WiMAX
RNU4000BS Base Station
User Manual
Doc: Runcom RNU4000BS User Manual RN-PMG-041112 V-3.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WiMAX RNU4000BS and is the answer not in the manual?

Questions and answers

Summary of Contents for Runcom Technologies Ltd. WiMAX RNU4000BS

  • Page 1 WiMAX RNU4000BS Base Station User Manual Doc: Runcom RNU4000BS User Manual RN-PMG-041112 V-3.4...
  • Page 2 Preface Material RNU4000BS User Manual About this Guide This User Manual describes the procedures for commissioning, mounting, installing and managing the RNU4000BS Base Station. Notice This document contains proprietary and confidential material of Runcom Ltd. Any unauthorized reproduction, use or disclosure of this material, or any part thereof, is strictly prohibited. This document is solely for the use of Runcom Ltd.
  • Page 3 RNU4000BS User Manual Preface Material Install the equipment and the grounded DC supply circuits in adjacent cabinets. • Protect the DC power source with an adjacent circuit breaker. • The equipment must be properly grounded before attempting to operate or perform any •...

  • Page 5: Table Of Contents

    RNU4000BS User Manual Table of Contents Table of Contents Introducing the RNU4000BS BS ..................1 1.1 Coverage Configurations ......................3 1.2 RNU4000BS Interfaces and Accessories..................5 1.2.1 GPS, Power and Communication Interfaces ................5 1.2.2 BS RF Antenna Interfaces ....................7 1.3 Supported Antennas........................7 1.3.1 RF Antennas ........................7 1.3.1.1 Internal Antennas....................7 1.3.1.2 External Antenna....................7...
  • Page 6 Table of Contents RNU4000BS User Manual 4.4.4 Multi-sector Daisy-chained GPS Antennas................42 4.4.4.1 Hardware Interconnections ...................42 4.4.4.2 Configuration Parameters..................42 4.5 End-to-End Traffic Test ......................42 4.5.1 Performing a PING Test ....................43 Field Test Performance Evaluation.................44 5.1 Field Test Overview........................44 5.2 Field Test Setup .........................45 5.3 Field Test Procedure ........................47 Technical Specifications ....................49 6.1 RNU4000BS BS Specifications .....................49...

  • Page 7: Introducing The Rnu4000Bs Bs

    RNU4000BS Base Station User Manual Introducing the RNU4000BS BS Introducing the RNU4000BS BS Runcom's RNU4000BS fully integrated outdoor WiMAX BS provides flexible, cost-effective WiMAX network deployment solutions where increased capacity and coverage is required. ‘All-in-one’ architecture combined with simple, single-handed installation and fast rollout make these BSs an ideal solution for operators that want to get in on the ground floor of WiMAX deployment at significant CAPEX reductions and maximum return on their network deployment.
  • Page 8 Introducing the RNU4000BS BS RNU4000BS Base Station User Manual Features All-in-one integrated packaging of RF and Baseband components. • Full compliance with IEEE802.16e-2005 according to the WiMAX Forum profiles. • Frequency Bands (model dependent): 705–745MHz, 2.3-2.7GHz, 3.3-3.8GHz (CBP capability for •...

  • Page 9: Coverage Configurations

    RNU4000BS Base Station User Manual Introducing the RNU4000BS BS 1.1 Coverage Configurations RNU4000BS supports either two or four RF channels and can provide coverage for either one, two or four sectors depending on the sector density (throughput capacity) and radio performance requirements (note that internal antenna can be used for single sector coverage only): Single-Sector solution of 4x4 –...
  • Page 10 Introducing the RNU4000BS BS RNU4000BS Base Station User Manual another, to perform Single Sector Coverage Figure 1 Runcom Technologies Ltd.

  • Page 11: Rnu4000Bs Interfaces And Accessories

    RNU4000BS Base Station User Manual Introducing the RNU4000BS BS The following figure illustrates dual-sector coverage of two sites by a single RNU4000BS • unit. Dual Sector Coverage Figure 2 1.2 RNU4000BS Interfaces and Accessories The interfaces of the RNU4000BS BS are distributed over two panels. Each of these panels is referred to according to the corresponding interfaces.
  • Page 12 Introducing the RNU4000BS BS RNU4000BS Base Station User Manual Connector Description Connects to an external (optional) GPS antenna. The GPS antenna is ordered separately. Connector Type: ITT CANNON APD DIN 72585 ETH1 Primary Fast Ethernet connector. Used for initial setup (and standalone tests), and for connection to the backhaul network (in normal installations).

