Summary of Contents for FREE RC HOBBY F8E-BX
- Page 1 1:8 Scale 4WD Electric Belt Driving Buggy Manual 福瑞达模型有限公司 DONGGUAN FREERCHOBBY CO.,LTD TEL/FAX :+86-769-82927540 www.freerchobby.com...
-
Page 2: Table Of Contents
Contents Preface………………………………………………………..3 Safety Guidelines……………………………………………...3 Li-Po Battery Charging………………………………………..4 Receiver Connection………………………………………..4 Operation Steps………………………………………………..5 Recommended Maintenance Tools………………………..7 F8E-BX Installing view……………………………………….7-30 F8E-BX Exploded View……………………………………..31 Spare Parts List……………………………………………..32... -
Page 3: Preface
Preface Thanks for purchasing F8E-BX (1:8 scale 4WD Belt Driving Buggy) from FREE RC HOBBY . This model was designed by experienced design team from FRC hobby, and we tested repeatedly and improved. Believe that FRC products will bring more fun for you. Enjoy it! Attention：... -
Page 4: Li-Po Battery Charging
Li-Po Battery Charging Charging Procedure Connecting the power supply, the light of the charger will indicate ● red and green alternately. Connecting battery and charger,the light of the charger will indicate red. ● When the three lights indicate green,charging finished. ●... -
Page 5: Operation Steps
Driving Procedure I、Driving Procedure 1. Open the cover of transmitter. 2. Insert the battery (pay attention to negative and positive). 3. Close the cover of transmitter. Attention: It is suggested to use AA1.5V Alkaline battery in order to achieve a better performance for transmitter. Please don’t mix the new and old battery. - Page 6 Driving Procedure II、Finishing Driving 1. Turn off the ESC switch, and then disconnect the power. 2. Turn off the transmitter. 3. Take off the battery. III、Transmitter adjustment Turn on the transmitter first, connect the output plug of battery and input plug of ESC, then turn on the ESC switch (please pay more attention to positive and negative).
-
Page 7: Recommended Maintenance Tools
Recommended Maintenance Tools 1.5mm Hex Screwdriver 2.0mm Hex Screwdriver 2.5mm Hex Screwdriver Diagonal Cutting Plier Needle-nose Plier Reamer Bend Scissors Knife Differential Build X 2 Add grease M3 X 16 Countersunk Phillips Self-tapping Screws Add grease Add grease... - Page 8 Front Gear Box Build 15T Belt gear installing M4 X 4 Set Screw Set Screw Should Add thread lock be tighten on the flat place M3 X 16 Countersunk Phillips Self-tapping Screws M3 X 28 Countersunk Phillips Self-tapping Screws Front Shaft Front Gear Box Assembly M4 X 14 Countersunk Phillips Self-tapping Screws...
- Page 9 Front Shock Tower Assembly M3 X 12 Button Phillips Self- M3 X 20 Button Phillips Self- M3 X 8 Countersunk Phillips tapping Screws tapping Screws Self-tapping Screws Front lower Arm/Front Sway Bar Assembly Set screw and Sway-bar installing The set screw is only used for sway-bar adjustment, not againest to sway-bar movement.
- Page 10 Steering Knuckle Assembly Front lower arm C-Mounting M4 X 18 Button Phillips CVD Drive shaft Out Drive bushing Bushing Machine Screws Front Upper Link Assembly M3 X 16 Button Phillips Machine Screws...
- Page 11 Servo Assembly M3 X 10 Button Phillips Machine Screws Steering Set Assembly M3 X 3 Set Screws Add thread lock M3 X 6 Button Phillips Add grease Machine Screws Add grease Add grease Add grease Add grease M3 X 12 Button Phillips Machine Screws Add grease M3 X 16 Button Phillips...
- Page 12 Front Upper Plate Assembly M3 X 28 Button Phillips Machine Screws M4 X 10 Button Phillips Machine Screws Add thread lock Add thread lock Servo Wires Front Belt Gear Assembly M4 X 4 Set Screw Set screw should be tighten on the flat place. M3 X 20 Button Phillips Self-tapping Screw Servo Wires...
- Page 13 Front Shock Build Front Shock Spring No Bubble Front Shock Shaft Front Shock Assembly M3 Step Lock Nut M3 X 20 Button Phillips Self- tapping Screws M3 X 26 Button Phillips Machine Screws...
