Summary of Contents for Sensor Systems DPSKO Series
-
Page 1: User Manual
USER MANUAL DPSKO-xx Dual axis planarity sensor with relay or open collector output - 1 -... - Page 2 BXX-11 02/2008 Index 1 – Working principle……………………................pg.3 2 – Technical features……....................pg.4 3 – Safety…………......................pg.5 4 – Electrical connections....................pg.6 5 – Calibration and setting using RS-232 port .............. pg.8 6 – Mounting ........................pg.14 7 – Disposal........................pg.15 8 –...
-
Page 3: Working Principle
1 – Working principle DPSK micro controlled planarity indicator is a digital device capable of: 1. operating as a common planarity indicator, living as an output axis X and Y planarity, separately over a 360° degrees range; 2. giving as an output X and Y planarity for two half axis each, allowing DPSK to be used for auto-levelling or other (optional) functions. -
Page 4: Technical Features
2 – Technical features 2.1 - Relay / open collector planarity control output Supply voltage = +9 ... +30 Vdc Max output current (planarity control, relay) = 1.0 A @ 50 ° C Max voltage output (planarity control, relay) = + 24V dc Max output current (planarity control, axis half-axis, transistor) = 1.0 A @ 50 °... - Page 5 3- Safety 3.1 Protections Built-in device protection: A) Supply • reverse polarity; • overvoltage. B) Planarity output (relay): • short-circuit; • overvoltage. C) Axis/half-axis output (transistor): • short-circuit; • overvoltage. D) Axis/half-axis output (relay): • short-circuit 3.2 Conformity DPSK conforms to the following EMC standards: EN 61000 –...
-
Page 6: Electrical Connections
4- Electrical connections 4.1 Preparation Cable choice To avoid any dysfunction due to incorrect wiring, device shall be cabled granting optimal electric insulation of all parts accessible by unspecialised operators ( insulating resistance > 1G x cm). Mounting must avoid improper cable bending, traction, twisting pressing or squeezing during machine operation. - Page 7 4.2 Supply Cable colour Description Function WHITE Positive supply + 7 ... + 30 Vdc YELLOW Negative supply 4.3 Planarity output (Relay) Cable colour Description Function BLUE Common relay GREEN NC Relay Normal closed GREY NO Relay Normal open 4.4 Serial RS232 communication Cable colour Description Function...
- Page 8 5- Calibration and setting using RS-232 connection 5.1 Zero Device zero is factory-calibrated. An after-mounting zeroing is preferable in most of the cases. Zero can be achieved in two ways: 5.1.1 – using the following RS-232 specific command (via Hyperterminal-like program): ZERO <...
- Page 9 5.3 Switching delay interval Switching delay interval are easily selectable using RS-232 commands between 0.1 and 25.5 seconds. Delays are selectable using RWAIT command (delay before intervention: waits X seconds to activate alarm) and FWAIT (delay after intervention: waits X seconds to deactivate alarm). RWAIT=22 <...
- Page 10 And the desired value and pres <ENTER> key RWAIT=12 <Enter> Sets RWAIT to 1.2 seconds If the user gives a parameter an out-of-range value or a wrong name “Syntax error” will be printed on the screen. In such a case the user shall press <ENTER>. 5.5 RS-232 parameters table Parameters for RELAY OUTPUT Parameter...
- Page 11 Example of the configuration using Windows HyperTerminal: 1) COM port configuration After power-on DPSK sends through RS-232 the following info: - 11 -...
- Page 12 Command “ABC” has not been recognized by the device so DPSK sends through RS-232 the following info “Syntax error” Command “MDEGX=20” to set the switching angle for X axis at 2.0° . To set switching angle for X axis using MDEGX command please type desired angle value multiplied by ten (to allow definition of decimal values of the angle): MDEGX=20 <...
- Page 13 Command “MDEGX:” to read the switching angle for X axis already set. To read switching angle for X axis using MDEGX command please type desired angle value multiplied by ten (to allow definition of decimal values of the angle): MDEGX: - 13 -...
- Page 14 6- Mounting - 14 -...
- Page 15 7- Dismission Dismissing of DPSK shall be performed in according regional/national rules. 8- Precautionary measures, checks and maintenance 8.1 Precautions 8.1.1 – Power-on must be performed using battery; 8.1.2 – Supply must be cut-off before any intervention on cables, wiring or before any changes in mounting position;...
- Page 16 Extraordinary maintenance comprises every maintenance which is not listed in the installation guidelines or ordinary maintenance paragraph. Extraordinary maintenance shall be carried out by trained professionals. Please contact directly Sensor Systems or the nearest of its authorized resellers. - 16 -...
