- Page 1 IP416 Qseven Carrier Board User’s Manual Version 1.0 (Oct. 2018)
- Page 2 IBASE Technology, Inc. (hereinafter referred to as “IBASE”). Disclaimer IBASE reserves the right to make changes and improvements to the products described in this document without prior notice.
-
Page 3: Compliance
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) IP416 User’s Manual... -
Page 4: Important Safety Information
Danger of explosion if the internal lithium-ion battery is replaced by an incorrect type. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions or recycle them at a local recycling facility or battery collection point. IP416 User’s Manual... -
Page 5: Warranty Policy
Software in use (such as OS and application software, including the version numbers) If repair service is required, you can download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact your distributor or sales representative. IP416 User’s Manual... -
Page 6: Table Of Contents
Chapter 2 Hardware Configuration .......... 7 Setting the Jumpers ................8 2.1.1 How to Set Jumpers ............... 8 Connector Locations on IP416 ............9 Jumpers Quick Reference ..............10 2.3.1 eDP / LVDS Selection (JP11) ..........10 2.3.2 COM3 & COM4 RS-232 Power Selection (JP4, JP3) ..11 2.3.3... -
Page 7: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: • Features • Specifications • Board Overview • Board Dimensions... -
Page 8: Introduction
Introduction IP416 is a Qseven carrier board coming with COM form factor. It receives major signals and interface from the Qseven module via the onboard 230-pin MXM connector. It offers expansion slots like PCIe (x1) and mini-PCIe, outputs video via DisplayPort and also has rich peripheral ports. -
Page 9: Specifications
Onboard Realtek ALC662 with 5.1 channel HD audio Audio Jacks 1 x Line-In, 1 x Line-Out, 1 x Mic-In Battery for 1 x Lithium battery button cell for RTC RTC/CMOS • 3 x PCIe (x1) slot Expansion • Slots 1 x full/half-size Mini-PCIe slot IP416 User’s Manual... - Page 10 Environment • Operation: -40 ~ 85°C (-40 ~ -185°F) Temperature Storage: -40 ~ 90 °C (-40 ~ 194°F) • Relative 10 ~ 90 % (non-condensing) Humidity All specifications are subject to change without prior notice. IP416 User’s Manual...
-
Page 11: Overview
DisplayPort COM2 RS-232 Port USB 3.0 Ports COM3 RS-232 Port GbE LAN Port Audio Jacks COM4 RS-232 Port (From top to bottom: Line-In, Line-Out, Mic-In) ＊The photos above are for reference only. Some minor components may differ. IP416 User’s Manual... -
Page 12: Dimensions
Dimensions IP416 User’s Manual... -
Page 13: Chapter 2 Hardware Configuration
Chapter 2 Hardware Configuration This section provides information on jumper settings and connectors on the IP416 in order to set up a workable system. • Jumper and connector locations • Jumper settings and information of connectors... -
Page 14: Setting The Jumpers
1 2 3 When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. IP416 User’s Manual... -
Page 15: Connector Locations On Ip416
Hardware Configuration Connector Locations on IP416 Board diagram of IP416 IP416 User’s Manual... -
Page 16: Jumpers Quick Reference
COM1 & COM2 RS-232 Power JP7 (COM1), JP8 (COM2) Selection AT/ATX Mode Selection JP10 LVDS Panel Power JP12 eDP Panel Power JP13 LVDS Backlight Level Selection JP15 2.3.1 eDP / LVDS Selection (JP11) Function Pin closed Illustration LVDS (default) IP416 User’s Manual... -
Page 17: Com3 & Com4 Rs-232 Power Selection (Jp4, Jp3)
Hardware Configuration 2.3.2 COM3 & COM4 RS-232 Power Selection (JP4, JP3) JP3 (COM4) JP4 (COM3) Function Pin closed Illustration +12V (default) IP416 User’s Manual... -
