- Page 1 AL-LZ100-NM LON ZigBee Gateway <Main Function> LON Communication ZigBee Communication <AL-LZ100-NM>...
- Page 2 Features AL-LZ100-NM - Reliable and rapid control by LON communication. - Wireless control by ZigBee communication. * LON communication The way of - 78Kbps / 2 wire / Non-polarity Communication - Two-way communication / Event Driven - Free Topology * ZigBee communication - 2.4GHz / 2Mbps...
- Page 3 Description ® LightON AL-LZ100-NM is the device which convert between the devices using ZigBee communication and the devices using LON communication. Through it, you can build the radio wire integration solution. Antenna Status AL-LZ100-NM Function Radio wave Transmit and Receive Antenna (2.4GHz/Helical Antenna)
-
Page 4: Description Of The Connection
Description of the Connection Ground DC 24V LON N LON P Input power Connect the DC Power line to the Ground and DC24V Connection Connection Point. Connect the LON communication lines to the LON N and LON P Point. LON Connection - In case the number of the products connecting it is few, it can be input power by LON communication line without external power... -
Page 5: Technical Support
Product of Co,. Ltd. LON ZigBee Gateway ® Model Name: LightON AL-LZ100-NM Input Power: DC 24V / 1A Head Office #308 ACE Techno Tower 8, 11, Digital-ro 33-gil, Guro-gu, Seoul, 08380, Republic of KOREA Phone : +82-2-2025-7591... -
Page 6: Fcc Information To User
FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 7 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this equipment near water. 6) Do not using near any heat sources such as radiators, heat resisters, stove, or other equipment that produce heat.
-
Page 8: Contact Information
CONTACT INFORMATION Manufacturer Address : 308 (ACE Techno Tower 8), 11, Digital-ro 33-gil, Guro-gu, Seoul, Korea To locate in- country ABIsystems Co.,Ltd., distributors of the ZigBee Gateway please refer to the ABIsystems Co.,Ltd. Website http://www.abisys.co.kr These distributor(s) represent local contacts for this product. CORPORATE HEADQUARTERS: ABIsystems Co.,Ltd. -
Page 9: Declaration Of Conformity
ABIsystems Co.,Ltd. 308 (ACE Techno Tower 8), 11, Digital-ro 33-gil, Guro-gu, Seoul, Korea declare under our sole responsibility that the product(s) ZigBee Gateway – AL-LZ100-NM to which this declaration relate(s) is in conformance with the following standards: EN 301 489-1 V1.9.2:2011 EN 301 489-17 V2.2.1:2012...
