  • Page 1 Network Computing FW-7573 User Manual Version: 1.8 Date of Release: 2018/06/19...
  • Page 2 FW-7573 User Manual The icons are used in the manual to serve as an indication of interest topics or important messages. Below is a description of these icons: Note: This mark indicates that there is a note of interest and is something that you should pay special attention to while using the product.
  • Page 3 This product has passed the CE test for environmental specifications. Test conditions for passing included the equipment being operated within an industrial enclosure. In order to protect the product from being damaged by ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the use of CE-compliant industrial enclosure products.
  • Page 4 FW-7573 User Manual Electrical equipment generates heat. Ambient air temperature may not be adequate to cool equipment to acceptable operating temperatures without adequate circulation. Be sure that the room in which you choose to operate your system has adequate air circulation.
  • Page 5 Ne travaillez pas seul si des conditions dangereuses sont présentes. Ne considérez jamais que l’alimentation est coupée d’un circuit, vérifiez toujours le circuit. Cet appareil génère, utilise et émet une énergie radiofréquence et, s’il n’est pas installé et utilisé conformément aux instructions des fournisseurs de composants sans fil, il risque de provoquer des interférences dans les communications radio.
  • Page 6 FW-7573 User Manual les effets néfastes du bruit externe et réduire les risques d’électrocution en cas de foudre. Pour désinstaller l’équipement, débranchez le câble de mise à la terre après avoir éteint l’appareil. Un câble de mise à la terre est requis et la zone reliant les sections du conducteur doit faire plus de 4 mm2 ou 10 AWG.
  • Page 7 Version Descriptions Change HDD specifications by taking off the support of 1x3.5”; change the Bypass Manual download site. Change the CPU specification to C2758/C2518 Change PCIe x8 golden finger to 2 PCIe x4 Change power supply to 150W Change two fans to only one fan Change the board layout to take out fan 1 and fan3 Change the front panel picture;...
  • Page 8 FW-7573 User Manual Package Content ......................... 10 Optional Accessories ........................11 Ordering Information ......................... 11 System Specifications ......................... 12 Front Panel Features ........................13 Rear Panel Features ........................15 Preparing the Hardware Installation ..................16 Installing the System Memory ....................16 Installing the Hard Disk .......................
  • Page 9 Boot Setup ..........................67 Save and Exit Setup ........................68 Lanner Generation 3 Bypass ....................... 71 Parallel Text-based LCM Build ....................73 Warranty Policy .......................... 76 RMA Service ..........................76 RMA Service Request Form ......................77...
  • Page 10 FW-7573 User Manual Thank you for choosing FW-7573. This system integrates the newest Intel® Atom Processor C2000 series processor, codenamed Rangeley, with the Intel QuickAssist technology to provide a robust and high performance communication platform. It supports up to 16GB of DDR3 system memory at 1333 or 1600 MHz on dual-channel DIMM banks.

  • Page 11: Chapter 1: Introduction

    Chapter 1: Introduction The system has a variety of optional accessories; visit the following website for more information. http://www.lannerinc.com/products/x86-network-appliances/rackmount/fw-7573 SKU No. Main Features Intel® Atom™ processor C2758, 6 GbE LAN ports with Gen.3 Bypass, 1 x NIC expansion FW-7573A slot, 150W ATX PSU, and TPM Intel®...
  • Page 12 FW-7573 User Manual Form Factor 1U Rackmount 8-core Intel® Atom Processor Options Processor C2000 series (Codenamed “Rangeley”) Platform FW-7573A: C2758 Chipset FW-7573B: C2518 FW-7573E: C2758 BIOS AMI BIOS 16Mbit, TPM secure-boot Dual-channel DDR3 1333/1600 MHz (ECC or Technology non-ECC, 1.5V) System Memory Max.
  • Page 13 Chapter 1: Introduction F1 Power/Status/HDD LED Power: If the LED is on it indicates that the system is powered on. If it is off, it indicates that the system is powered off. Status: This LED is programmable. You could program it to display the operating status with the following behavior: If the LED is green, it indicates that the system’s operational state is normal.
  • Page 14 BIOS; the default is disabled). Three pairs (LAN1-LAN2, LAN3-LAN4, LAN5-LAN6) can be configured as LAN Bypass by using Lanner Gen3 Bypass technology when failure events occur. This feature can be enabled dynamically with a watch dog timer.
  • Page 15 Chapter 1: Introduction R1 Reserved for PCIe Expansion Slot R2 CPU Fan This fan has smart fan feature which can be turned on automatically when the temperature exceeds the set threshold. R3 Power-on Switch It is a switch to turn on or off the power. R4 AC Power Socket The system equips an ATX 150W Power Supply.
  • Page 16 AC power is removed. Unpower the FW-7573 and remove the power cord. Unscrew 2 screws on each side and the rear of the top cover of the FW-7573 System. Slide the cover backwards to open it.

