iKANOO BT014 Service Manual

Power bank bluetooth speaker with microphone

Advertisement

Quick Links

BT014 Service Manual for Power Bank Bluetooth Speaker with
II Considerate Hints
1. Please do not turn up the volume to a fairly high level constantly as this could shorten the service
life of this product or impair your hearing ability, physical and mental
2. When encountering any malfunction during operation, please cut off the power supply and
disconnect the USB cable to prevent further damage to the speaker or other components;
3. The Bluetooth transmission range or connectivity could be affected by low battery power. In that
case, please recharge the device immediately.
4. Please remove audio cables for the use of Bluetooth.
III.

Outer appearance and function buttons

Speaker
: Press it for a long time for volume decrease during music playing; short time press for precious song. Under
BLUETOOTH mode, it's only for volume decrease
: Press it for a long time for volume increase during music playing; short time press for next song; under
BLUETOOTH mode, it's only for volume increase
/ When the Bluetooth is connected and calls are incoming, please click it to answer the phone and
click it again to hang up. Double click
IV. Product features
1. Dual-mode power supply:
Dual-mode power supply: Built-in lithium battery of the product can be supplied powers by USB
interface or USB power of DC5V.Dual-power mode can be selected freely.
2. AUX audio input: 3.5MM audio cable shall be input to connect various sound sources of widely
audiovisual products, including computer and MP3/MP4/IPOD/IPHONE.
3. Bluetooth technology: Built-in high quality Bluetooth module to wirelessly stream music and
answer phone calls hands-free.
4. Power bank:
Built-in high-capacity power bank for charging portable devices via 5V USB. Add up to 9 hours of
talk time to your iPhone and other smartphones.
Microphone
Brand name:IKANOO
FCC ID: OYCBT014
Recharge/ON/OFF
can replay the last phone in connections.
health.
USB Port
MICRO USB
Aux Port
Headshaking
button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT014 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for iKANOO BT014

  • Page 1 BT014 Service Manual for Power Bank Bluetooth Speaker with Microphone Brand name:IKANOO FCC ID: OYCBT014 II Considerate Hints 1. Please do not turn up the volume to a fairly high level constantly as this could shorten the service life of this product or impair your hearing ability, physical and mental health.
  • Page 2 V. Product parameters: Power output:3W R.Frequency: 90Hz-20KHZ Sensitivity: 80db±2db S/N Ratio: ≥76dB Input power: DC5V_500mA Power bank output: DC5V_1000mA VI. Bluetooth specifications Bluetooth specifications: BLUEBOOTH 2.1+EDR Bluetooth transmission distance: ≤10M (Depending upon operation environment and devices to which it connects) Bluetooth compatibility: BLUETOOTH V2.1+EDR, Consists of protocols like A2DP and HFP and so on.
  • Page 3 right away. Tracks can be selected and volume adjusted only by the music player. Hints: 1. Plug in AUX, the Bluetooth shall disconnect and blue ligh shall be on all the time. 2. Please remove audio cables for the use of Bluetooth. Hands-free calls: After Bluetooth speaker is connected to mobile phone successfully, the speaker beeps when calls are incoming;...

Table of Contents