  • Page 13: Bs Rf Antenna Interfaces

    RNU4000BS Base Station User Manual Introducing the RNU4000BS BS 1.2.2 BS RF Antenna Interfaces RNU4000BS supports either four external or four internal antennas. The unit below • shows a model supporting four external antennas. All antennas (internal and external) are 1W each •...

  • Page 14: Optional Accessories

    Introducing the RNU4000BS BS RNU4000BS Base Station User Manual 1.4 Optional Accessories The following accessories are not provided with the basic kit, and can be ordered as an option. Element Description Power Supply 110-220v AC/DC converter for 48VDC power supply RF Antenna External directional antenna with pole mounting kit Runcom Technologies Ltd.

  • Page 15: Web Gui Description

    RNU4000BS Base Station User Manual WEB GUI description WEB GUI description Follow by the next steps for BS WEB GUI menu access: Open Internet Explorer for access to BS WEB GUI using the BS IP address path • BS WEB GUI access path Figure 3 Use the BS WEB GUI credential (user name and password) to obtain the BS WEB GUI •...

  • Page 16: Web Gui Menu Description

    WEB GUI description RNU4000BS Base Station User Manual 2.1 WEB GUI Menu description The table below describes the WEB GUI Menu options and their functionalities Menu Section Description General Information General Provides BS related HW/SW info IP Status Provides BS ETH interface IP addresses status General General Provides RF parameters and MCS settings...
  • Page 17 RNU4000BS Base Station User Manual WEB GUI description General Information –working screen Figure 5 Runcom Technologies Ltd.
  • Page 18 WEB GUI description RNU4000BS Base Station User Manual Monitoring screen – The figures below represent the “Monitoring” working screens and provides the next info as described in the table below: Menu Section Description Monitoring Status Synchronization Provides the BS synchronization operational and configuration status: 1PPS lock status–...
  • Page 19 RNU4000BS Base Station User Manual WEB GUI description Menu Section Description Antenna Status Provides BS antenna configuration status: TX ON/OFF – indicates the BS configuration • status of each one transmitter independent transmitters) RX ON/OFF – indicates the BS configuration •...
  • Page 20 WEB GUI description RNU4000BS Base Station User Manual Monitoring Status– working screen Figure 6 Monitoring WiMAX– working screen Figure 7 Runcom Technologies Ltd.
  • Page 21 RNU4000BS Base Station User Manual WEB GUI description Monitoring CPE info /CPE list – working screen Figure 8 Monitoring CPE info / link status – working screen Figure 9 Runcom Technologies Ltd.
  • Page 22 WEB GUI description RNU4000BS Base Station User Manual Configuration screen – The figures below represent the “Configuration” working screens and provides the next info as described in the table below: Menu Section Description General General Provides RF parameters and MCS settings •...
  • Page 23 RNU4000BS Base Station User Manual WEB GUI description Figure 10 Configuration - General screen Figure 11 Configuration – HO neighbors BS definition screen Runcom Technologies Ltd.
  • Page 24 WEB GUI description RNU4000BS Base Station User Manual Figure 12 Configuration - IP Configuration screen Figure 13 Configuration – Stand Alone screen Runcom Technologies Ltd.
  • Page 25 RNU4000BS Base Station User Manual WEB GUI description Figure 14 Configuration – Multicast user definition screen Figure 15 Configuration – CPE network connection screen Runcom Technologies Ltd.
  • Page 26 WEB GUI description RNU4000BS Base Station User Manual Figure 16 Configuration – Service flow profile definition screen Configuration – CPE to Service flow profile setting screen Figure 17 Runcom Technologies Ltd.
  • Page 27 RNU4000BS Base Station User Manual WEB GUI description Maintenance screen – The figures below represent the “Maintenance” working screens and provides the next info as described in the table below: Menu Section Description Upgrade SW Upgrade Allows BS SW upgrade including all SW components: Maintenance SW bin –...
  • Page 28 WEB GUI description RNU4000BS Base Station User Manual Figure 19 Maintenance Banks screen Figure 20 Maintenance Default screen Runcom Technologies Ltd.
  • Page 29 RNU4000BS Base Station User Manual WEB GUI description Figure 21 Maintenance – Configuration profile file screen Runcom Technologies Ltd.