  • Page 17: Chapter 2: Hardware Setup

    Chapter 2: Hardware Setup The system can accommodate two 2.5” Serial-ATA disks. Follow these steps to install a hard disk into the FW-7573: PS4P2 PS4P2 Note: Please note the orientation of the HDD tray placement when you take out the tray. It is...
  • Page 18 FW-7573 User Manual 1. Locate the disk bay area in the chassis. 2. Loosen the three screws that secure the empty HDD tray. 3. Insert the four rubber washers into the four notches of the tray. Align and push the washer horizontally into the notch.
  • Page 19 Chapter 2: Hardware Setup 5. Insert one end of the SATA data cable to the SATA contacts on the disk. Do the same to the SATA power cable. 6. Secure the tray on the motherboard with three provided screws. 7. Insert the other end of the SATA data cable to a SATA port on the motherboard.
  • Page 20 FW-7573 User Manual To install the front Ethernet module, take off the front bezel first by loosening the thumbscrews on the front of LAN module. Insert the Ethernet module into the front expansion slot. You should hear a click when the module connects to the system’s main board.
  • Page 21 Chapter 2: Hardware Setup FW-7573 provides one CompactFlash slot. Follow the procedures bellow for installing a CompactFlash card. Align CompactFlash card and the card slot with the arrow pointing toward the connector. The card fits only the correct way into the slot; do not force the card into the slot.

  • Page 22: Block Diagram

    FW-7573 User Manual The block diagram depicts the relationships among the interfaces or modules on the motherboard. Please refer to the following figure for your motherboard’s layout design.

  • Page 23: Chapter 3: Motherboard Information

    Chapter 3: Motherboard Information The motherboard layout shows the connectors and jumpers on the board. Refer to the following picture as a reference of the pin assignments and the internal connectors.
  • Page 24 FW-7573 User Manual Fan Connectors (FAN2): The 5-pin connector is for connecting the CPU fan. It comes with the smart fan feature by which the fan could be monitored and turned on when the temperature exceed the set threshold. Note: FAN2 (CPU) fan can be set to be in either manual mode or smart fan mode in the BIOS menu.
  • Page 25 Chapter 3: Motherboard Information Dual USB 2.0 Ports (USB1): This provides two USB 2.0 ports in the front panel. Console Port (COM1)
  • Page 26 FW-7573 User Manual Serial Interface Connectors (COMB1): It is for connecting the RS-232 serial port (COM2) interface cable. LAN 1~4: LAN Connector(RJ-45, provided by Intel Marvell 88E1543) LAN 5~6 Connector (RJ-45, provided by Intel Ethernet i210AT) Parallel Interface for LCM (front LCD module) card...
  • Page 27 Chapter 3: Motherboard Information Clear CMOS jumper (JBAT1): It is for clearing the CMOS memory and system setup parameters by erasing the data (except for Quied Boot settings) stored such as the system passwords in the CMOS RAM. CompactFlash Connector (CF2): It is for connecting a Compact Flash card to be served as your system’s storage.

  • Page 28: Intelrc Setup

    FW-7573 User Manual DIMM Socket (DIMM1/DIMM2): The 240-pin DDR3 DIMM is for connecting the DDR3 1333/1600 memory. The system can support up to 16 GB in maximum with dual channel configuration. To activate dual channel, insert memory in both DIMM1 and DIMM2 slot: SATA Connector (SATA1/SATA2, SATA6G_1, SATA6G_2): It is for connecting a SATA hard disk to be served as your system’s storage.
  • Page 29 Chapter 3: Motherboard Information Power-switch Connector (SW1): Power tact for booting up the system. AT Mode Power Button Connector (CONN1): It is for connecting the power switch in AT mode Reset Switch (SW2) and Reset Button Connector (CONN2) Hardware/Software Reset Function (J5): It is a pin header to switch between hardware and software reset function for the front panel reset button.
  • Page 30 FW-7573 User Manual SPI-ROM Update Connector (SPI-ROM1): It is for updating the SPI Flash soldered on board for service and repair purposes. LPC I/O bus (It can also be called Port 80) (LPC1): It is a proprietary connector for connecting a checkpoint device to output checkpoints throughout booting and Power-On Self Test (POST) to indicate the task the system is currently executing.
  • Page 31 Chapter 3: Motherboard Information PCIe Expansion Connector (PCIEC1): PCIe expansion connector (two PCIe x 4) for front Ethernet module or other type of expansion through the back panel.
  • Page 32 FW-7573 User Manual Case open (OPEN1): Case opening detection pin header...

