  • Page 1 USER MANUAL AND SETUP INSTRUCTIONS www.casals.com CV072018-1...
  • Page 2 INDEX MAIN WINDOW DISPLAY p. 3 MANAGEMENT OF FAN SPEED, FLOW OR CONSTANT PRESSURE p. 4 BOOSTER FUNCTION p. 5 AIR POST-TREATMENT MANAGEMENT p. 5 PREHEATING MANAGEMENT p. 6 SELECTION MENÚ p. 6 STATUS MENÚ: OPERATING STATUS p. 7 PROGRAM MENÚ: MANAGEMENT OF THE WEEKLY SCHEDULE p.
  • Page 3 VISUALIZATION MAIN SCREEN The touch screen control panel has been designed to manage units of Mechanically Controlled Ventilation with Heat Recovery (VMC-RC) in a simple and intuitive way. The user manages the control by means of the icons of the graphic screen making a slight pressure on them; The direction buttons, which appear after the pressure in a modifiable parameter, allow the user to interact with the unit by going through menu items and modifying values.
  • Page 4 MANAGEMENT OF FAN SPEED, FLOW OR CONSTANT PRESSURE To modify this parameter, the icon at the top right of the synoptic table must be selected by clicking on it (it will turn green and the direction buttons will appear). Then press the icon of the address button up to increase or down direction to decrease the value located next to it; Once the desired one is located, press the OK button to confirm the selection.

  • Page 5: Booster Function

    BOOSTER FUNCTION By selecting the icon on the lower left you access the booster function. Through this you can select a time interval (from a minimum of 1 mi- nute to a maximum of 4 hours) in which to operate the unit at maximum power. The booster function is a priority with respect to other modes of fan speed management.

  • Page 6: Menu Selection

    PREHEATING MANAGEMENT In addition to the post-heating, the CTRL-MAX control is able to manage an electric preheating system (operated by a PWM signal or on-off ) to prevent the formation of ice inside the heat exchanger. The control automatically activates the anti-frost procedure when the temperature measured by the expulsion probe (Tx) drops below the value of 3 °C.
  • Page 7 STATUS MENU: OPERATING STATUS If the remote control panel is used to manage several units (master-slave mode), a screen with the list of available machines (max 4) will appear in the menu: Selection of unit to control configuration menu status Display menu status To view the status of an individual unit, select it (move with the arrows and confirm the selection with OK).
  • Page 8 Dp Supply Only for units of constant pressure with control over two flows. Pressure value in pascals below the driving fan. Fan exhau. Exhaust fan speed, see vent. Entr. Only Evo-d. If on, it indicates the independent regulation of the return fan from Modbus. FanE Remote Only for units of constant flow with control over two flows or with flow sensors.
  • Page 9 Dehumidif.On/Off It is active if the control is configured to manage the dehumidification system - on dehumidification enabled - off dehumidification disabled. DWat. NoFrost Off\On It is active if the control is configured to manage the dehumidification system Air temperature after the cold coil in °...
  • Page 10 DEFAULT By selecting this menu item and pressing the OK button, the parameters for the management of the unit are automatically assigned the preset values: Program valid from Monday to Friday: TIME TABLE Time table Speed fans/ air flow/ pressure Air after-treatment condition: (ON enabled, OFF inhibited) 00:00 ->...
  • Page 11 TIMETABLE By selecting this menu item and pressing the OK button you access the summary display of each day of the week, divided into 24 hours. detail of one day a week summary display To change the settings of each day, simply select it, in the summary display screen, and press the OK button; At this moment the detail screen of the selected day will be shown, in which the list of the eight possible time slots (C1-C8) appears, the day of the week in which it is being operated is shown in the upper left part of the screen.
  • Page 12 Disabled heating Post-heating enabled After carrying out the personalization of a day of the week according to your own needs (for example, Monday), you can copy the program- ming made on another day without having to repeat the whole procedure described above. In the summary display window of time slots, select the day in which you want to copy the previously made programming (for example, Tuesday) and press OK.
  • Page 13 CLOCK MENU: CLOCK SETUP This menu allows adjusting the day of the week and the current schedule for a correct management of the weekly schedule Configuration of the day Select the day / day line and press the OK button, the current day set will turn green; Scroll with the direction buttons to locate the desired day. Press the OK button to confirm the selection, the day will change from green to blue.

