Technical Specification
DESKO NEPTUN chrom
DESKO GmbH
Gottlieb-Keim-Str. 56
95448 Bayreuth
GERMANY
Phone: +49 (0)921/79279-0
Fax:
+49 (0)921/79279-14
E-mail:
info@desko.com
Web:
www.desko.com
Technical Support:
E-mail:
support@desko.com
Website:
www.desko.com/support
Technical Specification
DESKO NEPTUN chrom
| Phone: +49 (0) 921 79279-69 |
Doc # 7 001 160 101
®
Page 1 of 18
Doc.-Rev: 2018-06-06
Advertisement
Table of Contents
Summary of Contents for DESKO NEPTUN chrom
- Page 1 Technical Specification DESKO NEPTUN chrom ® DESKO GmbH Gottlieb-Keim-Str. 56 95448 Bayreuth GERMANY Phone: +49 (0)921/79279-0 Fax: +49 (0)921/79279-14 E-mail: info@desko.com Web: www.desko.com Technical Support: E-mail: support@desko.com | Phone: +49 (0) 921 79279-69 | Website: www.desko.com/support Technical Specification Page 1 of 18...
-
Page 2: Table Of Contents
Table of Contents DESKO Official Explanation of Abbreviations ............3 Handling Rules & Package Content ..............4 Handling of the NEPTUN chrom ............... 4 Package Content ..................4 Introduction ...................... 5 Features of the NEPTUN chrom ................6 Ingress Protection 54 (IP54) ..............6 3.1.1... -
Page 3: Desko Official Explanation Of Abbreviations
DESKO Official Explanation of Abbreviations 1D Code Linear or one-dimensional Barcode 2D Code Two-dimensional Barcode Application Programming Interface Barcode Barcode Reader Dynamic Link Library Dots Per Inch DUKPT Derived Unique Key per Transaction ICAO International Civil Aviation Organization Ingress Protection... -
Page 4: Handling Rules & Package Content
1 Handling Rules & Package Content 1.1 Handling of the NEPTUN chrom The NEPTUN chrom is designed to work in a rough environment and withstand light shocks. Nevertheless, the device contains a precise opto-mechanical part. Therefore, DESKO recommends the following handling rules: Do not drop the device. -
Page 5: Introduction
Quick Installation Guide or need access to our download area. The NEPTUN chrom is ideal for data gathering applications of OCR documents with a machine-readable zone and magnetic stripe documents. Such applications are usually found in the airline and airport environment, ticket- and border control or public authority environment and many more. -
Page 6: Features Of The Neptun Chrom
3 Features of the NEPTUN chrom 3.1 Ingress Protection 54 (IP54) The NEPTUN chrom is protected against dust and water according to IP54 regulations. IP stands for ingress protection and is a rating code commonly used for security equipment. It consists of two digits, which show the level of protection a device has against dust and water. -
Page 7: Magnetic Stripe Reader (Msr)
(blinking, 2 times) 3.1.4 Buzzer The NEPTUN chrom is equipped with an internal buzzer for audible user feedback. The buzzer volume can be adjusted by device configuration. See chapter 7 for further details regarding firmware and device configuration. -
Page 8: Serial Aux Port (Optional)
Picture 2: SUBD of NEPTUN chrom 3.1.6 Chip Card Module (optional) The NEPTUN chrom can be equipped with an ISO 7816 compliant chip card reader. The card reader module is designed for reading synchronous and asynchronous chip cards with the following standards: ISO 7816, 2-wire SLE 4432/42, 3-wire SLE 4418/28, I2C, SLE 4404. -
Page 9: Nfc/Rfid Reader (Optional)
It has to be considered that, in case of USB bus powered devices, these two USB AUX ports and the NEPTUN chrom have to share the power, which is provided by the USB port of the workstation. According to the USB 2.0 specification, one USB port has to provide 500 mA. -
Page 10: Software Integration
Virtual Serial Connection For using the DESKO NEPTUN chrom via a virtual serial port, it is necessary to install the DESKO VCOM software package. Please refer to the Quick Installation Guide, which is shipped with the device, for more information. -
Page 11: Usage Of The Neptun Chrom
Usage of the NEPTUN chrom As soon as the NEPTUN chrom is connected to a PC, the device is ready to read OCR and MSR data from various documents. The NEPTUN chrom provides the OCR and MSR scan functionality in only one slot. To read a document, the medium (e.g. -
Page 12: Reading An Msr Document
Picture 4: Position of magnetic stripe card Depending on the read result, the buzzer and the multicolor LED give a respective feedback (see chapters 3.1.3 and 3.1.4). Technical Specification Page 12 of 18 DESKO NEPTUN chrom Doc # 7 001 160 101 Doc.-Rev: 2018-06-06... -
Page 13: Using The Chip Card Reader
7.2 Using the Chip Card Reader The chip card reader module of the NEPTUN chrom is able to read ISO 7816 compliant chip cards. For using the chip card reader it is necessarry to install an appropriate software packet. Please refer to the Quick Installation Guide, which is shipped with the hardware or contact our support team at support@desko.com. -
Page 14: Warranty
Warranty excludes normal wear and tear. Support Please check if the NEPTUN chrom is properly connected to your PC and, if needed, the software is installed. If this is the case and the device still does not work, please... -
Page 15: Technical Overview
Approx. 1400 g (3 lb) Width: 200 mm (7.87 inches) Length: 385 mm (15.16 inches) Height: Back 43 mm (1.69 inches) Front 18 mm (0.71 inches) Technical Specification Page 15 of 18 DESKO NEPTUN chrom Doc # 7 001 160 101 Doc.-Rev: 2018-06-06... -
Page 16: Technical Drawing
11.3 Technical Drawing Technical Specification Page 16 of 18 DESKO NEPTUN chrom Doc # 7 001 160 101 Doc.-Rev: 2018-06-06... -
Page 17: Regulation Information
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. CAUTION: Any changes or modifications not expressly approved by DESKO GmbH could void the user’s authority to operate the equipment. Technical Specification... -
Page 18: Supplier's Declaration Of Conformity
13 Supplier's Declaration of Conformity Unique Identifier: NEPTUN chrom® Party issuing Supplier’s Declaration of Conformity DESKO GmbH Gottlieb-Keim-Str. 56 95448 Bayreuth GERMANY Phone: +49 (0)921/79279-0 Web: www.desko.com Responsible Party – U.S. Contact Information DESKO LC 1800 Pembrook Drive Suite 300...
