Solarcore
SOLAR HOT WATER SYSTEMS

IMPORTANT INFORMATION

Australian/New Zealand Standards
The Stratco Solarcore
TM
be installed in accordance with the requirements of the
following Standards and Regulations:
AS/NZS 3500 National Plumbing & Drainage
AS 5601 Gas Installations
AS/NZS 3000 Electrical Installations
Building Codes of Australia
NZBC G12
Local Occupational Health & Safety regulations
Wind Regions Covered
Flat-Mount Kit:
Region A – N1, N2, N3
Region B – N1, N2, N3, N4
(Checked to AS/NZS 1170.2:2002 and AS4055-2006)
Tilt Mount:
Region A – N1, N2, N3 – Maximum tilt angle 38°
Region B – N1, N2, N3, N4 – Maximum tilt angle 30°
(Checked to AS/NZS 1170.2:2002)
NOTE: In Region B, Terrain Category 1 where roof mount tilt kits are attached to steel framing, the steel framing rafter
spacing is limited to maximum 1200mm centres.
Installer is responsible for the correct identification of Site Wind Classification. Wind Region and Classification can be
obtained from local council.
TM
hot water heating system must
INSTALLATION
GUIDE