  • Page 14: Alarm List

    ALARM LIST Parameter State The configuration is correct. The configuration of the digital inputs or hardware is incorrect. Check the ext. Configuration Inputs in the factory menu. (eg if the same function is configured for several inputs) or Hardware (Hw evo-compact-> el.water). Communication The communication between the cards in the machine and the remote control panel works correctly.
  • Page 15 It is present only if the air after-treatment management is configured with wa- ter coil (Factory menu). The temperature of the water leaving the coil is higher than a safety threshold; there is no risk of freezing the water in the coil. Tw (water low) Risk of freezing the liquid in the water coil.
  • Page 16 It is only present if the automatic speed management of the fans with CO or CO-VOC sensor (Installer menu) is configured or there is an excess of CO2 in the Autominutes environment. The sensor works correctly. Possible anomaly in the sensor. It is activated if the unit fails to exit the antifreeze mode of the exchanger within 2 minutes.
  • Page 17 Bypass configured in universal mode (Factory menu), three values can be selected for the bypass parameter: Automatic bypass: A temperature range, comprised between TMIN and TMAX, is considered comfortable for the user; If the internal temperature (Tr) is within this range, the bypass will remain closed.
  • Page 18 PARAMETERS AVAILABLE IN THE INSTALLER MENU Language With this parameter you can select the language in which all the menus will be displayed (with the exception of the Factory menu, which will always be displayed in English). GB English display (default value) FR Display in French ES Display in Spanish IT Display in italian...
  • Page 19 HR Sensor The speed of the fans will be regulated by a relative humidity (RH) sensor with 0-10V output and linear characteristic between 0 and 100% RH (0V correspond to 0% RH and 10V correspond to 100% RH); If the external signal from the HR sensor assumes a value equal to 0V, the control will signal an alarm.
  • Page 20 AutoMin % This parameter is available only if the auto parameter is set to ext. or HR sensor. It can take values between 0 and 99% (steps 1%) with the limitation that AutoMin% <AutoMax% For units equipped with variable speed fans: If auto signal ext.
  • Page 21 AutoMinutes 000 -> 240 This parameter is available only if the auto parameter is set to a value other than none. No (default value) there is no effect on the operation of the system. It is a value expressed in minutes, it represents the interval of time elapsed since the signal of the external device for the auto mode has reached, or exceeded, the value AutoMax% or Auto Max ppm, without descending below said value, above which indicates an anomaly in the external device (CO2 probe, HR or external signal).
  • Page 22 Vel.max 055% ->100% This parameter is available if the control is set to manage variable speed fans (Factory menu) Default value 100%, is the maximum speed of the fans expressed as a percentage of the nominal value (reduction of the maximum speed). The maximum speed adjustable in the main window will always be 100% even for Vel values.
  • Page 23 Caud.Extr.=XXX% Caud.Ingr. 067%->150% This parameter is available only for units adjusted to constant pressure with control over the two flows. Default value 100%, expresses, in percentage, the desired ratio between the flow rate of the extraction fan and the supply fan, allowing an imbalance to be made between the flow rates of the two flows.
