HYDROMETER IZAR CENTER 60 Installation

IZAR CENTER 60/120/250 | IZAR CENTER 60/120/250 Memory
29 30 31 32 33 34
M-Bus
USB/LAN
RS232/Rep
59 mm /
42 mm
Modem
Rx/Tx
1 2 3 4 5 6
Important Note:

Mounting and Dismounting

IZAR CENTER is prepared for mounting on a standard rail mount.
Important Note:
Mounting:
Dismounting:
HYDROMETER GmbH
Industriestraße 13 · 91522 Ansbach · Telefon +49 (981) 18 06 - 0 · Telefax +49 (981) 18 06 – 615
Am Weimarer Berg 3 · 99510 Apolda/Thüringen · Telefon +49 (3644) 84 33 - 0 · Telefax +49 (3644) 84 33 - 411
info@hydrometer.de · www.hydrometer.de · Subject to technical adjustments · 12.05.2011

Installation

68
67 66
The IZAR CENTER device may only be installed and operated by trained
personnel.
Disconnect power supply (16) prior to mounting or dismounting the IZAR
CENTER device.
Clamp the IZAR CENTER device on the rail mount. The black hook at the
bottom of the device should snap in firmly.
Use a screwdriver to pull the black hook down. The IZAR CENTER device will
snap off the rail mount and you can take it off.
IZAR CENTER 250 MEMORY
65 16
157,5 mm
1
86 mm
12345678
00204AA9BD3E