Page 18: Bios Booting Selection (Jp6)
2.3.3 BIOS Booting Selection (JP6) Function Pin closed Illustration From CPU module (default) From IP416 carrier board IP416 User’s Manual... -
Page 19: Com1 & Com2 Rs-232 Power Selection (Jp7, Jp8)
Hardware Configuration 2.3.4 COM1 & COM2 RS-232 Power Selection (JP7, JP8) JP8 (COM2) JP7 (COM1) Function Pin closed Illustration +12V (default) IP416 User’s Manual... -
Page 20: At/Atx Mode Selection (Jp10)
2.3.5 AT/ATX Mode Selection (JP10) Function Pin closed Illustration AT Mode (default) ATX Mode IP416 User’s Manual... -
Page 21: Lvds Panel Power (Jp12)
Hardware Configuration 2.3.6 LVDS Panel Power (JP12) Function Pin closed Illustration 3.3V (default) IP416 User’s Manual... -
Page 22: Edp Panel Power (Jp13)
2.3.7 eDP Panel Power (JP13) Function Pin closed Illustration 3.3V (default) IP416 User’s Manual... -
Page 23: Lvds Backlight Level Selection (Jp15)
Hardware Configuration 2.3.8 LVDS Backlight Level Selection (JP15) Function Pin closed Illustration 3.3V (default) IP416 User’s Manual... -
Page 24: Connectors Quick Reference
GbE LAN & USB 3.0 Ports SATA III Port CN7, CN8 Mini-PCIe Slot PCIe (x1) Slot PCIEX1, PCIEX2, PCIEX3 Reset Button Power Button Factory use only J4, J13 [1]: This UART port has RX, TX, RTS and CTS lines. IP416 User’s Manual... -
Page 25: Sata Hdd Power Connector (J1, J2)
Hardware Configuration 2.4.1 SATA HDD Power Connector (J1, J2) Signal Name Signal Name Ground Ground +12V 2.4.2 COM5 UART Port (J7) J7 has RX, TX, RTX and CTS lines. Signal Name Signal Name Ground IP416 User’s Manual... -
Page 26: System Function Connector (J8)
Orientation is not required when making a connection to this header. • Power LED (Pins 7 and 8) This connector connects to the system power LED on control panel. This LED will light when the system turns on. IP416 User’s Manual... -
Page 27: Lvds Panel Inverter Power Connector (J11)
Hardware Configuration 2.4.4 LVDS Panel Inverter Power Connector (J11) Signal Name Signal Name +12V Backlight Adjustment Backlight Enable Ground 2.4.5 DC-In 12V Power Connector (J14) Signal Name Signal Name Ground +12V Ground +12V IP416 User’s Manual... -
Page 28: Com1 & Com2 Rs-232 Ports (Cn4)
COM1 & COM2 RS-232 Ports (CN4) COM1: COM2: Signal Name Signal Name DCD, Data carrier detect DSR, Data set ready RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI, Ring indicator Ground IP416 User’s Manual... -
Page 29: Com3 & Com4 Rs-232 Ports (Cn3)
COM3 & COM4 RS-232 Ports (CN3) COM3: COM4: Signal Name Signal Name DCD, Data carrier detect DSR, Data set ready RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI, Ring indicator Ground IP416 User’s Manual... -
Page 30: Qseven Mxm Connector (Cn9)
GBE_MDI2- GBE_MDI3+ GBE_MDI2+ GBE_LINK100# GBE_LINK1000# GBE_MDI1- GBE_MDI0- GBE_MDI1+ GBE_MDI0+ Reserved GBE_ACT# GBE_CTREF SUS_S5# WAKE# SUS_S3# Reserved PWRBTN# Reserved Reserved Ground Ground Ground PWGIN BATLOW# RSTBTN# SATA0_TX+ SATA1_TX+ SATA0_TX- SATA1_TX- SATA_ACT# Ground SATA0_RX+ SATA1_RX+ SATA0_RX- SATA1_RX- Ground Ground IP416 User’s Manual... - Page 31 Ground U3_USB0_TX_N U3_USB0_RX_N U3_USB0_TX_P U3_USB0_RX_P USB_OC1# USB_OC1# U3_USB2_TX_N U3_USB2_RX_N U3_USB2_TX_P U3_USB2_RX_P USB_OC1# USB_OC0# U2_USB3_N U2_USB2_N U2_USB3_P U2_USB2_P Reserved Reserved U2_USB0_N U2_USB1_N U2_USB0_P U2_USB1_P Ground Ground eDP0_TX0+/LVDS_A0+ LVDS_B0+ eDP0_TX0-/LVDS_A0- LVDS_B0- eDP0_TX1+/LVDS_A1+ LVDS_B1+ eDP0_TX1-/LVDS_A1- LVDS_B1- eDP0_TX2+/LVDS_A2+ LVDS_B2+ eDP0_TX2-/LVDS_A2- LVDS_B2- IP416 User’s Manual...