  • Page 30: Commissioning Procedure

    Commissioning Procedure RNU4000BS Base Station User Manual Commissioning Procedure 3.1 Overview Before mounting the RNU4000BS BS on a pole or wall, power should be connected to the BS and the basic parameters configured with the basic parameters using the BS WEB GUI. ATTENTION!!! BE SURE THE RF ANTENNAS ARE CONNECTED OR THE RF PORTS ARE TERMINATED BEFORE CONNECTING POWER TO THE UNIT.

  • Page 31: Connect Bs To Power And Computer

    RNU4000BS Base Station User Manual Commissioning Procedure 3.2 Connect BS to Power and Computer ATTENTION!!! BE SURE THE RF ANTENNAS ARE CONNECTED OR THE RF PORTS ARE TERMINATED BEFORE CONNECTING POWER TO THE UNIT. To commission the BS unit two setup connections are required: Power - Use the provided (BS) power cable to connect the BS VDC Power connector to •...
  • Page 32 Commissioning Procedure RNU4000BS Base Station User Manual Local Area Connections Properties dialog appears with the General tab displayed by default. 3. In the Items list, select “Internet Protocol (TCP*IP)” and click the Properties button. The “Internet Protocol (TCP/IP) Properties” dialog appears. Runcom Technologies Ltd.
  • Page 33 RNU4000BS Base Station User Manual Commissioning Procedure 4. In the IP Address display area: In the IP address field assign an IP address other than the BS IP address (Default BS • IP Address: 192.168.0.20). In the Subnet mask – set the subnet to the same subnet as the BS (Default BS •...

  • Page 34: Disable Firewall

    Commissioning Procedure RNU4000BS Base Station User Manual 3.2.1.2 Disable Firewall To disable firewall follow the next steps: 1. In the Local Area Connection dialog, click the Advanced tab. The following dialog appears. Advanced tab Settings button Windows Firewall 2. In the display area click the Settings button.

  • Page 35: Installing The Rnu4000Bs Bs

    RNU4000BS Base Station User Manual Installing the RNU4000BS BS Installing the RNU4000BS BS After commissioning the RNU4000BS BS, the unit is ready for installation. The procedure consists of the following steps: Choosing the installation location and mounting the BS on a pole or on a wall •...

  • Page 36: Mounting Bracket Description

    Installing the RNU4000BS BS RNU4000BS Base Station User Manual Verify that there are no power lines near the pole. • 4.1.2 Mounting Bracket Description The figure below shows the BS mounting bracket. Note: The same mounting bracket is used for the wall and the pole installation. WALL/POLE RACKET BASE CLAMPING BRACKET...
  • Page 37 RNU4000BS Base Station User Manual Installing the RNU4000BS BS Element Description WALL/POLE BRACKET Used for connecting the bracket to the wall. CLAMPING BRACKET Used for securing the bracket to the pole. Provided screws, nuts and washers: A. 4x flat washer M5 B.

  • Page 38: Mounting On A Pole

    Installing the RNU4000BS BS RNU4000BS Base Station User Manual 4.1.3 Mounting On a Pole Note: When installing on a pole, leave at least 40cm space between the BS and the top of the pole for lightning protection. To install the BS on a pole 1.
  • Page 39 RNU4000BS Base Station User Manual Installing the RNU4000BS BS 2. Assemble the bracket elements: Secure the WALL/POLE BRACKET to the Bracket Arm and then to the Bracket • Base using the provided screws, as shown below: BASE - connect WALL/POLE BRACKET to BS Ridges to ridges...

