Summary of Contents for Selle SMP Tourism
- Page 2 Note 1: eventual replacements of parts subject to wear are carried out at the sole www.sellesmp.com discretion of Selle SMP, and in any case will not be made later than three years from the date of purchase. The costs of this type of intervention are the responsibility of the user.
-
Page 3: Instructions For Assembly
INSTRUCTIONS FOR ASSEMBLY 1 • GENERAL PRINCIPLES Our saddles are designed to distribute body weight between the buttocks and lower part of the pelvic bone. The weight balance and comfort therefore depend on how the ischial tuberosities rest on the saddle while pedalling. This position depends on various factors: the height of the saddle in relation to the pedals •... - Page 4 5 - 10 - 15 mm. 5 • RECOMMENDATIONS REGARDING THE PILLAR The pillar has a significant impact on saddle frame resistance: For this reason Selle SMP recommends a pillar with the following characteristics: 1. it should allow correct saddle positioning 4. the contact area between the pillar and the saddle frame should...
- Page 5 6. the coupling surfaces with the saddle frame should be symmetrical and parallel The models of the Tourism catalogue are designed to be installed, preferably on seat rails with integrated seat post (such as that shown in the figure or similar), as this type of seat rail allows for the saddle to be fixed with maximum safety and precision of positioning.
- Page 6 In this case, it is recommended that the clamp is of the 5-part type, and with the safety features highlighted by the following figures. For questions or clarifications, please contact Selle SMP: E-mail: info@sellesmp.com Telephone: +39 049 643966...
-
Page 7: Maintenance And Checks
Periodically check that there is no movement/play between the • “fork” (metal frame) and the “body” (plastic frame). If there is movement do not use the saddle and consult your local Selle SMP dealer; • If the saddle makes noise, try to eliminate it by carefully cleaning and lubricating the couplings with the pillar;... - Page 8 • Dangers linked to the Selle SMP product: use this Selle SMP product if you are in good physical and mental • injury to the perineal structures; •...
- Page 9 Devised only in Italy, Made only in Italy, Sold all over the world. Selle SMP sas - Via Einstein, 5 - 35020 Casalserugo (PD) - Italy Tel. +39 049 643966 - Fax +39 049 8740106 - info@sellesmp.com ISO 9001:2008 certified...