- Page 32 Reserved DP_LANE2-/TMDS_LANE0- Reserved Ground Ground DP_LANE0+/TMDS_LANE2+ HDMI_CTRL_DAT DP_LANE0-/TMDS_LANE0- HDMI_CTRL_CLK DP_HDMI_HPD# DP_HPD# PCIE_REF_CLK+ PCIE_WAKE# PCIE_REF_CLK- PCIE_RST# Ground Ground PCIE3_TX+ PCIE3_RX+ PCIE3_TX- PCIE3_RX- Ground Ground PCIE2_TX+ PCIE2_RX+ PCIE2_TX- PCIE2_RX- UART0_TX UART0_RTS# PCIE1_TX+ PCIE1_RX+ PCIE1_TX- PCIE1_RX- UART0_RX UART0_CTS# PCIE0_TX+ PCIE0_RX+ IP416 User’s Manual...
- Page 33 Hardware Configuration Signal Name Signal Name PCIE0_TX- PCIE0_RX- Ground Ground LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_CLK LPC_FRAME# LPC_SERIRQ LPC_LDRQ# VCC_RTC SPKR FAN_TACHOIN FAN_PWMOUT Ground Ground SPI_MOSI SPI_CS0# SPI_MISO SPI_CS1# SPI_SCK VCC_5V_SB VCC_5V_SB IP416 User’s Manual...
-
Page 34: Lvds Connector (Cn10, Cn11)
2.4.9 LVDS Connector (CN10, CN11) CN11 (Channel A) CN10 (Channel B) Signal Name Signal Name TX0P TX0N Ground Ground TX1P TX1N Ground Ground TX2P TX2N Ground Ground CLKP CLKN Ground Ground TX3P TX3N IP416 User’s Manual... -
Page 35: Edp Connector (Cn12)
Connector (CN12) Signal Name Signal Name TX0N TX0P Ground AUXP AUXN Ground Ground +3.3V Ground Ground +12V Ground Ground TX3N Backlight Adjustment TX3P Backlight Enable Ground +12V TX2N +3.3V TX2P Ground Ground SMB_CLK TX1N SMB_DATA TX1P Ground IP416 User’s Manual... -
Page 36: Cpu Fan Power Connector (Cpu_Fan1)
2.4.11 CPU Fan Power Connector (CPU_FAN1) Signal Name Signal Name Ground Rotation detection +12V Control IP416 User’s Manual... -
Page 37: Appendix
Appendix This section provides the types of onboard connectors and the mating types for your reference. IP419 User’s Manual... -
Page 38: Onboard Connector Types
Onboard Connector Types Connector Compatible Mating Function Onboard Type Name Type for Reference SATA HDD Power J1, J2 Connector B4B-XH-A XHP-4 E-call E-call COM5 RS-232 Port 0151-2011009 0109-042-XX0 System Function E-call Dupont Connector 0126-01-203-080 2.54 mm-pitch (female) LVDS Panel Inverter Power Connector B4B-PH-K-S PHR-4...