  • Page 40: Mounting On A Wall

    Installing the RNU4000BS BS RNU4000BS Base Station User Manual For poles with a diameter of 1.00-1.75”: CLAMPING BRACKET Assembled CONCAVE on the pole Mount the BS on the pole using the Clamping Bracket as shown above. Assemble • the bracket CONCAVE as shown. Tighten the bracket using the provided screws.
  • Page 41 RNU4000BS Base Station User Manual Installing the RNU4000BS BS BASE Assemble to Ridges to ridges i ARM Washers and bolt Note: The bolt head should be positioned in the socket on the Bracket BASE. 3. Mount the BS on the wall: Mount the WALL/POLE BRACKET on the wall in the appropriate position.

  • Page 42: Overview Of The Cable And Power Connections

    Installing the RNU4000BS BS RNU4000BS Base Station User Manual Attach the Bracket Arm to the WALL/POLE BRACKET using the provided • screws. WALL/POLE BRACKET Note: The bolt head should be positioned in the ARM socket. Use a tightening torque of 24 N/m to the azimuth and elevation hardware. •...
  • Page 43 RNU4000BS Base Station User Manual Installing the RNU4000BS BS If necessary, secure the cables to the pole so that it is not loose using plastic strips. 40cm from TOP of pole GPS Antenna Double Dual-Slant RF Antennas Cables for 4 GPS Cable RF Antennas (10 meters max)

  • Page 44: Mounting The Rf Antennas

    Installing the RNU4000BS BS RNU4000BS Base Station User Manual 4.3 Mounting the RF Antennas After mounting the base station on a pole or wall: For models with external RF antennas, mount the RF antennas in the selected locations • according to the instructions given in this section. Mount the GPS Antenna in the selected locations according to the instructions given in •...

  • Page 45: 4X4 Antennas Outdoor Connection Requirements

    RNU4000BS Base Station User Manual Installing the RNU4000BS BS 4.3.1.3 4x4 antennas Outdoor Connection Requirements Pico BS 4x4 antennas require using Antennas Dual Slant type (with polarization). Antennas connection should be accordantly: BS “Ant 1” connector → connected via RF cable →to Antenna 1 “Port 1” or “ANT1” •...

  • Page 46: Pole Mounted Gps Antenna

    Installing the RNU4000BS BS RNU4000BS Base Station User Manual 4.4 Pole Mounted GPS Antenna The following is an example of a pole mounted GPS antenna for single-sector coverage. Runcom Technologies Ltd.

  • Page 47: Gps Antenna Installation

    RNU4000BS Base Station User Manual Installing the RNU4000BS BS 4.4.1 GPS Antenna Installation The GPS active antenna may be mounted using two different methods: Attached to a pole or other hosting surface using a magnet • Mounted to the RNU4000 unit using the supplied bracket. •...

  • Page 48: Multi-Sector Daisy-Chained Gps Antennas

    Installing the RNU4000BS BS RNU4000BS Base Station User Manual 4.4.4 Multi-sector Daisy-chained GPS Antennas This section describes how to connect and synchronize GPS antennas for multi-sector sites covered by a dedicated RNU4000BS unit per site (x4 Tx/Rx channels per site). The BSs can be connected in two configurations: One GPS antenna can serve all the BSs •...

  • Page 49: Performing A Ping Test

    RNU4000BS Base Station User Manual Installing the RNU4000BS BS To perform the test 1. Ensure that the BS is configured with the: Center frequency • ASN-GW IP address and security parameters • 2. Connect the BS to a CPE configured with the: Center Frequency •...

  • Page 50: Field Test Performance Evaluation

    Field Test Performance Evaluation RNU4000BS Base Station User Manual 5 Field Test Performance Evaluation The purpose of this document is to validate in the field performance of Runcom system that includes base station and CPEs (with or without NOC) in the operation modes. The field tests cover MIMO-A (Matrix A or SISO) and MIMO B (Matrix B).

  • Page 51: Field Test Setup

    RNU4000BS Base Station User Manual Field Test Performance Evaluation 1. For MIMO B operation mode the DL CINR should be 25db 2. For maintaining the MIMO B mode the recommended set up is LOS or Near-LOS. 5.2 Field Test Setup The setup presented here is a suggestion for a general setup which allows the operation of the tests as described in this document.
  • Page 52 Field Test Performance Evaluation RNU4000BS Base Station User Manual Figure 31 Field Test Point Sector 1 120° Site Figure 32 Sector Radio Coverage Runcom Technologies Ltd.

