ALTUS - SureTrack User Setup
If you already have a SureTrack account, follow these
steps to setup and register your ALTUS account:
From a PC or mobile device:
1. Connect the thermal imager to a Wi-Fi network, see
Thermal Imager Elite Wi-Fi Connection on page
2. Write down the Serial Number, PIN and Code that are
displayed when the device connects to the Wi-Fi network,
or leave the screen displayed. These codes can also be
found in the Settings menu, see
Screen on page 3.
3. Using a mobile device or PC, visit
https://ALTUSDRIVE.com
screen).
4. Log in using your SureTrack Username and Password.
5. Open Profile Manager (additional login may be required).
6. From the Device Management tab, select Add Device.
See
Device Management on page 9
screen.
7. Enter your Serial Number, PIN, Code, and Device Name.
8. Log out of "Profile Manager", then select the ALTUS Home
Page browser tab to get started.
9. Turn the thermal imager off, and then on.
10. See for operation instructions.
Using ALTUS
Your thermal imager is now registered to your ALTUS online
account. When connected to Wi-Fi, your images will be
automatically sent to the online account from the device.
ALTUS Setup Information Screen
From the imager, selecting ALTUS Setup
Settings menu allows you to view the diagnostic tool serial
number, PIN and Code needed to register on
ALTUSDRIVE.com.
1. Press the Menu button.
2. Select the Settings icon from the toolbar, then select
ALTUS Setup from the menu.
ALTUS Setup displays the following:
Device Serial Number
•
PIN
•
Code
•
ALTUSDRIVE.com QR code
•
This information is used when registering on
ALTUSDRIVE.com.
1.
ALTUS Setup Information
and select Login (upper right
for a description of this
(Figure 4) from the
i
Serial Number:
PIN:
Code:
Go to ALTUSDRIVE.com
Note: The PIN and Code numbers will change each time you
view the ALTUS Setup screens
is normal, any displayed set of PIN and Code numbers may
be used to register on ALTUSDRIVE.com.
Using ALTUS
Note: ALTUSDRIVE.com navigation and menu options will
vary by device and/or operating system (PC, mobile, etc).
Some menu selections may be grayed out or not shown,
indicating the option is not supported on your device/system.
Some menu options shown in these instructions may be not be
available on your device.
To use ALTUS:
An ALTUS account is required, see
•
page 2.
The thermal imager must be connected to a Wi-Fi network,
•
see
Thermal Imager Elite Wi-Fi Connection on page
Logging In to ALTUS
1. Using your mobile device or PC visit ALTUSDRIVE.com.
2. Select the Login icon
3
123HTM123456
123456
B12A456C
Figure 4
(Figure 4 Figure
and
ALTUS Registration on
(Figure 5).
Figure 5
5). This
1.
