Intova ISS 2000 Quick Start Manual

Step 9:
Arm mount to camera tray. To mount the arm on the camera tray back off the knurled screw to allow the
strobe arm to slide onto the camera tray. Once installed tighten the screw to a snug fit
I
—
Strobe mount to arm. Position Strobe head on top of arm and tighten hold-down screw so that strobe is
at desired angle.
The ISS 2000 Underwater Slave Flash has
two pick-up sensors. When either detects a sudden flash the
Strobe fires instantaneously. For this reason the sensor should be aligned so that it is slightly forward of
the camera flash when adjusting the arm configuration for picture taking.
Specifications:-
• Guide No. 60/20
• Coverage Angle: 60 degree
• Color Temperature: 5700 K
• Batteries (not included): 4AA Alkaline Battery
Cycle Time: Approx 7-8 seconds
• Rated Depth: 54M (180 Feet)
• No. of Pre-Flash Settings : 4
• No. of Power Output Level Settings: 4 (10%> 25%> 50%> 100%)
INTOVA
155 2000
UNDERWATER SLAVE FLASH
QUICK START GUIDE
Preparing the INTO
VA Underwater Slave
Flash for Use
Step 1
Battery installation
Unscrew the large knob giving access to the battery compartment.
You will feel some resistance as there are two 0-rings providing positive protection against leakage.
Upon removal you can see the battery holder inside the compartment
—
slide this out
Step 2
Install four Double AA batteries in the holder paying close attention to polarity
Replace battery holder, lit can only be inserted when correct)
Step 3
