Tait T02-00026-3002 Installation Instructions

T02-00026-3002 Desktop Mount U-Cradle
Installation Instructions
The T02-00026-3002 Desktop Mount U-Cradle
Installation Kit is used for desktop installation of
mobile radios. The U-cradle can be attached to the T02-
00036-xxxx Universal Input Power Supply Unit or any
other even surface.
The kit is supplied with four thumb screws to attach a
mobile radio, and two screws to mount the microphone
clip.
Mounting the U-Cradle to the Power Supply
The recommended position for the U-cradle is on the
top surface of the power supply, 2.4 inch (60mm)
from the front edge.
Caution When handling solvents. Follow the
manufacturer's precautions and directions for use.
1 Use a solution of isopropanol and water (50/50) to
remove any oil or dirt from the top surface of the
power supply.
To ensure maximum bond strength, the
temperature of both the power supply and
the U-cradle should be above 68°F (20°C).
2 Remove the liners that protect the
adhesive surfaces on the bottom of the U-
cradle.
3 Position the U-cradle on the top surface
of the power supply and press firmly
along the length of the U-cradle. Main-
tain pressure for a minimum of 30 sec-
onds to ensure maximum adhesion. Full
bond strength is achieved within 72
hours.
© Tait Limited January 2018
www.taitradio.com
402-00112-00
u-cradle
microphone clip
2 screws
2.4 inch
(60mm)
U-cradle
adhesive surfaces
remove protective liner
press U-cradle down firmly
4 thumb
screws
