Related Manuals for SMAR DC302

Summary of Contents for SMAR DC302

  • Page 1 OPERATION & MAINTENANCE INSTRUCTIONS MANUAL FIELDBUS REMOTE I/O DC302 FOUNDATION D C 3 0 2 M E...
  • Page 2 Specifications and information are subject to change without notice. Up-to-date address information is available on our website. web: www.smar.com/contactus.asp...
  • Page 3 ™ Fieldbus configuration tool. Function blocks provide logic such as AND, OR, NAND OUNDATION etc. as well as latches etc. Link master capability allows the DC302 to work as a backup LAS for greater availability of network communications. The DC302 may be installed close to the sensors and actuators, thereby eliminating long wire runs and associated marshalling panels and cable trays for the conventional I/O, with subsequent savings further reducing overall system cost.
  • Page 4 Smar provides specific training to instruct and qualify such professionals. However, each country must comply with the local safety procedures,...

  • Page 5: Table Of Contents

    DESCRIPTION-INPUTS ................................5.1 DC302 OPEN COLLECTOR OUTPUTS ........................5.2 DESCRIPTION – OUTPUTS ..............................5.2 ORDERING CODE ..............................5.2 APPENDIX A – SRF – SERVICE REQUEST FORM ................A.1 RETURNING MATERIALS ............................A.2 APPENDIX B – SMAR WARRANTY CERTIFICATE ................B.1...
  • Page 6 DC302 – Operation and Maintenance Instruction Manual...
  • Page 7 Check cabling and connections. ● Check power; ● Are the outputs Check cabling and connections; ● Check if the outputs are open collector; ● Check the load limits. ● * More information in Section 1 from DC302 Operation, Maintenance and Instructions Manual.
  • Page 8 DC302 – Operation and Maintenance Instruction Manual VIII...

  • Page 9: Section 1 - Installation

    For details of mounting, please, refer to Figure 1.1 and Figure 1.2 Mounting Use DIN rail (TS35-DIN EN 50022 or TS32-DIN EN50035 or TS15 DIN EN50045), as shown in Figure 1.1 – Mechanical Mounting. The DC302 can optionally be supplied preinstalled in an enclosure ready for field mounting. Rail Lock Figure 1.1- Mechanical Mounting...

  • Page 10: Electric Wiring

    DC302 – Operation and Maintenance Instruction Manual (6.85) (0.06) NOTE The measurements are in mm. Electric Wiring Access the wiring block by the front View with label for inputs, outputs power supply and bus connection. The connections are made using the screws.
  • Page 11 Installation smar DC302-10 COMM SAVING VOUT Figure 1.4 – Label DC302 The following table describes the terminal numbers for DC302. Upper (U) Lower (U) Remark VIN (1A) GNDIN (2A) Auxiliary power for inputs IN1 (1B) IN9 (2B) IN2 (1C) IN10 (2C)
  • Page 12 DC302 – Operation and Maintenance Instruction Manual Figure 1.6 – Example of Output Connections The DC302 is a non bus-powered device. The DC302 uses a 31,25 Kbit/s voltage mode option for the physical signaling. Various types of Fieldbus devices may be connected on the same bus, being bus-powered or non-bus-powered.

  • Page 13: Topology And Network Configuration

    OUT 1 Fieldbus H1 OUT 2 Fieldbus H1 OUT 3 Fieldbus H1 OUT 4 Fieldbus H1 Spur TERMINATOR ENABLED FUSE 2,5A Junction smar Shield PS302 PS302 Terminator FAIL FAIL 1 FAIL 2 FAIL 3 FAIL 4 Spur Spur smar smar...

  • Page 14: General System

    DC302 – Operation and Maintenance Instruction Manual Junction PSI302 Terminator Figure 1.8 - Tree Topology General System According to the figure below, we can see a general network topology where the DC302 is integrated in a simple Fieldbus network. PS302 PSI302 DC302 TT302...