- Page 14 Rear Gear Box Build M4 X 4 Set Screw 15T Gear Installing Add thread lock Set screw should be tighten on the flat place M3 X 16 Countersunk Phillips Self-tapping Screws M3 X 28 Countersunk Phillips Self-tapping Screws Front Shaft Rear Gear Box Assembly M4 X 14 Countersunk Phillips Self-tapping Screws...
- Page 15 Rear Shock Tower Aseembly M3 X 20 Countersunk Phillips M3 X 12 Countersunk Phillips Self-tapping Screws Self-tapping Screws Rear Lower Arm /Rear Sway Bar Assembly Add grease Rear Suspension Arm M4 X 20 Countersunk M3 X 20 Button Phillips Suspension Arm M3 X 3 Set Screw M4 X 10 Set Screw Sway Bar Upper Ball Sway Bar Mounting Pin Bushing(Rear)
- Page 16 Rear Hub Carrier Build Rear Driver Shaft Rear lower Suspension Arm Pin B Rear Axle Rear Upper Turnbuckle Assembly Add grease M3 X 16 Button Phillips M3 X 22 Button Phillips M3 Lock Nut Rear Upper Turnbuckle Machine Screws Machine Screws...
- Page 17 Rear Shock Build Rear Shock Spring No Bubbles Rear Shock Shaft Rear Shock Assembly M3 Step Lock Nut M3 X 20 Button Phillips Self-tapping Screws M3 X 26 Button Phillips Machine Screws...
- Page 18 Motor Mount Assembly M3 X 26 Button Phillips Machine Screws Add thread lock M3 X 16 Button Phillips Machine Screws This part is upgrade part M3 X 8 Countersunk Phillips Self-tapping Screws Add thread Add thread lock Add thread lock lock Front Suspension Assembly M3 Lock Nut...
- Page 19 Rear Suspension Assembly M3 X 22 Button Phillips M3 X 20 Button Phillips M3 Lock Nut Machine Screws Machine Screws Rear Belt Box Assembly Add thread lock M3 X 12 Countersunk Phillips Machine Screws Add thread lock...
- Page 20 Middle Belt Assembly Can Adjust the belt M3 X 22 Button M3 Lock Nut Phillips Machine Screws Can Adjust the belt...
- Page 21 65T Main Gear Assembly Main Gear M4 Lock nut Spring Front Belt Box Assembly M3 X 8 Countersunk Phillips Self-tapping Screws...
- Page 22 Middle Belt Box Assembly M3 X 8 Countersunk Phillips Self-tapping Screws Motor Assembly Set Screw should be tighten on the falt place M3 X 12 Button Phillips Machine Screws Motor Mounting: 1.it can install 15T or 17 Add thread lock T pinion gear,but please use the appropriate mounting hole for the...
- Page 23 Rear Belt Box Assembly M3 X 20 Button Phillips M3 X 8 Countersunk Phillips Self-tapping Screws Self-tapping Screws Receiver Box Assembly M3 X 8 Countersunk Phillips Self-tapping Screws...
- Page 24 ESC Assembly Double side tape Double side tape Middle Brace Assembly Please use AB glue Please use AB glue Add thread lock M3 X 28 Button Phillips M3 X 26 Button Phillips Self-tapping Screws Self-tapping Screws...
- Page 25 Battery Assembly Battery Tray Assembly...
- Page 26 Battery Tray Button Assembly M3 X 12 Button Phillips Self-tapping Screws...
- Page 27 Fan Brace Assembly T parts are option parts M3 X 10 Button Phillips Self-tapping Screws M3 X 16 Button Phillips Machine Screws...
- Page 28 Tail Wing Build M3 X 12 Button Phillips M3 X 16 Button Phillips Self-tapping Screws Self-tapping Screws Tail Wing Assembly M3 X 22 Button Phillips M3 X 16 Button Phillips M3 X 3 Set screw M3 lock nut Machine Screws Self-tapping Screws...
- Page 29 Tire Build Put the insert into the tire Put the tire on the rim. Drop the CA glue into the gap between the tire and rim.
- Page 30 Tire Assembly Bodyshell Assembly...
-
Page 31: F8E-Bx Exploded View
Spare Part List... -
Page 32: Spare Parts List
Spare Part List... - Page 33 Spare Part List...
- Page 34 Spare Part List Ball Head of Shock Ends...
- Page 35 Spare Part List Glass Fiber...
- Page 36 Spare Part List Ball Head of Shock Ends Small Belt...
- Page 37 F8E-BX Exploded View...
- Page 38 Thank you 福瑞达模型有限公司 DONGGUAN FREERCHOBBY CO.,LTD TEL/FAX :+86-769-82927540 www.freerchobby.com...