  • Page 24 WINTER TEMPERATURE / SUMMER TEMPERATURE Through these parameters you can access the menus below to adjust the effective return temperature threshold values (Tr) for bypass or base management for bypass management with air after-treatment. The summer / winter values coincide in order to have an optimal setting for all seasons.
  • Page 25 COMMUNICATION (ONLY CTRL-MAX IP TOUCH PANEL WITH MODBUS) A version of the touch screen control that supports the Modbus TCP-IP protocol is available through an ethernet connector mounted directly inside the panel or Modbus RTU via an RS485 additional interface card upon request. For wiring, see the section “Wiring the control panel” . In this submenu, the installer menu, the communication parameters of the modbus protocol in use can be established.
  • Page 26 Parameters Specifications Modbus protocol - MODBUS TCP-IP: Transmission speed: 10/100 Mbit / s. Automatic negotiation of transmission speed. Auto -MDIX (automatic swap for crossed cables), disconnection after 10 sec without access to the registers (modifiable via MODBUS). Maximum number of simultaneous connections: 8 Default address: IP: 192.168.1.243 MASK: 255.255.255.0 LINK DOOR: 192.168.1.1 - MODBUS-RTU: Transmission speed: 9600 bit / s.
  • Page 27 Interaction table The configuration parameters, set points, input signals, states and alarms are accessible as “retention registers” (word access 16 bits). BXX is the XXth bit of a word (XX is a value of 00 to 15). R indicates that the word is only readable, R / W in turn indicates that the word is both readable and writable.
  • Page 28 CONTROLS SPEED ADJUSTMENT POINT FOR VARIABLE SPEED VERSION: 0- 100 % ; FANS. FOR VAV UNIT: 101=TIMER ; 102=AUTO. FOR THREE SPEED 0-100%; 101 = SCHEDULE PROGRAM; VERSION: 102 = AUTO. 1-2-3 ; 4=TIMER ; 5=AUTO SPEED_SET_POINT FOR 3 SPEED UNITS: 1-2-3 4 = SCHEDULE PROGRAM;...
  • Page 29 DIGITAL INPUT: ESTADO ENTRADA DIGITAL (1=ACTIVO): B00: BYPASS BYPASS STATUS: 1 = OPEN; 0 = CLOSED B01: SUPPLY_SPEED_REM_CONT_ACTIVE ENABLING CONTROL INDEPENDENT IMPULSION FAN ACTIVE B02: EXHAUST_SPEED_REM_CONT_ ACTIVE ENABLING CONTROL INDEPENDENT FAN RETURN ACTIVE B03: DEHUM_ON ACTIVE DEHUMIDIFICATION B04: NOFROST_ACTIVE ANTIFREEZE STATE STATUS_FLAGS B05: EXT_DI_HUMIDITY STATE DIGITAL ENTRY: HUMIDITY...
  • Page 30 FOR UNITS COP = VALUE OF DP _SUPPLY B15: DPEXHAUST_FAIL PRESSURE SIDE IMPULSION FAN FOR UNITS COP = VALUE OF (Pa) DP _EXHAUST PRESSURE SIDE FAN RETURN FOR CAV UNITS = FLOW VALUE FLOW VALUE. FLOW_SUPPLY (m3/h) IMPULSION FOR CAV UNITS WITH DOUBLE PROBE = FLOW FLOW_EXHAUST (m3/h) VALUE SIDE VALUE.

  • Page 31: Installation

    SERVICE DATA 8502 BAUD RATE (100 bit/s) DEFAULT=96 8503 TIME OF DISCONNECTION BY DEFECT = 10 SEG. (sec.) TIMEOUT 65535 DISABLED THE CONNECTION IN CASE OF ABSENCE OF READING THE REGISTERS 8559 INSTALLER: 5678 ENTER PASSWORD FOR MODIFICATIONS MENU INSTALLER INSTALLATION The installation must be carried out by specialized personnel.

  • Page 32: Dimensions (Mm)

    DIMENSIONS (mm) CV072018-1...
  • Page 33 ASSEMBLY (mm) Insert two supports to the right and left of the panel Place the panel on the stand Push the support upwards and the panel down until the panel is completely fixed in the support CV072018-1...
