R E A D A N D S AV E T H E S E I N S T R U C T I O N S
X L ERATOR
®
MODELS: X L - B W
W
G R C SB
INSTAL L ATION AND OW NER' S M ANUAL
CONTENTS OF B OX
1
Hand Dryer
M ODEL INF O
Dryer Model
Serial Number
Date Of Purchase
5 - Y EAR L IM ITED W ARRANTY (U.S. Only)
1. T his product is warranted to be free of manufacturing defects for five (5) years (one [1] year on HEPA Filter & Pre-Filter) from the
date of shipment from the Manufacturer's factory at 357 Chestnut St., East Longmeadow, Massachusetts 01028. This warranty
explicitly excludes normal wear and tear on the Filter or Pre-Filter, as well as faulty installation, accident, misuse, or vandalism.
In the event of a breach of the warranty described above, the Owner shall have either one of the following remedies:
a. The Owner shall return the defective product to the Manufacturer, postage prepaid, and the Manufacturer shall repair said
product within a reasonable time and free of charge, provided that said product is returned within the stated period above
from the date of original shipment from the Manufacturer's factory in East Longmeadow, Massachusetts; and, provided further
that said defect is not due to faulty installation, accident, misuse, or vandalism; or
b. The Owner may notify the Manufacturer by telephone or in writing of the defect and, within a reasonable time, the
Manufacturer shall send a suitable replacement part to remedy said defect, and Owner shall be charged for said part at the
current price level. The Owner may return the defective part to the Manufacturer, postage prepaid, along with the serial
number of the defective product and the Manufacturer will then issue to the Owner a full credit for the repair part, including
outgoing postage (within the Continental U.S. only). Said remedy is available only within the stated period stated above from
the date of original shipment of the product from the Manufacturer's factory in East Longmeadow, Massachusetts, and
provided further that said defect is not due to faulty installation, accident, misuse, or vandalism.
2. Any implied warranties of merchantability or fitness for a particular purpose are hereby limited to the duration of the express written
warranty contained in paragraph one (1); namely, five (5) years (one [1] year on HEPA Filter & Pre-Filter) from the date of shipment
from the Manufacturer's factory in East Longmeadow, Massachusetts.
3. There are no other warranties and remedies except as contained herein. This warranty shall inure to the benefit of the Owners,
Successors and Assigns.
E X C E L
D R Y E R , I N C
3 5 7
C H E S T N U T S T R E E T, E A S T L O N G M E A D O W
AND X L ERATOR e c o
SI SP
WITH OR WITHOUT SUFFIX:
2
Tamper-Proof Wrench
1 . 8 0 0 . 2 5 5 . 9 2 3 5
HAND DR Y ER M ODE L S
®
ECO
E X C E L D R Y E R . C O M
A D M I N @
, M A 0 1 0 2 8
V
H
3
Installation and Owner's Manual
110–120V 11.3 – 12.2A
208–277V 5.6 – 6.2A
110–120V 4.3 – 4.5A XLERATOReco
208–277V
2 – 2.2A
E X C E L D R Y E R . C O M
XLERATOReco
0 2 / 2 0 1 6
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Excel XL-BW
Summary of Contents for Excel XL-BW
- Page 1 R E A D A N D S AV E T H E S E I N S T R U C T I O N S X L ERATOR AND X L ERATOR e c o HAND DR Y ER M ODE L S ®...
- Page 2 R E A D A N D S AV E T H E S E I N S T R U C T I O N S IM P ORTANT SAF ETY INSTRUCTIONS W ARNING : F o r p r o p e r e l e c t r i c a l c o n n e c t i o n s , c h e c k y o u r l o c a l b u i l d i n g c o d e s . Your unit must be installed by a qualified, licensed electrician.
- Page 3 , t o t h e s e r v i c e p a n e l . CL EANING / M AINTENANCE OUTSIDE Gently wash Cover (including air inlet holes) using a soft cloth or sponge and a mild soap or detergent with lukewarm water to loosen dirt and grime. INSIDE Excel recommends inspecting the inside of the dryer and cleaning as required at least once per year, or if performance diminishes. Heavier usage, or an environment that contains excessive lint, dust or other particles, requires more frequent cleaning. Lint on the air inlet, the Pre-Filters (Dryer or HEPA if so equipped), or other internal parts of dryer will reduce efficiency and shorten the life of the working parts. To clean, shut off power to dryer at service connection. Remove Cover by unscrewing the 2 Tamper-Proof Bolts from side of Cover with the special Tamper-Proof Wrench provided with each dryer. Use a small, soft brush to gently clean all parts. If your unit contains a dryer Pre-filter or HEPA Filtration System, unclip the Pre-Filter, rinse the Pre-Filter with water and dry. Re-install.
- Page 4 TROUB L ESHOOTING ( Co n t i n u e d ) Dryer blows only cold air (non-ECO dryers) Dryer has loss of air volume C heck heat setting on control. Check motor speed setting on control. 2. Check for loose connections to Heating Element. 2. Check for slow running Motor or burning smell. If so, replace Motor. Replace Heating Element. 3. Check Pre-Filter for lint buildup. Clean by removing Pre-Filter and rinse in warm water then dry Pre-Filter before reinstalling. CODE CHART Codes are displayed by the flashing of the red LED light in the sensor adjacent to the air outlet.