  • Page 53: Field Test Procedure

    RNU4000BS Base Station User Manual Field Test Performance Evaluation 5.3 Field Test Procedure Preliminary preparation 1. Establish the test setup and the outdoor installation according to the figure “Field Test Setup” or equivalent 2. Establish connection between the BS and the CPE and required settings to obtain proper connection Perform PC to PC TCP throughput performance using measurement tools: FTP “FileZilla Server”...
  • Page 54 Field Test Performance Evaluation RNU4000BS Base Station User Manual UL Throughput performance SISO - theoretical calculation / symbol ratio 32:15 DL Modulation DL CINR DL Throughput DL Throughput (max) threshold (max) BW 5MHz BW 10MHz [Mb/s] [Mb/s] QPSK 1/2 1.34 QPSK 3/4 QAM 16 1/2 2.68...

  • Page 55: Technical Specifications

    RNU4000BS Base Station User Manual Technical Specifications Technical Specifications The RNU4000BS BS installation procedure involves the following accessories: RF Antennas • GPS Antenna (Optional) • Mounting kit • This section details the specifications for the RNU4000BS BS and accessories. 6.1 RNU4000BS BS Specifications Radio Standard compliance complies with 802.16e according to the WiMAX Forum profiles.
  • Page 56 Technical Specifications RNU4000BS Base Station User Manual Management Network Management SNMPv2/v3, standard and proprietary MIB System Configuration SNMP, FTP, CLI Software Upgrade Remote TFTP upgrade of firmware and programming Interfaces Network Interfaces 2x10/100 Base-T, Optional 1xGE and optical interface SX/LX Northbound Interface Profile C, R6 per SF GRE tunnel, Profile B is optional Connectors...

  • Page 57: External Dual-Slant Rf Antennas Specifications

    RNU4000BS Base Station User Manual Technical Specifications 6.2 External Dual-Slant RF Antennas Specifications 6.2.1 Dual-Slant Antenna 2.3-2.7 GHz; 17 dBi; 65° (MT-364054/ND) Electrical Gain 16 dBi (min) @ 2.3 - 2.5 GHz 17.5±0.5 dBi @ 2.5 - 2.7 GHz VSWR 1.5:1 (typ), 1.7 :1(max) Azimuth Beam width @ 13.5dBi 65º...

  • Page 58: Double-Dual Slant 2300-2700 Mhz Remote Tilt-Panel Antenna

    Technical Specifications RNU4000BS Base Station User Manual 6.2.2 Double-dual Slant 2300-2700 MHz Remote Tilt-Panel Antenna Electrical Frequency Range 2300-2700 MHz Gain 17.1 dBi @ 2.4 GHz 17.8 dBi @ 2.6 GHz Return Loss > 15 dB Polarization Dual Slant ± 45° Horizontal Beamwidth 65°...

  • Page 59: Dual-Slant Antenna 2.3-2.7 Ghz; 16 Dbi; 60° (Sp2327-16Xp60Nuf)

    RNU4000BS Base Station User Manual Technical Specifications 6.2.3 Dual-Slant Antenna 2.3-2.7 GHz; 16 dBi; 60° (SP2327- 16XP60NUF) Electrical Gain 16 dBi @ 2.3-2.5 GHz 16.5 dBi @ 2.5-2.7 GHz VSWR 1.5 : 1 (max) Azimuth Beamwidth @ 13.5dBi 60º +/- 5º Elevation Beamwidth @ -3 dB 9º...

  • Page 60: Dual-Slant Antenna 2.3-2.7 Ghz; 15 Dbi; 90° (Sp2327-15Xp90Nuf)

    Technical Specifications RNU4000BS Base Station User Manual 6.2.4 Dual-Slant Antenna 2.3-2.7 GHz; 15 dBi; 90° (SP2327- 15XP90NUF) Electrical Gain 14.5 dBi @ 2.3-2.5 GHz 15 dBi @ 2.5-2.7 GHz VSWR 1.5 : 1 (max) Azimuth Beamwidth @ 13.5dBi 90º +/- 5º Elevation Beamwidth @ -3 dB 9º...

