Summary of Contents for Peavey PROCOMM
- Page 1 PROCOMM® 2.4 GHz Digital Wireless Transmitters Operating Manual www.peavey.com...
- Page 2 FCC/ICES Compliancy Statement FCCID: I4S-PCXDBP FCCID: I4S-PCXDHT This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS Standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, that may cause undesired operation. Le présent appareil est conforme aux CNR d’lndustrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) I’appareil ne doit pas produire de brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Caution: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the user’s authority to use the equipment. Prudence: Les modifications apportées à l'équipement non approuvés par Peavey Electronics Corp. peuvent annuler le droit de l'utilisateur à utiliser l'équipement. Note – This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures. Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is ...
- Page 3 FCC Radiation Exposure Statement(for Model number: PCX-D HT) This equipment complies with FCC &IC RSS-102 RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 1.5 centimeters between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
- Page 4 PRO COMM® 2.4 GHz Digital Wireless System PRO COMM Rechargeable Handheld Transmitter PRO COMM Rechargeable Bodypack Transmitter WARNING: Contains lithium ion batteries. Lithium ion batteries contain Perchlorate-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate WARNING: Lithium Ion batteries may be a re hazard. Do not expose to open ame or excessive heat.
-
Page 5: Controls And Indicators
Controls and Indicators 1. Capsule Module: The anti-roll grille protects detachable microphone capsule and the internal foam prevents breathing, wind and POP noises. 2. Fixed Ring 3. Battery Compartment: Accommodates one 18500 rechargeable battery. 4. Housing: Protects transmitter PCB, battery compartment and battery. 5. - Page 6 Operating instructions for insertion& removing battery Remove grill in counter clock direction. Press and hold both sides of microphone capsule module and remove gently. Ascertain the battery is inserted according to its correct polarity. A click is heard once correctly inserted and grill can be closed properly.
- Page 7 Operating Instructions Power On & Off a. Power On: Push the ON/OFF switch to the “ON” location, the battery indicators will light. b. Power Off: Push the ON/OFF switch back, the battery indicators will go out. Battery Status Display a. Red LED indicator is lit when battery is too low. Please recharge or insert a new recharged battery. The microphone will be shut down automatically if the battery keeps low status 100% (green indicator)(red indicator)
- Page 8 and compensate by turning up the amplifier volume to increase the sound level as this can easily cause echo or feedback. In contrast, performers with a ‘’louder’’ sound level should not hold the microphone too close as this can easily result in distortion by causing the amplifier system to be overloaded. Furthermore, a large-diaphragm directional microphone has a very distinct proximity effect.
- Page 9 12. Battery Charging Contact: Align contacts during charging. Metal objects contact is forbidden. It is forbidden to contact metal objects. (Figure 1) (Positive Wear) (Opposite Wear) Audio Input Operating Instructions Insert the lavalier, headset microphone or instrument cable into the audio input connector before power ON the transmitter.
- Page 10 AF Input Connections (1) 2-Wire Electret condenser microphone Capsule 3-Wire Electret condenser microphone Capsule (3) Dynamic Microphone (4) Electric Guitar (5) Line-in (Impedance 8KΩ ATT. 10dB Battery Removal and Installation Pushing down both snap locks on the sides to open battery compartment cover. Take out the one battery. (Figure 3) Insert one charged 18500 rechargeable battery into the battery compartment according to the correct polarity (- and +) as shown in (Figure 4) .
- Page 11 18500 Charging PRO COMM Dual-Slot Battery Charger Use the Battery Charger to charge up to two rechargeable 18500 Li-ion batteries for rechargeable Peavey® handheld or bodypack transmitter. Charging Batteries: Insert the batteries with the correct positive (+) & negative (-) polarity and plug the charger into a power outlet, as shown here.
- Page 12 The batteries may be faulty or damaged and should be replaced. Rechargeable 18500 Li-ion Battery (Transformer is shown here for reference only) Notes Refer to actual product in the event of product description discrepancy. Frequency range and maximum deviation comply with the regulations of different countries. WARNING FOR OUTDOOR USE: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
