FeiYu Tech FY-30A Installation & Operation Manual

Inertial attitude balancer for multi-rotor control

Advertisement

Quick Links

F
Y
EI
U
T
ECH
Guilin Feiyu Electronic Technology Co., Ltd
Rm. C407, Innovation Building, Information Industry Park, Chaoyang Road, Qixing
District, GuiLin, CN
www.feiyu-tech.com
Email: feiyutech@yahoo.cn
FY-30A
for multi-rotor control Installation &
Operation Guide
Inertial attitude balancer

Advertisement

loading
Need help?

Need help?

Do you have a question about the FY-30A and is the answer not in the manual?

Questions and answers

Summary of Contents for FeiYu Tech FY-30A

  • Page 1 FY-30A Inertial attitude balancer for multi-rotor control Installation & Operation Guide Guilin Feiyu Electronic Technology Co., Ltd Rm. C407, Innovation Building, Information Industry Park, Chaoyang Road, Qixing District, GuiLin, CN www.feiyu-tech.com Email: feiyutech@yahoo.cn...
  • Page 2 Guilin Feiyu Electronics Co., Ltd. Dear Pilot, Thank you for choosing FY30A as your inertial stabilization solution. This manual mainly introduces FY30A firmware for Multi-rotor flight system. Please read this manual carefully before using the system to ensure proper use and operation. Note: ...
  • Page 3  Y3-copter  Any other configuration apply need, please e-mail us: service@feiyu-tech.com. RC Radio suitability: The FY-30A has been tested to work well with the following RC system:  Robbe-Futaba PPM / PCM 1024 / PCM G3 mode, 2.4G systems ...
  • Page 4 Auto Stabilization mode 3D Mode c) If you do not connect the Switch channel with your RC Receiver or FY-30A does not detect any incoming signal through this input channel, it will automatically engage Mode 1- Auto Stabilization Mode. However, we do not suggest flying the unit with no signal input to the Switch Channel.
  • Page 5 Guilin Feiyu Electronics Co., Ltd. FY-30A interface for multi-rotor POINT ARROW FORWARD (TOWARDS FLIGHT DIRECTION) Roll sensitivity knob Yaw sensitivity knob pitch sensitivity knob Function DIP switch Red LED: Solid ON indicates Blue LED: Flight mode indicator. vibration is too severe.
  • Page 6 Gyroscope initialization (re-setting): Out of the box, the FY-30A has been fully initialized. However, if the following condition occurs, resetting the gyro is recommended: The device is kept unused for a long time. 2. There is a change in environmental temperature of over 30 degrees.
  • Page 7 Yellow Rudder Channel 4 Brown Controlled 2-Way switch Channel 5 Note Channel 5 will output the signal to control the 2 flight modes of the FY-30A. Therefore assign 2-way switch to this channel. QUADCOPTER SET UP ESC4 Motor4 (RUD) ESC3...
  • Page 8 Guilin Feiyu Electronics Co., Ltd. X-Type Layout X-Type QuadCopter Layout: = ESC 1 CCW = ESC 2 CW = ESC 3 CCW = ESC 4 CW cw = clock wise ccw = counter clockwise Cross Type Layout 1 2 3 4 十...
  • Page 9 Guilin Feiyu Electronics Co., Ltd. The knob for Quadcopter 0 Min 0 Min 100 Max Turning the knob to the left will reduce the gyro gain ,turning to the right increase the gyro gain. Y3-COPTER SET UP Servo (RUD) ESC3 Motor3 (THR) ESC2...
  • Page 10: Vibration Damping

    FY-30A Module Installation 1. FY-30A has an arrow indicator on top. Please ensure this arrow is pointed towards the direction of flight. 2. Installed the module horizontally, and as close as possible to the aircraft center. A more centered installation will result in more stable drift free of hover.
  • Page 11 Ensure rigidity of your frame (will not flex with motor rotation). v) Use appropriate propeller length and pitch for the weight of your aircraft. d) The FY-30A is supplied with the shock absorbing mount and double-sided foam padding dampers. Please use them as shown below:...
  • Page 12 Guilin Feiyu Electronics Co., Ltd. 5. Check the FY-30A sensitivity control knobs. Please ensure the dials are beyond 12 o’clock. Anything less than that may result in no flight stability for this first flight. Tie down test: Before proceeding, we highly advise that you tie down the aircraft to the ground to prevent from any possibility of going out of control during this initial flight tests.
