Gardenline 22008-17 User Manual

Pergola
Hide thumbs
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

Download this manual
Pergola
Pérgola
AFTER SALES SUPPORT
1800 599 8898
USA
MODEL: 22008-17 PRODUCT CODE: 44964
User Manual
Manual
del usuario
04/2017
english.... Page 3
español.... Página 20
support@tdcusainc.com
USA
1

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 22008-17 and is the answer not in the manual?

Questions and answers

Related Manuals for Gardenline 22008-17

Summary of Contents for Gardenline 22008-17

  • Page 1 User Manual Manual del usuario Pergola Pérgola english..Page 3 español..Página 20 AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 2 Contents Getting Started ........Parts List ..........Assembly Instructions ......Warranty ..........

  • Page 3: Getting Started

    Seek assis- tance to assemble bulky or heavy items. After final alignment, make sure all bolts and nuts are securely tightened with screw covers pressed in place. AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 4 Cover Plate Slide Bar Stakes Wrench/Hex Key Canopy Rope M6 * 10mm Screws M6 * 15mm Screws M6 * 35mm Screws M6 * 65mm Screws M6 Nut AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...

  • Page 5: Parts List

    1 M6 * 10mm Screws Canopy Weight Bar 2 M6 * 15mm Screws H Connector 3 M6 * 35mm Screws Support 4 M6 * 65mm Screws Foot 5 M6 Nut AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...

  • Page 6: Assembly Instructions

    Insert two Screws M6x35mm (3) through Crossbeams (B) and into Canopy Guide Bar (F); tightened down to hold parts together. Repeat for the second set of Crossbeams (B). AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 7 (1) through Crossbeam (D) and into Crossbeam (C); tightened down to hold parts together. Insert two Screws M6x15mm (2) through Plate (L) and into bottoms of Crossbeam (C) and Crossbeam (D); tightened down to hold parts together. AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 8 Insert four Screws M6x35mm (3) through Connector (H), through Canopy Supports (E), and through Connector (H); tighten down using Nut (5). Repeat for the other Canopy Supports (E). AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 9 (J) onto bottoms of Poles (A & A ) and screw together with Screw M6x15mm (2). Slide the Cover (K) down over Foot (J). Repeat for the additional Poles (A & A AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 10 Insert M6x15mm (2) through Support (I) and beneath assembled Crossbeams (B). Insert second M6x15mm (2) through opposite end of Support (I) and both Poles (A & A AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 11 Insert M6x15mm (2) through Support (I) and beneath assembled Crossbeams (C & D). Insert second M6x15mm (2) through opposite end of Support (I) and into Poles (A & A AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 12 Crossbeams (C & D). Insert two Screws M6x65mm (4) through both ends of assembled Canopy Supports (E) and into Crossbeams (C & D). AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 13 ). The push pins on Slider Bars (M) should be at the bottom of this part when it is vertical. Insert top ends of Slide Bar (M) into upper loops of Poles (A & A AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 14 ). Insert bottom end of Slide Bar (M) into lower loops of Poles (A & A ). Push in on pushpins so this part connects into holes on the sides of these loops. AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 15 Lift Cover (K) up and run four Stakes (N) through designated holes of Foot (J) and into the ground. Do this with each pole for extra stability. AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...

  • Page 16: Warranty

    Return your completed 1800 599 8898 warranty card with the faulty product to: support@tdcusainc.com MODEL: TDC USA, Inc. PERGOLA MODEL: 22008-17 04/2017 14 Madison Road Phone lines available Fairfield, NJ 07004 Monday to Friday United States of America 9am - 5pm EST.
  • Page 17 ALDI INC. FuLL WARRANTy CONDITIONS Dear Customer: The ALDI warranty is a full warranty offering you the following benefits: Warranty period: 2 years* from date of purchase. Costs: Free repair / exchange or refund. No transport costs. ADVICE Please contact our service hotline by phone, email or fax before sending the device.
  • Page 18 1. Some sections require working overhead and lifting components. Beams can be heavy and awkward to lift into place by yourself. 2. Ask others to lend a hand. We recommend having four people to help in the assembly of your pergola. Having others to help in the building process will result in and faster installation.
  • Page 19 Contenido Para comenzar ........Lista de piezas ........Instrucciones de ensamblaje ....Garantía ..........

  • Page 20: Para Comenzar

    Pida ayuda para ensamblar las partes pesadas y voluminosas. Tras la alineación final, asegúrese de que todos los pernos y tuercas estén firmemente apretados y estén cubiertos con los embellecedores. SERVICIO POSVENTA AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 21 Barra deslizante Estacas Llave inglesa/Llave hexagonal Toldo Cuerda Tornillos M6 * 10mm Tornillos M6 * 15mm Tornillos M6 * 35mm Tornillos M6 * 65mm Tuercas M6 SERVICIO POSVENTA AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...

