QUCIKTE TECHNOLOGY I30-802M Hardware Installation Manual

I30 series

Advertisement

Quick Links

I 30 SERIES
Hardware Installation Manual
INSTALLATION and OPERATION MANUAL
Release 1.0
2011/05/03
Confidential – QUCIKTE TECHNOLOGY CO., LTD
Page 1 of 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I30-802M and is the answer not in the manual?

Questions and answers

Summary of Contents for QUCIKTE TECHNOLOGY I30-802M

  • Page 1 I 30 SERIES Hardware Installation Manual INSTALLATION and OPERATION MANUAL Release 1.0 2011/05/03 Confidential – QUCIKTE TECHNOLOGY CO., LTD Page 1 of 16...
  • Page 2 This includes ties, over-size shirts, or dangling jewelry. Clothing items of these types can catch on jumpers and disconnect them, catch on system components and cause injury to you, or damage to the equipment. Electro-Static Discharge Precautions 2011/05/03 Confidential – QUCIKTE TECHNOLOGY CO., LTD Page 2 of 16...
  • Page 3: Table Of Contents

    Rack Mount Installation................10   2.10.4 Desktop Installation .................. 10     2.10.5   Installing a DC Power Supply..............10   2.10.6 Attaching a PC or Terminal ..............12     2011/05/03 Confidential – QUCIKTE TECHNOLOGY CO., LTD Page 3 of 16...
  • Page 4: Getting Started

    1 Getting Started 1.1 Introduction This guide describes I30 SERIES family of products and features from Dowslake Microsystems. These procedures are provided for installing the hardware and configuring the system. 1.2 Audience This manual is designed for system administrators with a working knowledge of Telecommunication and Networking equipment, who need instructions about how to install and configure I30 SERIES.
  • Page 5: Installing I30 Series Equipment

    EMS systems as a plug-in network element. For use in a TN system, I30 SERIES is a UL Class 1, Type A system. Quickte I30 family: I30-802M: 8xFE RJ45 ports, 2* 1000m base-x(combo),8 ports included; Din Rail Shelf with 48V DC power and CLI/WEB/SNMP management included...
  • Page 6: Unpacking A I30 Series

    Unpacking a I30 SERIES The I30 SERIES ships with all of the following items. Please review the list below and verify the contents. If any of the items are missing, please contact your local Quickte representative. • I30 SERIES chassis •...
  • Page 7: Handling And Cleaning Fiber Optic Equipment

    2.4 Handling and Cleaning Fiber Optic Equipment 2.4.1 Handling Fiber optic cable is designed to survive the installation environment. As with coaxial cable, fiber optic cable should never be bent at sharp angles. The most vulnerable area of the fiber is the connector. When pulling fiber, do not pull directly on the connector or on the fiber immediately behind the connector.
  • Page 8: Servicing And Maintenance

    2.6 Servicing and Maintenance I30 SERIES is not serviceable nor does it require regular maintenance or calibration. If experience any difficulties with our product please refer to the Troubleshooting section of this manual or contact Quickte customer service. 2.7 Laser Safety This product complies with IEC60825-1:1993 + A2:2001 and IEC 60825-2, 3 Edition, 2004-06.
  • Page 9 Compare this total with the rating limit for the circuit. The maximum ampere ratings are usually printed on the devices near the input power connectors. WARNING: For the DC input circuit to a I30 SERIES chassis, make sure there is a 5- amp circuit breaker on the input to the power supply.
  • Page 10: Preparing The Installation Site

    2.9 Preparing the Installation Site 2.9.1 Cabling Infrastructure Ensure that the proper cabling is installed in the site. DC power wires should be able to support the maximum current draw. Communications cabling, serial or Ethernet should be installed and working. 2.9.2 Installation Location Before installing the equipment, plan its location and orientation relative to other devices and equipment.
  • Page 11 the end of each one. (Use at least 14 AWG wire.) • Loosen the two screws used to hold the wires in the connectors These are the wires under the following markings: - and + • Slip the return wire into the opening above the + marking until the wire is fully in place, then tighten the screw to hold the wire in place.
  • Page 12: Attaching A Pc Or Terminal

    2.9.6 Attaching a PC or Terminal These ports are used for management: RJ45: To connect with PC through RJ45 by using IP address to telnet in or by using Web GUI. RS232: To connect with PC through RS232 port by using Virtual Terminal There are a number of sessions you can open for different user interfaces:  ...
  • Page 13 To attach a management station using the serial port: Connect a PC or terminal to the serial port of the system using a straight-through cable. The serial port has a RJ45 connector. NOTE: You need to run a terminal emulation program on the PC. Open the terminal emulation program and set the session parameters as follows: Baud: 38400 bps Data bits: 8...
  • Page 14 Pin Assignment Pin Number MTS Signal Reserved Reserved TXD(Output) RXD(Input) Reserved Reserved Figure:I30 SERIES RJ45 PIN assignment Serial Cable RJ45 to DB-9 connection: Figure: Serial Connection between I30 SERIES and PC’s Page 14 of 16...
  • Page 15 Appendix A: Product Specification Specification Model Base Unit Power Over Ethernet(PSE) Input Specification Data Interface RJ-45 Jack ( See Pin Assignment ) Input Voltage 36 ~ 57 Vdc (48V) Input Current 350mA MAX. Input @Vin=48Vdc Output Specification PD Detection & Classification IEEE802.3af compliant PoE Interface RJ-45 Jack...
  • Page 16 Appendix B: Troubleshooting 1. The device connected to PD cannot be powered. Solution: a. Please check if PD is connected to IEEE 802.3af complied device. And check if LED on the PD is blinking once connected to IEEE 802.3af complied device. b.
  • Page 17 FCC Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
