Matchmaster 50MM-WN8CH2TB4B Quick Manual

Note: The default WNVR username and
password are, admin and, the password
is blank with no characters, if the user has
updated this detail please use the newly
added username and password.
CMS remote playback
Select "playback" on the main interface,
double click the device list or point "begin
searching" its default is to show all recording
fi les of that day.
The CMS also supports local playback and
remote playback support base in "fi le type"/
date to search, and the fi le will be show on
the lower window of the application.
AU Technical Support 1800-AERIAL
NZ Technical Support 0800-AERIAL
HDD upgrade
To upgrade the Wireless Network Video
Recorder (WNVR) from its existing 2TB hard
drive to the larger 4TB hard drive please
follow the steps below and also reference
the diagram below.
1. Remove the screws as indicated in
diagram above and remove the cover
2. Turn the WNVR upside down, note
the screws that support the drive and
remove them so that the HDD is free
from the WNVR.
3. Remove the cables connected to the
existing hard drive and connect to the
new hard drive, making sure to be careful
with the connectors
4. Align the drive to the existing mounting
holes and secure using the screws
removed from the original drive
5. Place the WNVR cover back and use
the previously removed screws to
reassemble the WNVR. The unit is now
upgraded with the larger HDD.
237425 www.matchmaster.com.au
237425
www.matchmaster.co.nz
50MM-WN8CH2TB4B / 50MM-WN8CH2TB4D
HD Security Camera Kit
QUICK GUIDE
Live remote monitoring through Smartphone and PCs
!
IMPORTANT: Remember to change your password from factory default.
!
