DUDLEY
Specifically designed for wall hung pans, can be sited on a flat wall, in a
A
F
D
C
Clamping bolts at rear of uprights
498mm
180mm
230mm
Foot rotational locking screw
at end of adjustable leg
ILLUSION A
corner or used within furniture.
INSTALLATION INSTRUCTIONS
1.
Set frame height .
To adjust the height of the frame slacken off the bolts holding the adjustable
legs in frame
rim is 400mm above the floor level. Re-tighten the bolts clamping the
frame into position. The feet can be rotated, into any position to suit
Vantage
installation, by using the screw at the foot of the leg
Mounting
section of the frame to the required height and re-tighten the bolts.
Brackets
2. Fit wall straps to frame.
The wall straps
on the depth of installation required. Minimum depth is 150mm, maximum
depth is 370mm. Once positioned attach firmly to the frame using the M8
bolts, nuts and washers provided.
A
3. Fixing to wall and floor.
Attach frame securely to wall and floor using the plugs, washers and hex
head screws provided. See diagrams overleaf for corner fitting. It is the
C
responsibility of the installer to ensure that these fixings in the wall and floor
are strong enough to adequately support the load which will be applied to
the pan in use. It is recommended that fixings are as close as possible to the
horizontal part of the brackets.
E
4. Fitting flushpipe.
Cut the vertical section of the pipe to the required length, ensuring the pipe is
cut straight. Push the flushpipe onto the spigot of the Vantage cistern and
secure in place using clamp
required length. When installing the frame at its maximum height use the
flushpipe extension piece
A
5. Fitting pan connector.
Fit a pan connector or soil pipe to clamp
fitted. When in the correct position, complete plumbing to the soil piping.
6. Fitting Partition.
Fit Partition/Wall/Furniture prior to fitting Pan.
7. Fitting pan.
Ensure M12 allthread protrudes sufficiently for correct and secure installation
of the pan. See fig. 1 for installation detail.
Notes -
- Pan outlet connector and soil pipe seal to be purchased
separately. Required diameter 110mm
DECORATIVE CAP
FLOOR LEVEL
FIXING LEVEL
B
WITH
A
. Adjust the lower section of the frame so that the WC pan
C
can be adjusted and used in any orientation dependant
D
. Cut the horizontal section of the pipe to the
F
supplied.
PAN
M12 FULL NUT,
& FLAT WASHER
DISHED WASHER
Fig 1
B
. Adjust the top
E
and position to suit the pan being
M12 ALLTHREAD
FRAME
PAN PROTECTION
BUSH SUPPORT
Thomas Dudley Ltd. 2012.
R325586 (11987 - ISSUE A)
