Summary of Contents for Barnett Engineering PRO TALK CV2
- Page 1 INSTRUCTION MANUAL...
- Page 2 INSTRUCTION MANUAL 1272M001 Manual Revision: 9.4 - November 2007...
-
Page 3: Table Of Contents
Contents Getting Started ........1-1 Operations Overview Cv2 capabilities (Advanced Mode) . -
Page 4: Regulatory Notices
The ProTalk Cv2, model B1272D, has been certified by the Federal Communications Commission (“FCC”) using the included articulating dual-band dipole antenna. Unauthorized modifications or changes not expressly approved by Barnett Engineering Ltd. could void compliance with regulatory rules, and thereby your authority to use this equipment. -
Page 5: Getting Started
Basic mode eliminates the need to configure the Hardware Inputs, Groups and Points by combining them into a single function called Alarms. Similarly, the outputs are reduced to a B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 6 If the total number of unacknowledged calls in all directories exceeds 75, a call will be made to Barnett Engineering with the MIN and ESN of the phone. This information will be used to attempt to locate the owner of the equipment and notify them of the problem condition. At this point the timer used to control the interval between the last call in the directory and when the cycle is restarted at the first number will be set to 4 hours regardless of the program settings.
- Page 7 Advanced when programming in the Basic mode. Only phone numbers can be programmed in Basic mode. Acknowledge code Interrogate code Cycle Timer Rings before answer Call progress enable Access code Temporary Ack time Enable Modem code — — BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 8: Operations Overview
Analog inputs convert the voltage level to a digital value and perform a comparison against the programmed low and high setpoints. An alarm is present when the measured value is above or below the setpoint. Alarm messages are spoken using the stored phrase with either B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 9: How Are Alarms Processed
B1272M001 INPUTS OUTPUTS HARDWARE HARDWARE INPUTS OUTPUTS POINTS UP TO 30 INPUTS OR OUTPUTS GROUP GROUP DIRECTORY CONTROL DIALOUT COMMANDS COMMANDS CELL PHONE Figure 1 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 10: What Actions Should Occur When An Alarm Is Detected
Cv2 sends the number to be displayed on the pager. When calling a paging terminal, it is sometimes useful to allow the called party time to call the Cv2 back and acknowledge the B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 11: How Do You Want To Respond To An Alarm Call
Site ID phrase, the phrases for any groups that have alarms, followed by the prompt “Enter Command Code”. An Access Code is not required. At the next level of security, the Cv2 will announce the Site ID phrase and then wait ten seconds for the password code before B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 12: Sending Remote Control Commands
The three user controls can be set to operate as either on/off controls or as timed controls. The other five controls are always set to indicate New Alarm, Any Alarm, Acknowledge Received, Modem Carrier Detect and Ring Out. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 13: What Constitutes An Alarm
Each call consists of dialing the phone number followed by a verbal message containing the Site ID phrase then any active alarm phrases. B1272M001 INPUTS OUTPUTS ALARMS OUTPUTS HARDWARE USER CONTROLLED CONTROLLED ACKNOWLEDGE INTERROGATE DIRECTORY ACCESS CONTROL COMMANDS CELL PHONE BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 14: How Do You Want To Respond To An Alarm Call
When the unit is called and after the Access Code, if required, has been entered, the prompt to “Enter Command Code” will be issued. In either case, the call will be terminated if a valid code is not received during the ten second window. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 15: Indicators
RSSI (Received Signal Strength Indicator) in the phone to see if there is coverage in the area. The message “error” will be returned if there is no coverage. This can possibly be corrected by improving the antenna system. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 16 If you receive a recording from the telephone company indicating the user is not available, there may be a problem with the installation or you may be calling the wrong number. Use the programming phone to confirm the telephone number in the unit. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 17: Installation
TNC coaxial jack on the Cv2. Connect the input and output signal lines between the Cv2 and the equipment that you want to monitor and control. Details of the input and output ports are discussed later in this chapter. BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 18: Input Port Connections
“Normally Low”. B1272M001 C or above +50 Figure 5 Ground Closure Input Wiring BARNETT ENGINEERING LTD. Connect a DC power source to the terminals on TB2. The Cv2 requires up to 1.2 Amps to operate;... - Page 19 The connection shown in Figure 8 will provide additional filtering of the signal. Figure 8 Analog (filtered) Input Wiring B1272M001 Figure 6 +12 Volt Input Wiring Figure 7 Figure 9 Analog (unfiltered) Input Wiring BARNETT ENGINEERING LTD. +5 VDC Input Wiring ProTalk Cv2...
