Summary of Contents for Ambiano md37277
- Page 1 User Manual TABLE TOP FREEZER...
-
Page 2: Table Of Contents
Contents Overview ..................4 Use ....................5 Scope of delivery/device parts ............6 General information ................ 7 Please read these operating instructions and keep them in a safe place ....................7 Explanation of symbols ................ 7 Proper use ..................8 Safety information ................9 General safety instructions ..............10 Transport ....................11 Setting up and electrical connection ..........11... -
Page 4: Overview
Distance to the sealing and the side walls Distance to the rear wall... -
Page 6: Scope Of Delivery/Device Parts
Scope of delivery/device parts Temperature control (on the back, not shown) Hinge, top Freezer door Hinge, bottom Adjustable feet Mains cable with plug (on the back, not shown) Shelf Freezer compartment... -
Page 7: General Information
General information General information Please read these operating instructions and keep them in a safe place Read the safety instructions carefully before using the device for the fi rst time. Note the warnings on the device and in the operating instructions. Always keep the operating instructions close to hand. -
Page 8: Proper Use
Proper use Warning: risk of explosion! Warning: risk of fi re! This symbol gives you useful additional information on assembly or operation. Declaration of conformity (see section “Declaration of conformity”): Products bearing this symbol meet all the regulations and standards applicable in the European Economic Area. -
Page 9: Safety Information
Safety information − Heed all the information in these operating instructions, especially the safety information. Any other use is deemed improper and can cause personal injury or property damage. − Do not use the appliance outdoors. − Do not expose the product to extreme conditions. The following should be avoided: −... -
Page 10: General Safety Instructions
Safety information − Do not store any of the packaging material used (bags, polystyrene, etc.) within the reach of children. WARNING! Risk of suffocation. There is a risk of suffocation if plastic packaging or small parts are inhaled or swallowed. −... -
Page 11: Transport
Safety information − Manipulations to the coolant circuit are not permitted and will invalidate the warranty. − If the cooling system becomes damaged and no ignitable gas- air mixture can form, the room in which the appliance is located must be well ventilated for a few minutes (according to the EN 378 standard, the room must have a minimum size of 1 m 8 g of refrigerant. -
Page 12: Setting Up The Appliance
Safety information − Do not operate the appliance if it has been visibly damaged or the mains cable or plug is defective. Setting up the appliance − Connect the appliance only to a properly installed safety socket that is easy to reach and close to the set-up location. The mains voltage should correspond to the technical data for the appliance. - Page 13 Safety information − The appliance should be level; compensate for any unevenness in the fl oor by appropriately unscrewing the two adjustable feet − Do not place any other household appliances (such as a microwave, food processor, etc.) on top of the freezer. −...
-
Page 14: Cleaning And Maintenance
Safety information The appliance may not function perfectly (possible defrosting of the stored food or an increased temperature in the freezer compartment) if it is exposed for a long period of time to temperatures that are colder than the lower limit of the temperature range for which it was designed (below 16 °C). -
Page 15: Faults
Safety information DANGER! RISK OF EXPLOSION AND FIRE. Explosions can occur due to the formation of gases. − Do not use any flammable liquids to clean the appliance or any parts of the appliance. − Do not use any defrosting sprays. They could cause the formation of explosive gases. -
Page 16: Disposal
Safety information − To prevent risks, damaged mains cables may only be replaced by our Service Centre or by a qualifi ed specialist workshop. − In the event of a fault, contact our Service Centre or another suitable specialist workshop. Disposal WARNING! Risk of injury! -
Page 17: Package Contents
Package contents Package contents WARNING! Risk of suffocation. There is a risk of suffocation if plastic packaging or small parts are inhaled or swallowed. − Do not store any of the packaging material used (bags, polystyrene, etc.) within the reach of children. When unpacking, ensure that the following parts are included: •... -
Page 18: Information On The Refrigerant R600A
Preparing the freezer Information on the refrigerant R600a The R600a and cyclopentane used in this appliance are 100% CFC-free coolants and insulants. This helps to protect the ozone layer and reduce the greenhouse effect. These appliances can be identifi ed by the marking “Refrigerant R600a” on the type plate. -
Page 19: Using The Freezer
Using the freezer 6. Tilt the appliance slightly backwards and remove the adjustable feet 7. Remove the three screws on the bottom hinge with a spanner and then remove the hinge. 8. Fit the bottom hinge on the left side of the appliance and mount the adjustable feet. -
Page 20: Setting The Temperature
Using the freezer − Store foods only in suitable containers or the original packaging. − Select the setting of the temperature control according to how full the appliance is. Setting the temperature The temperature of the freezer is controlled via the temperature control The cooling temperature can be set as follows: The appliance is switched off The lowest cooling level (the warmest) -
Page 21: Defrosting The Freezer Compartment
Using the freezer Defrosting the freezer compartment WARNING! Risk of injury. Burns caused by low temperatures are possible. − Do not touch the frozen inner walls of the freezer compartment or frozen food with your hands. Use an aid such as a dry cloth to handle the frozen food. -
Page 22: Switching Off The Appliance
Cleaning the appliance Switching off the appliance − In order to switch off the power to the appliance completely, disconnect the mains plug from the mains socket. Cleaning the appliance WARNING! Risk of electric shock. There is a risk of electric shock from electrifi ed parts. −... -
Page 23: Transport
Transport − Clean all of the fi ttings carefully and dry them. − Clean the appliance surfaces, except the door seal, with a mild cleaning agent. If necessary, the appliance surface can be treated with silicone wax. − Clean the door seal with clean water; wipe it off and allow it to dry. −... -
Page 24: End Of Operation
End of operation Malfunction Problem Remedy The temperature The door will not shut − Arrange the contents of the is not low tight, or is opened fridge so that nothing can enough. too often. prevent the door from closing. − Open the door only for a short period of time. -
Page 25: Disposal
Disposal Disposal Appliance Old appliances should not be disposed of with the normal household rubbish. In accordance with Directive 2012/19/EU, the appliance must be properly disposed of at the end of its service life. This involves separating the materials in the appliance for the purpose of recycling and minimising the environmental impact. -
Page 26: Technical Data
Technical data Technical data Brand: AMBIANO Model: MD 37277 Category: Temperature rise time: Star rating of frozen-food storage 4-star compartment: Freezing capacity: 2kg/24hrs Noise emissions: 42 dB Rated Voltage: 220–240 V~ Rated Frequency: 50 Hz Rated Current: 0.6 A Energy Consumption: 146 kWh/year* 0.40 kWh/24 h... -
Page 27: Declaration Of Conformity
Declaration of conformity Declaration of conformity Medion AG hereby declares that the product MD 37277 conforms to the following European requirements: • EMC Directive 2014/30/EU • Low Voltage Directive 2014/35/EU • Regulation (EC) No 1935/2004 Legal notice Copyright © 2017 Status: 2017-10-19 All rights reserved. - Page 29 Great care has gone into the manufacture of this product and it should therefore provide you with years of good service when used properly. In the event of product failure within its intended use over the course of the fi rst 3 years after date of purchase, we will remedy the problem as quickly as possible once it has been brought to our attention.