  • Page 33: Chapter 4: Bios Settings

    Chapter 4: BIOS Settings BIOS is a hardware configuration program that allows you to change the system setting anytime using BIOS To enter the BIOS setup utility, simply follow the steps below: 1. Boot up the system. 2. Pressing the <Tab> or <Del> key immediately allows you to enter the Setup utility, then you will be directed to the BIOS main screen.
  • Page 34 FW-7573 User Manual The main BIOS setup menu is the first screen that you can navigate. Each main BIOS setup menu option is described in this chapter. The Main BIOS setup menu screen has two main frames. The left frame displays all the options that can be configured.
  • Page 35 Chapter 4: BIOS Settings Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as SuperIO Configuration, to go to the sub menu for that item.
  • Page 36 FW-7573 User Manual This option allows you to configure parameters regarding BIOS support for security device. Press <Enter> to access the submenu.
  • Page 37 Chapter 4: BIOS Settings Item Option Description Enables or disables BIOS support for the security device. By Enabled Security Device Support disabling this function, OS will not show Security Device. Disabled TCG EFI protocol and INT1A interface will not be available. Enabled SHA-1 PCR Bank Enables or disables SHA-1 PCR Bank.
  • Page 38 FW-7573 User Manual TPM 20 InterfaceType Select TPM 20 Device for the Communication Interface. TPM 1.2 will restrict support to TPM 1.2 devices; while TPM TPM 1.2 2.0 will restrict support to TPM 2.0 devices; Auto will Device Select TPM 2.0 support both with the default set to TPM 2.0 devices.
  • Page 39 Chapter 4: BIOS Settings This option allows you to configure parameters about Super IO Chip. Press <Enter> to access the submenu. Select “Serial Port 1 Configuration”, “Serial Port 2 Configuration” or “Parallel Port Configuration” to enter sub setting screen.
  • Page 40 FW-7573 User Manual Serial Port 1 Configuration Item Option Description Enabled Serial Port Enables or disables Serial Port 1. Disabled Device Settings IO=3F8h; IRQ = 4...
  • Page 41 Chapter 4: BIOS Settings Serial Port 2 Configuration Item Option Description Enabled Serial Port Enables or disables Serial Port 2 Disabled Device Settings IO=2F8h; IRQ = 3...
  • Page 42 FW-7573 User Manual Parallel port Configuration Item Option Description Disabled Parallel Port Enable or Disable Parallel Port (LPT/LPTE). Enabled Device Settings IO=378h; IRQ = 5...
  • Page 43 Chapter 4: BIOS Settings This menu shows the hardware monitor configuration settings. Select an item then press <Enter> to display the configuration options. Press <Enter> to access the submenu. Feature Options Description Enabled After enabling "CPU Smart Fan" function, the system automatically Smart Fan Function Disabled adjusts the CPU fan speed.

  • Page 44: Displayed Information

    FW-7573 User Manual Displayed Information SYS/CPU Temperature The onboard hardware monitor automatically detects and displays the CPU and motherboard temperatures. FAN2 Speed (CPU FAN) The onboard hardware monitor automatically detects and displays the CPU fan speeds in rotations per minute (RPM). If the fan is not connected to the motherboard, it displays N/A.

