Summary of Contents for Vdwall MP905
- Page 1 MP905 HD media player User Manual The front panel The rear panel...
-
Page 2: Table Of Contents
MP905 User Manual Contents Chapter 1:Safety precautions.............03 Chapter 2:Item list..................04 Chapter 3: Product introduction.........05 Chapter 4:Hardware connection introduction......06 4-1 Rear panel effect diagram........06 4-2 Typical application connection diagram....06 4-3 Specifications............09 4-4 Installation dimension diagram......10 Appendix: modify the record table ..........11... - Page 3 MP905 User Manual Warning 1. This device shall not encounter water sprinkle or splash, please do not place anything containing water on this device. 2. To prevent fire, keep this device far from any fire source. 3. If this device gives out any strange noise, smoke or smell, please immediately unplug the power cord from receptacle, and contact local dealer.
-
Page 4: Chapter 2:Item List
MP905 User Manual Chapter 2 Item List Please unpack the product carefully, then check whether all the following things are included in the package. If anything is found missing, please contact the dealer. Standard Accessories The accessories supplied with this Media Player may differ from the figures contained in the User’s Manual, but they are applicable for the... -
Page 5: Chapter 3: Product Introduction
User Manual Chapter 3: Product Introduction The MP905 is a high-performance media player that supports up to @4K 60Hz output. It supports two-way USB input and USB plug and play function (automatically play video files in the root directory of the U-disk after inserting the U-disk). -
Page 6: Chapter 4:Hardware Connection Introduction
MP905 User Manual Chapter 4:Hardware Connection Introduction 4-1Rear panel effect diagram diagram 4-1 Rear panel effect diagram (1)TF card slot (2)Power input (3) WIFI antenna (4) Two-way USB input (5) Operation indicator light (6) Wired network interface (7)HDMI output 4-2 Typical application connection diagram... -
Page 7: Specifications
MP905 User Manual diagram 4-2 Typical application connection diagram 4-3 Specifications Amlogic S905 Functional DDRIII 1G characteristics operating android 5.1 system Output 4K（3840*2160 @60Frame/s）； resolution 1080p/720p/576p/480p/PAL/NTSC Video H.265 AVC HD、VC-1(WMV HD)、 compressi MPEG-2 HD、MPEG-1、MPEG-4、Xvid on format format Video file MKV/TS/M2TS/TP/TRP/AVI/WMV/RM/RMVB/MPEG/MPG... - Page 8 MP905 User Manual G.W.：0.38Kg weight N.W.：0.58Kg Accessories and 5V2A Power Adapter；Cable; Quick Operation Guide; CD other parameters...
-
Page 9: Installation Dimension Diagram
MP905 User Manual 4-4 Installation Dimensions diagram 4-4 Installation dimension diagram... -
Page 10: Appendix: Modify The Record Table
MP905 User Manual Appendix：modify the record table Version Time Description Draft V1.0 2018.2.08 MP905 first release...
