Shappell Wide House 6500 Setup & Takedown Instructions

Shappell Wide House 6500 Setup & Takedown Instructions

Advertisement

REPLACEMENT PARTS

MODEL WH6500
Part#
10538
10539
10540
10527
10528
10532
10536
10541
IA2
To Order Parts, give Part No., Description and Qty Needed.
SHAPPELL CORP., 3562 W. Jefferson Hwy., Grand Ledge, MI 48837
Toll Free (888) 571-1144

CONSUMER WARRANTY

SHAPPELL CORPORATION warrants its products against defects in material
and workmanship for (1) YEAR from date of purchase. We will provide FREE
repair or replacement, in whole or in part, at our option, for any product, found
in our opinion to be defective. If return is required, freight must be prepaid.
This warranty does not cover Freight Damage, Ordinary Wear and Tear, Abuse,
Misuse or Altered Product.
WINDOWS ARE NOT GUARANTEED AT TEMPERATURES BELOW
–15 DEGREES FAHRENHEIT.
For warranty claim, send letter indicating product and explanation of defect plus
dated proof of purchase to the SHAPPELL Corp., 3562 W. Jefferson Hwy,
Grand Ledge, MI 48837.
Description
Frame Rod Top (49-5/8")
Frame Rod Top Side (47")
Frame Rod Bottom Side (61")
Hub Plate
Plastic Hub Insert
Hub Body & Bolt & Strap
Replacement Window - Main 12" H x 18" W
Replacement Window - Door 12" H x 15" W
Ice Anchor (pair)
4-2-12
IMPORTANT SAFETY INFORMATION
WARNING: Keep all Heat & Flame Sources away from the Shelter's Fabric
Cover. The Fabric Cover is Fire Retardant, it is not Fire Proof. The use of any
heat source can be extremely dangerous, both for Fire Hazard and Carbon
Monoxide Emissions. The Shappell Corporation does not endorse the use of any
Heater. It is the user's responsibility to follow the Instructions and Warnings
provided by the Heater Manufacturer for the safe use of a particular Heater.
CARBON MONOXIDE POISONING HAZARD:
C O
ventilated if using an oxygen consuming heat source. DO NOT PACK SNOW
AROUND SHELTER or in any way prevent fresh air from entering shelter.
Failure to Ventilate Shelter could create a Serious Health Hazard or Death.
Window can not be made to withstand temperatures below –15
MAINTENANCE: After each use, set up shelter until fabric is completely dry.
Never leave shelter folded closed with a wet cover.
NOTICE:
It is normal for fabric to have some pinholes. This does not affect
water repellency.
READ SETUP & TAKEDOWN INSTRUCTIONS BEFORE USING SHELTER
TM
This shelter must be
o
F. (see warranty)