  • Page 22: Lista De Piezas

    Barra de peso del toldo 2 Tornillos M6 * 15mm H Conector 3 Tornillos M6 * 35mm Soporte 4 Tornillos M6 * 65mm Pata 5 Tuercas M6 SERVICIO POSVENTA AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 23 (B). Insertar dos tornillos M6x35 mm (3) a través de los travesaños (B) y en la barra guía del toldo (F); apretar para mantener las piezas unidas. Repetir para el segundo conjunto de travesaños (B). SERVICIO POSVENTA AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 24 Insertar dos tornillos M6x15 mm (2) a través de la placa (L) y en la parte inferior del travesaño (C) y del travesaño (D); apretar para mantener las piezas unidas. SERVICIO POSVENTA AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 25 Insertar cuatro tornillos M6x35 mm (3) a través del conector (H), de los soportes del toldo (E), y del conector (H); apretar con la tuerca (5). Repetir el procedimiento para los otros soportes del toldo (E). SERVICIO POSVENTA AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 26 M6x15 mm (2). Deslizar la cubierta (K) hacia abajo para cubrir la pata (J). Repetir para los postes adicionales (A & A SERVICIO POSVENTA AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 27 Insertar un tornillo M6x15 mm (2) a través del soporte (J) y por debajo de los travesaños ensamblados (B). Insertar el segundo tornillo M6x15 mm (2) a través del extremo opuesto del soporte (J) y en ambos postes SERVICIO POSVENTA AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...

  • Page 28: Instrucciones De Ensamblaje

    Insertar M6x15 mm (2) a través del soporte (I) y por debajo de los travesaños ensamblados (C + D). Insertar el segundo M6x15 mm (2) a través del extremo opuesto del soporte (I) y en los postes (A SERVICIO POSVENTA AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 29 (C + D). Insertar dos tornillos M6x65 mm (4) a través de ambos extremos de los soportes ensamblados del toldo (E) y en los travesaños (C + D). SERVICIO POSVENTA AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 30 ésta se encuentra en posición vertical. Insertar los extremos superiores de las barras deslizantes (M) en las argollas superiores de los postes (A SERVICIO POSVENTA AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 31 Insertar el extremo inferior de la barra deslizante (M) en las argollas inferiores de los postes (A ). Presionar los pines para que esta pieza se conecte en los orificios en los lados de estas argollas. SERVICIO POSVENTA AFTER SALES SUPPORT 1800 599 8898 support@tdcusainc.com MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...
  • Page 32 Levantar la cubierta (K) y pasar cuatro estacas (N) a través de los agujeros designados de la pata (J) y clavar en el suelo. Haga esto con cada poste para obtener una mayor estabilidad. SERVICIO POSVENTA AFTER SALES SUPPORT support@tdcusainc.com 1800 599 8898 MODEL: 22008-17 PRODUCT CODE: 44964 04/2017...

  • Page 33: Garantía

    TARJETA DE GARANTÍA PÉRGOLA Sus datos: Nombre Dirección Correo electrónico Fecha de la compra* * Le recomendamos que guarde el recibo con esta tarjeta de garantía. Lugar de la compra Descripción de la avería: SERVICIO POSVENTA 49964 Devuelva su tarjeta de garantía 1800 599 8898 completada junto con el producto defectuoso a:...
  • Page 34 CONDICIONES DE LA GARANTíA COMPLETA DE ALDI INC. Estimado cliente: La garantía ALDI es una garantía completa que le ofrece los siguientes beneficios: Período de garantía: 2 años* a partir de la fecha de la compra. Costos: Reparación/sustitución gratis o reembolso. No hay costos de transporte.
  • Page 35 1. Algunas secciones requieren trabajar por encima de la cabeza y levantar los componentes. Las vigas pueden resultar pesadas y difíciles de colocar en su lugar por usted mismo. 2. Pida que alguien le ayude. Se recomienda tener a cuatro personas para ayudar en el montaje de su pérgola.
  • Page 36 DISTRIBUTED BY• DISTRIBUIDO POR: ALDI INC., BATAVIA, IL 60510 www.aldi.us AFTER SALES SUPPORT • SERVICIO POSVENTA 49964 1800 599 8898 support@tdcusainc.com YEAR WARRANTY MODEL / NO DEL MODELO: AÑOS DE GARANTÍA PERGOLA/PÉRGOLA 04/2017...
