Body Clock Easy TENS Instructions For Use

Advertisement

Quick Links

Electrode Placement
KEY:
=first pair of electrodes
=second pair of electrodes.
N.B. Electrodes supplied with this unit are all the same colour - the
black and white squares show suggested electrode placement only.
8
Frequently Asked
Troubleshooting
Questions
Questions
Is it safe?
Why does the pulse sensation
Yes, TENS is used widely for
not appear to be as strong after
pain relief and is recommended
you have used the Easy T ENS
by medical professionals.
for a while?
Increase the intensity, you may
Can I use it with other
have become acclimatised to a
medications?
lower setting.
Yes. TENS is drug free so
you can use it with any
Why does the pulse sensation
other medication including
feel strong but ineffective?
paracetamol.
You may need to reposition the
electrode pads (don't forget to
What conditions can TENS
switch the Easy TENS off before
be used to treat?
doing so).
TENS can be used to treat
numerous pain conditions.
Why does the sensation not
If you are unsure about using
feel sufficiently strong even on
TENS please consult your
a high setting?
medical adviser or contact
The batteries may need
Body Clock Health Care on
replacing.
(+44) (0)20 8532 9595.
Useful Information
Can I use the Easy TENS for
1. If electrodes become dry,
labour?
switch off the unit, disconnect
This is not recommended.
the electrodes, and apply a
For information on TENS for use
small drop of water to them.
during labour, please visit
2. Ensure the unit is switched
www.babycaretens.com or call
off before removing wires and
(+44) (0)845 230 9737.
pads. Do not pull the wires.
ALWAYS remove the jack plug
from the socket by holding
between forefinger and thumb.
10
9
Easy TENS Technical Data
Display:
The LCD has a total of 13 display segments.
The array of Level Bars consists of 10 LCD Level
Bar. In addition, 2 individual LCD segments
respectively indicate the Modes (i.e. Burst
and Boost). The last LCD segment is used to
illuminate the low battery indicator.
Mode:
2 operation modes
Pulse
Pulse
Frequency
Width
BURST
32Hz
150µs
second
burst
BOOST
70Hz
150µs
Output Channel
ONE Channel
Automatic Power Off 5 minutes
Output Voltage
0 – 55V (zero-to-peak) across
a 500Ω load; adjustable in 10 steps
Output Intensity
110 mA (max.) into a 500Ω load
Output Waveform
Symmetrical Mono-phasic rectangular
Output Jacks
CE Touch-proof jacks
Battery
2 X1.5V AAA Battery (Type LR03)
Battery Low Detect
2.2V±0.1V
Tolerances
All output parameters are subjected to a
±10% tolerance unless other specified
11
Your 5 Year Guarantee
Your Easy TENS machine is
guaranteed for a period of 5 years
against manufacturer's defects.*
*The guarantee does not include leads, electrodes or battery.
Pattern
2 bursts per
8 pulses per
Constant pulse
Body Clock Health Care Ltd
e-mail customercare@bodyclock.co.uk
108 George Lane, South Woodford
London, UK E18 1AD
Tel (+44) (0)20 8532 9595
Fax (+44) (0)20 8532 9551
www.bodyclock.co.uk
0120
June 2017 (2)
