Summary of Contents for Idea DT8260
- Page 1 Noncontact Thermometer With Probe USER’S MANUAL 1 Introduction This meter is a convenient non-contact infrared...
-
Page 2: Lcd Display
thermometer with probe. This thermometer combines precision thermometers in one unit: a noncontact infrared thermometer and a resistance thermal device penetration probe. The noncontact mode can be used for quick scans of a surface temperature, while the probe mode is used to accurately measure internal temperatures. - Page 3 ⑤ Laser targeting aperture ⑥ Probe sensor ⑦ Battery cover ¡ ã C /¡ ã F SCAN LCD display ① Infrared measurement indication ② Laser indication ③ Data hold indication ④ Probe measurement indication ⑤ Low power indication ⑥ °C temperature unit ⑦...
- Page 4 4 Specifications ·Infrared: Measurement range: -20℃~270℃; -4℉~518℉ Resolution: 0.1℃/0.1℉ Accuracy: -20℃~0℃: ±5℃ 0℃~270℃: ±(reading×1.5%+3℃) Field of view: 6:1 Typical Distance to Target: up to 1m Laser power: <1mW Emissirity: 0.97 Over range indication: “OL” or “-OL” ·Probe measurement range: -50℃~270℃; -58℉~518℉ Resolution: 0.1℃(-50℃~200℃) ;...
- Page 5 ·Dimensions: 182(L)×49(W)×43(H) mm ·Weight: 120g. Approx. (battery included) 5 Operation Instruction 5-1. Measurement method of the Infrared ① Point the infrared sensor to the object, and then press the “SCAN” button, the unit begins working, and the laser appears. ② Read the measured result from the LCD display. ③...
- Page 6 ② The Infrared and the probe are all enabled in this state, but the function of auto power off will be disabled. (the measurement method of the Infrared refer to 5-1) ③ Insert the probe at least 12mm(1/2”) into the target, then the meter will measure the core temperature automatically.
- Page 7 The thermometer has a visual angle and visual spot size. a drawing is shown as following: Make sure that the target is larger than the unit’s visual spot size. The smaller the target, the closer you should be to it. The relationship between distance and spot size is 6:1, the drawing as following: 7 CLEANING INSTRUCTIONS...
- Page 8 8 Replace batteries If the sign “ ” appears on the LCD display, it indicates that battery should be replaced. Remove the battery cover, and replace the exhausted batteries with new ones.
