C6 HDMI Transmitter with HDBaseT Technology, No. 38019
Thank you for purchasing the LINDY C6 HDMI Transmitter with HDBaseT Technology! It allows HDMI, IR and Ethernet
Signals to be extended up to 100m via a single Cat5e/6/7 Cable. The C6 HDMI Transmitter is designed to be used
with professional Displays and Projectors which have integrated HDBaseT technology. It can also be used with a
HDBaseT Wallplate Receiver (LINDY No. 38114) or added to an existing installation.

Features

Extends a HDMI signal, IR & Ethernet via a single Cat5e/6/7 Cable
Extends uncompressed HDMI or DVI-D signals up to 100m via its HDBaseT connection
Supports resolutions up to HDMI UHD 4K 2160p @ 30Hz
Support for 3D signals, including 1080p 3D
Supports 10/100 Base-T Ethernet via the HDBaseT connection (2 x Port 10/100 Ethernet)

Package Contents

C6 HDMI Transmitter
5V DC/2A Power Adapter

Installation and Operation

The following steps are for an installation using the C6 HDMI Transmitter with display equipment with integrated
HDBaseT Technology and a HDMI source. If you are using DVI equipment, please substitute the HDMI cables for DVI
to HDMI cables where required.
1. Connect your HDMI source to the C6 HDMI Transmitter unit using a HDMI cable (maximum length 5m).
2. Connect one end of the Cat.5e/6/7 cable (max. length 100m) to the output port on the C6 HDMI Transmitter and
the other end to the HDBaseT port of HDBaseT equipped Display/Projector. Use solid core installation cable of at
least Cat.5e UTP.
3. For Ethernet functionality, connect your devices to the 10/100Base-T ports on the Transmitter.
4. Plug the DC power supplies into the Transmitter and display equipment with integrated HDBaseT Technology
and switch on.
5. Power on your HDMI Source to complete the installation.
For further information, including troubleshooting tips please refer to the manual for the HDBaseT Splitter Series of
products (LINDY No. 38116-8) available from www.LINDY.com.
Only use a direct Cat.5e/6/7 cable connection between the HDBaseT ports. Do not
connect these ports to Network or Ethernet equipment or any active components
WEEE (Waste of Electrical and Electronic Equipment), Recycling of Products
The European WEEE regulation for the collection and recycling of all Waste Electrical and Electronic Equipment does not allow to
simply throw away electrical and electronic equipment into the bin. Instead, these products must enter the recycling process. Each
individual EU member state has implemented the WEEE regulations into national law. Please follow your national law when you want
to dispose of any electrical or electronic products. More details can be obtained from your national WEEE recycling agency.
Tested to Comply with FCC Standards
For Home and Office Use
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH – 1. EDITION
IR Emitter Cable 1.4m
This User Manual
!!! IMPORTANT !!!
Quick Installation Guide
(September 2014)
