Grand ULTIMATE WIRELESS User Manual

CHAPTER 1
WELCOME TO GRAND ULTIMATE WIRELESS
1.1 INTRODUCTION
Thank you for purchasing the Grand ULTIMATE WIRELESS.GRAND ULTIMATE
WIRELESS is a VGA to TV converter with an integrated 2.4GHz Wireless
Transmitter & separate Receiver. Transmit the computer's video and audio to any
remote TV. It is ideal for Internet or DVD/VCD movie viewing, presentations,
baby/patient monitoring, burglary detection, theft prevention, or home/company
monitoring.
1.2 FEATURES
Plug and Display, no software required.
Supports four selectable channels and multiple receivers , transmits , ISM
Band from 2414~2468Mhz.
Simultaneous display on TV, Remote TV and VGA monitor.
Supports NTSC,NTSC-EIAJ，PAL-N, PAL, PAL-M, PAL-combination-N and
SECAM video system.
Supports CVBS, S-VIDEO video outputs by switch change (via wired
connections) .
True 24 bit, true color digitizer.
User controls: MENU, ZOOM, FINE TUNE，SAVE，VIDEO SOURCE，POWER
& Position adjustments.
Menu key supports Freeze , Size, Brightness, Contrast, Hue, Saturation,
Video Standard, Flicker , OSD color, Reset.
DIP Switch supports functions : CHANNEL 1~ CHANNEL 4
LED indicator PAL & POWER.
1
Adjustable H-SIZE and V-SIZE.
64 stages control : Brightness, Contrast, Hue, Saturation adjustment.
Fine Tune (Sharpness)
16 stages control :
Stereo Audio input from sound card or any audio device.
RF frequency: CH1=2414MHz, CH2=2432MHz, CH3=2450MHz,
CH4=2468MHz.
Demodulation Method: FM.
Frequency Generating: P.L.L..
Audio Response: 20Hz ~ 20kHz.
Video Output: 1Vpp/ 75 ohm composite Video.
Distance : Open area is 100 meters, indoor is 30 meters. (Actual range may
vary depending on environment)
1.3 MODE AND RESOLUTION TABLE
This converter supports the following VGA display modes:
720 640 800
x x x
Resolution
400 480 600
Vertical 70 60, 70, 56, 60,
Frequency 72, 75, 70, 72,
(Hz) 85, 100, 75, 85,
120 100
This converter supports the following MAC display modes:(for MAC G4,G4
Cubic,G3)
640 832
Resolution x
480 624
, Flicker adjustment.
1024 1152 1280 1280
x x x x
768 864 960 1024
60, 70, 60, 70, 60 60
72, 72, 75
75
800 1024 1152
x X X X
600 768 864
2