  • Page 61: Dual-Slant Antenna 3.3-3.8 Ghz; 17 Dbi; 65° (Mt-404067/Nd)

    RNU4000BS Base Station User Manual Technical Specifications 6.2.5 Dual-Slant Antenna 3.3-3.8 GHz; 17 dBi; 65° (MT-404067/ND) Electrical Gain 16 dBi (min) @ 3.3-3.4 GHz 17.5 ±0.5 dBi @ 3.5-3.8 GHz VSWR 1.5 : 1 (typ) 1.8:1 (max) Azimuth Beamwidth @ 13.5dBi 65º...

  • Page 62: Dual-Slant Antenna 3.3-3.8 Ghz; 17 Dbi; 65° (Sp3338-17Xp65)

    Technical Specifications RNU4000BS Base Station User Manual 6.2.6 Dual-Slant Antenna 3.3-3.8 GHz; 17 dBi; 65° (SP3338-17XP65) Electrical Gain 16.5 dBi @ 3.3-3.5 GHz 17 dBi @ 3.5-3.8 GHz VSWR 1.5 : 1 (max) Azimuth Beamwidth @ 13.5dBi 65º +/- 5º Elevation Beamwidth @ -3 dB 7º...

  • Page 63: Radiation Patterns

    RNU4000BS Base Station User Manual Technical Specifications 6.2.6.1 Radiation Patterns SP3338-17XP65 azimuth plane SP3338-17XP65 elevation plane Runcom Technologies Ltd.

  • Page 64: Dual-Slant Antenna 3.3-3.8 Ghz; 17 Dbi; 90° (Sp3338-17Xp90)

    Technical Specifications RNU4000BS Base Station User Manual 6.2.7 Dual-Slant Antenna 3.3-3.8 GHz; 17 dBi; 90° (SP3338-17XP90) Electrical Gain 15.5 dBi @ 3.3-3.5 GHz 16 dBi @ 3.5-3.8 GHz VSWR 1.5 : 1 (max) Azimuth Beamwidth @ 13.5dBi 90º +/- 5º Elevation Beamwidth @ -3 dB 7º...

  • Page 65: Radiation Patterns

    RNU4000BS Base Station User Manual Technical Specifications 6.2.7.1 Radiation Patterns SP3338-17XP90 azimuth plane SP3338-16XP90 elevation plane Runcom Technologies Ltd.

  • Page 66: Dual-Slant Antenna 4.9-5.95 Ghz; 16 Dbi;90º (Mt- 464018/Nd)

    Technical Specifications RNU4000BS Base Station User Manual 6.2.8 Dual-Slant Antenna 4.9-5.95 GHz; 16 dBi;90º (MT- 464018/ND) Electrical Gain 16 dBi (min) @ 4.9-5.95 GHz VSWR 2 : 1 (max) 1.7:1 (typ) 4dB Azimuth Beam width 90º (typ) Elevation Beam width @ -3 dB 6.0º...

  • Page 67: Rnu4000Bs Internal Antenna Specifications

    RNU4000BS Base Station User Manual Technical Specifications 6.3 RNU4000BS Internal Antenna Specifications Specifications for 2.5 GHz / 3.5 GHz/4.9GHz Electrical 2.5 GHz 3.5 GHz 4.9 GHz Antenna Model 4x Sector 4 x Sector 4 x Sector Frequency Range 2.3 – 2.7 GHz 3.3 –...

  • Page 68: Gps Antenna Specifications

    Technical Specifications RNU4000BS Base Station User Manual 6.4 GPS Antenna Specifications GPS Active Antenna (BY/GPS/06) Dielectric Center Frequency 1575.42 MHz ± 3 MHz VSWR 1.5:1 Bandwidth ±5 MHz Impedance 50 ohm > 3 dBic Based on 7×7cm ground plane Peak Gain Gain Coverage >- 4 dBic at –90°<0<+90°(over 75% Volume) Polarization...
  • Page 69 RNU4000BS Base Station User Manual Technical Specifications Humidity 95%~100% RH Weatherproof 100% Weatherproof Runcom Technologies Ltd.