  • Page 45: Smart Fan Configuration

    Chapter 4: BIOS Settings Smart Fan Configuration It allows you to configure the smart fan feature. You can manually turn on the CPU fan or set the target CPU temperature at which the CPU fan will start running if the fan is not yet turned on. And the CPU fan can also be turned off automatically if the temperature for the CPU is at or below the specified value.
  • Page 46 FW-7573 User Manual Console Redirection Settings Feature Options Description VT100: ASCII char set VT100 VT100+:Extends VT100 to support color, function keys, etc. VT100+ Terminal Type VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or VT-UTF8 more bytes ANSI...
  • Page 47 Chapter 4: BIOS Settings Disabled With this mode enabled, only text will be sent. This is to capture Recorder Mode Terminal data. Enabled Disabled Enables or disables extended terminal resolution. Resolution 100x31 Enabled Legacy OS 80x24 On Legacy OS, the Number of Rows and Columns supported Redirection redirection.
  • Page 48 FW-7573 User Manual This option enables or disables UEFI network stack. Press <Enter> to access the submenu. Item Option Description Disabled Network Stack Enables or disables UEFI Network Stack Enabled...
  • Page 49 Chapter 4: BIOS Settings Enabling this function to access the following configurations: Item Option Description Disabled Enables Ipv4 PXE Boot Support. If IPV4 is disabled, PXE boot Ipv4 PXE Support Enabled option will not be created. Disabled Enables Ipv6 PXE Boot Support. If IPV6 is disabled, PXE boot Ipv6 PXE Support Enabled option will not be created.
  • Page 50 FW-7573 User Manual This option allows you to enable or disable ROM execution settings. Press <Enter> to access the submenu. Feature Options Description Enable/Disable CSM Support Disabled CSM Support Enabled...
  • Page 51 Chapter 4: BIOS Settings UPON REQUEST - GA20 can be disabled using BIOS services. ALWAYS - do not allow disabling Upon Request GateA20 Active GA20; this option is useful when any RT code is Always executed above 1MB. Set display mode for Option ROM Force BIOS Option ROM Messages Keep Current...
  • Page 52 FW-7573 User Manual You can use this screen to select options for the USB Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. The settings are described on the following pages.
  • Page 53 Chapter 4: BIOS Settings Item Value Description Enables Legacy USB support. Enabled AUTO option disables legacy support if no USB Legacy USB Support Disabled devices are connected. Auto DISABLE option will keep USB devices available only for EFI applications. This is a workaround for OSes without EHCI Enabled EHCI Hand-off hand-off support.
  • Page 54 FW-7573 User Manual Press <Enter> to access the submenu.
  • Page 55 Chapter 4: BIOS Settings Item Value Description Press[Enter]for configuration of advanced items, including the following:  Link Speed: Change link speed duplex for current port; NIC Configuration options are AutoNeg/10Mbps, Half/10Mbps, Half/10Mbps, Half/100Mbps, and Full.  Wake On LAN: Enable/Disable WakeOnLANfeature. 0-15 Blink LEDs for the specified duration (up to 15 seconds).
  • Page 56 FW-7573 User Manual You can use this screen to view the capabilities and of your CPU. You can also use this menu to . Select the IntelRCSetup menu item from the BIOS setup enable/disable certain functions of your CPU screen to enter the IntelRCSetup screen. Users can select any of the items in the left frame of the screen.
  • Page 57 Chapter 4: BIOS Settings Press <Enter> to access the submenu. Feature Options Description Enable/Disable EIST. GV3 and TM1 must be enabled for TM2 to be Disable EIST(GV3) available. GV3 must be enabled for Turbo. Auto - Enable for B0 CPU Enable stepping, all others disabled, change setting to override.
  • Page 58 FW-7573 User Manual Enable Enable /Disable TM1. TM1 and GV3 must be enable in order to Disable support TM2 Enables the Enhanced Cx state of the CPU, takes effect after reboot. Disable CPU C State Auto - Enable for B0 CPU stepping, all others disabled, change Enable setting to override.
  • Page 59 Chapter 4: BIOS Settings Press <Enter> to access the submenu.
  • Page 60 FW-7573 User Manual Press <Enter> to access the submenu. Feature Options Description SMBUS Controller Enable SMBUS Controller options Disable Restore On Power Power On Specify what state to go to when power is re-applied after a...
  • Page 61 Chapter 4: BIOS Settings Loss Power Off power failure (G3 state). Last State Auto SATA Configuration...
  • Page 62 FW-7573 User Manual SATA Mode Selection The system supports various SATA modes. Feature Options Description Disable SATA Controller Enables or disables SATA controller Enable This item identifies whether the SATA port is connected to a SATA Mode AHCI SSD and HDD. Select IDE, AHCI or RAID. The default is “AHCI”.
  • Page 63 Chapter 4: BIOS Settings Use [←] / [→] to select [Security] setup screen. Under this screen, you may use [↑] [↓] to select an item you would like to configure. Item Description Administrator Set the administrator password. Once set, then this only limits access to Setup and Password is only asked for when entering Setup.
  • Page 64 FW-7573 User Manual Item Option Description Attempt Disabled Secure Boot is activated when Platform Key (PK) is enrolled, Secure Boot Enabled System mode is User/Deployed, and CSM function is disabled. Secure Boot mode selector: Secure Boot Standard In Custom mode, Secure Boot Variables can be configured...
  • Page 65 Chapter 4: BIOS Settings Key Management Allows you to provision advanced Secure Boot settings. Description Item Description Provision Factory Enable Allow to provision factory default Secure Boot Defaults Disabled Keys when System is in Setup Mode Item Description Install Factory Default Forces System to User Mode - install all Factory Default keys when system is keys in Setup Mode.
  • Page 66 FW-7573 User Manual Item Description Platform Key (PK) This feature is to enroll Factory Defaults or load the keys from a file with: Key Exchange Keys 1. Public Key Certificate in: Authorized Signature a) EFI_SIGNATURE_LIST b) EFI_ CERT_X509 (DER encoded)
  • Page 67 Chapter 4: BIOS Settings Use [←] / [→] to select [Boot] setup screen. Under this screen, you may use [↑] [↓] to select an item you would like to configure. Item Option Description Number of seconds to wait for setup activation key. Setup Prompt Timeout 65535 means indefinite waiting.
  • Page 68 FW-7573 User Manual Use [←] / [→] to select [Save & Exit] setup screen. Under this screen, you may use [↑] [↓] to select an item you would like to configure. ■Save Changes and Reset When Users have completed the system configuration changes, select this option to save the changes and Reset from BIOS Setup, so the new system configuration parameters can take effect.
  • Page 69 Chapter 4: BIOS Settings ■Restore Defaults Restore default values for all setup options. Select “Yes” to load Optimized defaults.

