Flame RD 6009 Instruction Sheet

RD 6009 Roof Dryer
Moving parts can cause injury. Keep hands, feet and clothing away from air
intake and all other moving parts on machine and engine. Never put hands or
feet in air exhaust outlet while machine is running.
Blower housing becomes very hot. Keep away from housing when burner is on.
Allow engine to run until exhaust air is cool after shutting off gas. Always have a
fire extinguisher nearby.
Do Not attach hoisting devices near valves or hoses.
Always shut off engine and close valve on LP-Gas cylinder before refueling.
Never operate torch without blower.
Never lift machine with LP-Gas cylinder attached.
Never lift LP-Gas cylinder by valve.
Replace immediately any components that become worn, damaged or
inoperative.
Assembly Instructions
Upon opening carton, examine RD 6009 Roof
Dryer closely for damage. Report any damage to
freight carrier.
See parts list enclosed prior to assembling Roof Dryer
1. Install front wheel bracket onto bolts and tighten
lock nuts. Slide bushing in wheel and attach wheel
to bracket with 5/16 bolt, flat washers and lock nut.
2. Bolt handle brace to front cover.
3. Install upper handle with hose assembly attached
onto lower right and left handles. Leave nuts loose.
4. Place handle brace on inside of handle and place
bolts through holes. Place lock nuts on bolts.
5. Tighten all bolts and nuts.
6. Place torch into holder and tighten set screw.
7. Tighten supply hose onto torch fitting.
(No Pipe Compound Needed)
Flame Engineering, Inc. • West Hwy 4 • P.O. Box 577 • LaCrosse, KS 67548
CAUTION
800-255-2469 • 785-222-2873 • Fax 785-222-3619
Adjustable Pilot
Valve
Squeeze Valve
Lever
3
7
Instruction
Sheet
NOTICE
Any modification
to this machine
voids all warranty
and liability.
4
6
1
See Reverse Side
For Operating Instructions
2