-
Page 20: Output Port Connections
The power supply has a power fail output signal that can be connected to any of the input ports on the Cv2 and programmed as an alarm point. B1272M001 Figure 10 BARNETT ENGINEERING LTD. Output Wiring Figure 11 Serial Cable ProTalk Cv2... - Page 21 Installation Figure 12 Stand-alone Cv2 Figure 13 Packaged Cv2 B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 22: Configuration Using The Pc
Selection items on the menus and taskbar are different for Advanced and Basic editing. The menu and button operations for the two modes are summarized in the following section. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 23: Program Functions - Advanced Mode
Inputs - Setup the type of input for each port and select basic hardware settings. Outputs - Setup the type of output for each port and select basic hardware settings. General Settings that concern the operation of the entire Cv2 are entered in the General section. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 24: Program Functions - Basic Mode
Settings that concern the operation of the entire Cv2 are entered in the General section. Programming Programming is the same as for the Advanced mode. 4.7 Configuring the Cv2 - Advanced mode When configuring the Cv2, the sequence described in the following section is the simplest B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 25: Hardware Section
Refresh activities can be changes from low to high, changes from high to low, or both. Watchdog input types use two timers for their operation: the Debounce timer and the B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 26 Timed outputs are activated by receipt of a single DTMF ‘On’ code. This code is set in the Points section. When the code is received, the output will activate and will remain in that state until the timer expires or the DTMF ‘Off’ code is received. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 27 Output used to indicate that there is an unacknowledged, or New Alarm, <NEW> in one or more groups. Output used to indicate that an Acknowledge Code has been received for <ACK> one or more groups. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 28 An Interval Point uses only the common settings. It cannot generate alarms, but can be interrogated to obtain readings. Totalizer Point Totalizers cannot generate alarms, but can be interrogated to obtain readings. In addition to the common ones, the totalizer also has the these settings: B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 29 B1272M001 Unit Suffix NONE NONE CUBIC METERS PER DAY CUBIC YARDS PER HOUR CUBIC FEET PER MINUTE PER SECOND POUNDS METERS GALLON BARRELS PERCENT PARTS PER MILLION BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 30 Both setpoints can be used within a single point. If the low setpoint is not required, set it to the decimal minimum; if the high setpoint is not needed, set it to the decimal maximum. Default Decimal Values: B1272M001 C to +60 BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 31 After the On code has been received and the output port set, the Cv2 announces the current status of the output. If the timer is set for a short B1272M001 +100.0 +25.0 +75.0 BARNETT ENGINEERING LTD. 4-10 ProTalk Cv2...
-
Page 32: Group Section
Acknowledge Code permanently silence the alarm condition, append the digit ‘#’ when you send the code and the Temporary Acknowledge Time in the General section will be used as an override. Default Acknowledge Code: an empty text string. B1272M001 BARNETT ENGINEERING LTD. 4-11 ProTalk Cv2... - Page 33 1 setting. After receipt of the Shift Change Code, the Cv2 responds with a spoken message indicating the new shift setting. The Shift Change Code is set in the General section. B1272M001 BARNETT ENGINEERING LTD. 4-12 ProTalk Cv2...
-
Page 34: Directories
Instructions for dialing, speaking, inserting delays and signaling are placed in the directory in the order in which they are to be performed. Each of the six directories can contain unique operational sequences. The directory summary displays the sequence of events B1272M001 BARNETT ENGINEERING LTD. 4-13 ProTalk Cv2... - Page 35 DTMF string to create a two second delay. DTMF must be preceded by a Dial command; it cannot be the first entry in the list. It can be used more than once in a list. Default DTMF value: 0000 B1272M001 BARNETT ENGINEERING LTD. 4-14 ProTalk Cv2...
-
Page 36: General
“Enter Command Code”. An Access Code is not required. Level 2 When the incoming call is answered by the Cv2, only the Site ID is announced; for further access to the Cv2 the caller must enter the Access Code. B1272M001 BARNETT ENGINEERING LTD. 4-15 ProTalk Cv2... - Page 37 Answer commands directly following a Dial command in the directories. This will cause the Cv2 to look for a voice response twice in a row and may prevent alarm announcements. Default Call Progress: disabled B1272M001 BARNETT ENGINEERING LTD. 4-16 ProTalk Cv2...
-
Page 38: Configuration Programming
Data is transferred in four-kilobyte packets at 9600 baud. The configuration database will take two packets to transfer; the number of packets in a voice data transfer will vary depending on how many points are used and how long the messages are. B1272M001 BARNETT ENGINEERING LTD. 4-17 ProTalk Cv2... -
Page 39: Configuring The Cv2 - Basic Mode
The common timescale can be set for either seconds or minutes. Maximum values are 65535 minutes and 1638 seconds. Default: 1 second B1272M001 BARNETT ENGINEERING LTD. 4-18 ProTalk Cv2... -
Page 40: Controls
If the requirements of the system you are setting up cannot be met with the basic phone number and voice commands in the directory, you can switch to the advanced editor while B1272M001 BARNETT ENGINEERING LTD. 4-19 ProTalk Cv2... - Page 41 When the end of a directory has been reached without receipt of an Acknowledge code, the Cv2 waits for the time set in the Cycle timer before repeating the alarm transmission sequence. This repetition will continue until the unit is acknowledged. B1272M001 BARNETT ENGINEERING LTD. 4-20 ProTalk Cv2...
