KD interactive Aura Drone with Glove Controller Instruction Manual page 2

HOW TO INSTALL BATTERIES
Drone battery
connector
1. Gently insert the big
2. Make sure that the
battery into the
battery connector
battery compartment
faces the outside and is
located on the bottom
not pushed inside.
of the Aura Drone.
HOW TO CHARGE - Charging Aura Drone
1. Turn Aura Drone OFF by 2. Plug the USB cable
disconnecting the battery into a computer or a
from its connector.
USB charging wall
adapter. The
Charging Indicator
light will turn red.
HOW TO CHARGE - Charging Aura Glove Controller
Connector
ON
OFF
ON/OFF switch
2. Disconnect the battery
1. The Aura Glove Controller
of the Aura Glove
LEDs will blink red when
Controller from the
the battery needs to be
connector.
charged. Turn the Aura
Glove Controller OFF by
using the ON/OFF switch.
HOW TO FLY
Drone battery
connector
Light of the Drone
Aura Drone
connector
1. Always switch on the
2. Place the Aura drone on a
drone by connecting the
flat surface with the light
battery connector of the
of the drone facing you.
Aura Drone to the battery.
Light of the Drone
6. Extend your arm. Position your hand parallel to the
ground, palm facing down. Keep the Aura Glove
Controller flat. The Glove Controller will calibrate
showing rainbow colors. Then the LEDs on the glove
controller will blink green to show the Glove controller
binding with the Aura Drone.
HOW TO REMOVE BATTERIES
Glove battery connector
Glove battery
housed inside
Side Button
1. Gently slide the battery
2. The Aura Glove
out of the battery Controller comes with
compartment located on a pre-installed battery
the bottom of the Aura that cannot be
Drone.
removed.
Charging indicator off
3. Carefully plug the other
4. The Charging Indicator
end of the USB cable light will turn off while
into the connector of charging.
the Drone battery.
Charging
indicator off
3. Plug the USB cable into a 4. The Charging Indicator light will turn
4. The Charging Indicator
off while charging
computer or a USB charging
will turn off while charging.
wall adapter. The Charging
Indicator light will turn red.
Carefully plug the other end
of the USB cable into the
connector of the Glove
Controller.
Connect
3. Connect the battery 4. Put the glove controller
connector of the glove on by ensuring that one
controller. band goes behind the
thumb and the other is
between the thumb and
first finger.
Take-off/Landing Button
NOTE ON DRONE ORIENTATION:
The blue light of the drone should always face
you. If the drone changes orientation and the
blue light faces away from you, it is
recommended that you change the position of
your body to face the light of the drone.
NOTE ON GLOVE CALIBRATION:
7. Once the Glove Controller
It is important to keep the hand flat to allow
LEDs are solid green color and
the Aura Glove controller to calibrate to your
the drone LED is solid blue
hand. The LEDs will flash a rainbow pattern
color, press the Take Off/Landing
and then blink green. Once calibration is
button 1 time and the Aura
complete, the light of the drone stops blinking
Drone will take off.
and becomes solidly lit.
2
HOW TO FLY - Forward/Backward
Forward
HOW TO FLY - Change the Height
Side button
Charging Indicator Red
1. Press the side button with your
thumb. Keep it pressed and tilt up
5. The Charging Indicator
to increase the height. The LEDs
light will turn on red
will animate with an orange color.
when fully charged. Once
NOTE: The height of the drone will lock at an approximate
fully charged, remove the
height of 7 to 8.5 feet (2.1 - 2.6 meters) above height of drone at
charging wire and store
take-off. This range may vary.
back in a safe place.
HOW TO FLY - Land
Take-off/Landing Button
Charging Indicator Red
5. The Charging Indicator
1. Press the Take Off/Landing button
light will turn on red when
1 time.
fully charged.
HOW TO FLY - Switch Off
ON
OFF
ON
OFF
1. Switch OFF the glove controller
using the ON/OFF switch.
5. Switch the Aura Glove
Controller on using the
ON/OFF switch. The LEDs will
turn white during the power
BLADE REPLACEMENT
on state.
The drone needs two shapes of propellers A and B. You can find markings of A and B on the
propellers and the body of the drone. When replacing propellers, match one A propeller to one A
slot on the drone and one B propeller to one B slot on the drone.
1. Choose a replacement propeller that belongs to the drone slot by matching the labels, A to A
and B to B.
2. Hold the drone steady with one hand from the bottom of the plastic housing of the motor. Do
not hold the drone from the protective frame. Use your other hand to gently pull the propeller
straight up until you feel and see it release.
3. Line up the motor shaft (little metal rod coming out of the motor body) with the hole in the body
of the replacement propeller. The shaft will go in the hole.
4. Gently push the propeller from the top down into the shaft until the propeller is secure. Do not bend
the frame while doing this step.
HOW TO FLY - Left/Right
Backward Left
HOW TO FLY - Flip
Side button
2. Keep it pressed and tilt down to 1. Press the side button with your
decrease the height. The LEDs thumb. Keep it pressed, and tilt to
will animate with an purple the right to flip right. The LEDs will
color. blink with a turquoise color. Flip
won't work if the Aura Drone
battery is low and the Aura Drone
Light is flashing.
2. Direct the drone to safety using forward/backward/left/right gestures to
land.
HOW TO FLY - Drone Calibration
Drone battery
Take-off/Landing Button
connector
Aura Drone
connector
2. Switch off the drone by If your drone drifts while taking off, it needs to be calibrated. Place the
disconnecting the batteries. drone on a flat surface. Press the Take Off/Landing button and hold it
down for 2 seconds. The LEDs on the Aura Glove controller will blink blue
and the light of the Aura drone will blink fast. When the calibration is
complete, the light of the drone will become solidly lit and the LEDs of
the Aura Glove Controller will return to green.
3
Right
2. Press the side button with your
thumb. Keep it pressed, and tilt to
the left to flip left. The LEDs will
blink with a yellow color. Flip won't
work if the Aura Drone battery is
low and the Aura Drone Light is
flashing.
3. The drone will automatically land.
Light of the Drone
A
B
B
A