  • Page 70: Watchdog Timer

    FW-7573 User Manual A watchdog timer is a piece of hardware that can be used to automatically detect system anomalies and reset the processor in case there are any problems. Generally speaking, a watchdog timer is based on a counter that counts down from an initial value to zero. The software selects the counter’s initial value and periodically restarts it.
  • Page 71 Bypass Gen 3 employs a programming method to control the bypass function by software. There are typically two communication statuses for the bypass function; one is “Normal’ and another is “Bypass” status. Furthermore, the Lanner Bypass software is capable to control the bypass status in the following 3 states: When the system powers off, it can be forced to enable the LAN Bypass function .
  • Page 72 FW-7573 User Manual Console redirection lets you monitor and configure a system from a remote terminal computer by re-directing keyboard input and text output through the serial port. The following steps illustrate how to use this feature. The BIOS of the system allows the redirection of the console I/O to a serial port. With this configured, you can remotely access the entire boot sequence through a console port.

  • Page 73: Appendix D: Programming The Lcm

    After compiled, the executable programs (plcm_test, plcm_cursor_char, Test) and the driver (plcm_drv.ko or plcm_drv.o) will appear in the program’s folder. Note: The OS supported by Lanner LCM function include platforms based on Linux Kernel series 2.4.x and Linux Kernel series 2.6.x.
  • Page 74 After compiled, the executable programs (plcm_test, plcm_cursor_char, Test) and the driver (plcm_drv.ko) will appear in the program’s folder. Note: The OS supported by Lanner LCM function include platforms based on Linux Kernel series 2.4.x and Linux Kernel series 2.6.x. Install #insmod plcm_drv.ko...
  • Page 75 Appendix E: Installing Intel QuickAssist Software for Linux The FW-7573 platform incorporates Intel QuickAssist Technology, which includes acceleration modules that are accessed via Intel QuickAssist software. The Intel quickAssist software also enables the acceleration modules to be easily accessed by open source software such as OpenSSL. The Intel QuickAssist Technology...

  • Page 76: Rma Service

    FW-7573 User Manual 1. All products are under warranty against defects in materials and workmanship for a period of one year from the date of purchase. 2. The buyer will bear the return freight charges for goods returned for repair within the warranty period;...

  • Page 77: Appendix F: Terms And Conditions

    Appendix F: Terms and Conditions When requesting RMA service, please fill out the following form. Without this form enclosed, your RMA cannot be processed.