-
Page 42: Remote Data Access
The suggested serial cable is shown in Figure 14. Do not use the programming cable that is supplied with the Cv2 or any cable that asserts the DTR line on the CV2 for external data transfer. Figure 14 - Data Cable for External Equipment B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 43: Voice Storage And Configuration With The Telset
The following example is for part of an advanced mode programming session. The sequences for both Basic and Advanced modes are shown in detail at the end of this section. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 44 Unless you exit, the Cv2 will automatically advance through all the enabled points, then back to the main menu. 5rr - Erase Voices Cv2: “Enter Empty Code” Press #31rr to confirm that you want to erase all voices. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 45: Telset Programming Summary
#0 <telephone number> #6 rr in Advanced mode. The Cv2 will accept either entry method regardless of which programming mode is being used. B1272M001 [VOICE] [SIGNAL] ‘!’ 2 second pause in Dial or DTMF ‘#’ digit Accept BARNETT ENGINEERING LTD. ProTalk Cv2... -
Page 46: Programming Flowchart
Exit to Main Menu Exit to Main Menu B1272M001 Record new voice Exit to Voice Menu Accept current recording and advance to next voice Confirm erase command Exit to Voice Menu Exit to Voice Menu BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 47 Exit to Directory Menu Accept interrogate code and exit to Directory Menu Change number of rings to 2 (range: 1-9) Exit to Main Menu Accept answer rings and advance to Call Progress Control Turn call progress detector off BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 48 Accept directory assignment, advance to next alarm or Alarm Format Change format to normally low inputs Change format to normally high inputs Change format to normally low latched inputs Change format to normally high latched inputs BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 49 Accept on code and advance to Off Code Change off code to 11 (max 8 digits) Erase off code Accept off code and return to Control Output Menu (type = On/Off) or advance to Timer Scale (type = timed) BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 50 0=very poor, 15=very good Exit to Main Menu Advance to Query Service Exit to Main Menu Advance to Query SID Exit to Main Menu Advance to Query NID Exit to Main Menu Advance to Query Transceiver State BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 51 Exit to Main Menu Exit to Main Menu Exit to Main Menu Advance to Edit MIN Change MIN to 800-268-2646 (must be 10 digits) Exit to Main Menu Accept MIN and advance to Query State BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 52: Voice Editor
If these files are relocated after they have been selected in the editor, an error will occur when the message file is being generated. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 53 .vox extension. B1272M001 the location contains no phrase data the phrase is contained in a loaded message file the phrase is in an individual file has been loaded at this location BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 54 A File Save dialog box is used to select the location and name of the stored configuration file. A configuration file does not contain any phrase data, only pointers to the source location for the phrases. The file is saved with a .vcf extension. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 55 ADPCM file. Press Convert to generate the output file. The generated ADPCM tile has the extension .vox and can be used by the Voice Editor to create message files for the Cv2. B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 56: Specifications
• Up to 4 shifts can be used. The current setting of the shift instructs a group to use one of the six directories. • Two-stage timer which uses the short interval several times before switching to a long interval. Short and long BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 57 • Up to 20 numbers in each of the 6 directories; each directory can hold up to 200 digits. • Multiple methods of security are available to restrict access and to control the unit. • NEMA 4 enclosure • Battery-backed power supply • Programming telephone set BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 58: Transceiver Codes
83: Voice Channel Initialization 84: Waiting For Order 85: Waiting For Answer 86: Conversation 87: Release 88: Update Overhead Information 89: Mobile Station Origination Attempt 8A: Page Response 8B: Order/Message Response 8C: Registration Access 8D: Message Transmission B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2... - Page 59 D = Current Protocol Revision in Use 0: Unrecognized / non-CDMA 1: IS-95/J-STD-008 2: IS-95-A 3: IS-95-A + TSB74 4: TIA/EIA-95-B Phase 1 5: TIA/EIA-95-B Phase 2 6: IS-2000 (Release 0) 7: IS-2000-A (Release A) B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
- Page 60 14: Call End due to Maximum Access Probe D = Online Mode 0: Mode Information Not Initialized 1: Phone Is in ONLINE Mode 2: Phone Is in OFFLINE Mode 4: Phone Is Powering Off 5: Phone Is Resetting/Power Cycling B1272M001 BARNETT ENGINEERING LTD. ProTalk Cv2...
-
Page 61: Warranty
(2) Exclusive Warranty: The warranty set forth herein is the only warranty, oral or written, made by Barnett Engineering Ltd. and is in lieu of and replaces all other warranties, expressed or implied, including the warranty of merchantability and the warranty of fitness for particular purpose.
