass while handling.
- Page 10 B - Handle Installation 1. Set the glass door in a position to enable the assembly of the handle (diagram 18) clear washer 2. A left door will have the Door Handle on the left, a right door will have the Door Handle clear clear washer on the right.
- Page 11 GROUT Your American Bath Factory shower has a non-porous tile surface, which makes it easy to clean. Grout used must contain an ACRYLIC ADDITIVE to ensure proper bonding to the tiles. We suggest you add grout to every grout line and seam in the shower.
