T02-00025-1001 GPS Receiver
Installation Instructions
The T02-00025-1001 GPS receiver is a high
performance, 66-channel GPS receiver that operates
at a frequency of 1575.42MHz (±10MHz).
The GPS receiver is designed for installation inside
a vehicle. It is supplied with a square of industrial
standard 3M double-sided tape, and a connector
cable.
The cable connects to the auxiliary connector of a
TM8000 or TM9000 mobile radio.
The GPS receiver can be installed on the windscreen behind the rearview mirror, on the
dashboard at the front of the vehicle, or on the parcel tray at the rear of the vehicle.
Alert Symbols and Message Conventions
Please follow exactly any instruction that appears in the text as an 'alert.' An alert provides
necessary safety information as well as instruction in the proper use of the product.
This document uses the following types of alert:
Warning This alert is used when there is a hazardous situation which, if not
avoided, could result in serious injury.
Notice This alert is used to highlight information that is required to ensure procedures
are performed correctly. Incorrectly performed procedures could result in equipment
damage or malfunction.
This icon is used to draw attention to information that may improve understanding of the
equipment or procedure.