  • Page 15: Section 2 - Operation

    Section 2 OPERATION The DC302 accepts up to 16 optically isolated inputs and up to 8 open collector outputs. It is therefore ideal for interfacing exisisting discrete points to a Fieldbus system. An extensive Function Blocks library enables the DC302 to execute logic and functions of regulatory and descrete control integrated via H1 Bus.
  • Page 16 DC302 – Operation and Maintenance Instruction Manual MAIN CIRCUIT BOARD INPUT - OUTPUT CIRCUIT BOARD FACTORY FIRMWARE POWER POWER RESET DOWNLOAD ISOLATION SUPPLY INTERFACE FRAM INPUT OPTICAL POWER LATCHES ISOLATION SUPPLY MODEM SIGNAL SHAPING Vout OUTPUT OPTICAL LATCHES ISOLATION Figura 2.1 – DC Block Diagram...

  • Page 17: Section 3 - Configuration

    (2) Do not instantiate FFB block together with MDI, this causes channel conflict. (3) From the serial number 2000 the DC302 comes with 8 DI blocks and 8 DO blocks already instantiated. The firmware version of the equipment must be used with the corresponding version of DD/CFF.

  • Page 18: Connecting Physical Signals To Digital Output Block

    CHANNEL selection. For details, please see the Function Blocks Manual. Figure 3.2 - DC302 and DO Block connections Connecting physical signals to Multiple Digital Input Block One MDI block makes available for the FF network eight discrete variables of the I/O subsystem through its eight output parameters OUT_D1 through OUT_D8.

  • Page 19: Connecting Physical Signals To Multiple Digital Output Block

    Fieldbus actuators and switch gears are the transducer blocks of this block. For details, please see the Function Block Manual. Figure 3.5 - DC302 and PID Step Block connections...

  • Page 20: Simulation Jumper

    To perform the block simulation user must enable the jumper simulation first, which should be in the ON in DC302. See how to enable the hardware in the figure below. Then enable a DI or DO block on configuration software. Refer to Functional Blocks manuals: "Library A" and "Library B".

  • Page 21: Examples Of Applications

    Configuration Examples of Applications Application 1: From the computer the input and output can be manipulated. Figure 3.6 - DC302 – Appplication 1 Application 2: Distributed control (Level limit will start a motor, a pump, or open/close an on/off valve).
  • Page 22 DC302 – Operation and Maintenance, Instruction Manual Application 4: Distributed discrete control using TIME & FFET Function Blocks. Figure 3.9 - DC302 – Appplication 4 Application 5: General application for DC302. HSE Fieldbus DFI302 H1 Fieldbus DC302 Level Switch Motor...

  • Page 23: Flexible Function Block

    Flop and SR Flip-Flop. The logic is done using the 8 discrete variables available for the FF network (OUT_Dx), the 8 input parameters from the FF network (IN_Dx), the 16 input discrete variables from DC302 hardware(HIN), the 8 output discrete variables from DC302 hardware (HOUT), the failsafe (FSx) values and the auxiliary bit variables (AUX’s).

  • Page 24: Parameters

    DC302 – Operation and Maintenance, Instruction Manual Parameters Data Type/ Valid Range/ Default Store/ Parameter Units Description (Length) Options Value Mode The revision level of static data associated ST_REV Unsigned16 None S/RO with the function block. The user description of intended application...
  • Page 25 Configuration Data Type/ Valid Range/ Default Store/ Parameter Units Description (Length) Options Value Mode The calculated discrete output variable 2 OUT_D2 DS-66 D / Man of the block in AUTO mode or specified by the user when in MAN mode. The calculated discrete output variable 3 OUT_D3 DS-66...
  • Page 26 DC302 – Operation and Maintenance, Instruction Manual Data Type/ Valid Range/ Default Store/ Parameter Units Description (Length) Options Value Mode Array of 16 unsigned integer32 elements where the user can set the PST value of each CTU_PST 16 Unsigned32 Positive...
  • Page 27 Configuration Data Type/ Valid Range/ Default Store/ Parameter Units Description (Length) Options Value Mode LOGIC_30 VisibleString(24) Spaces S/ OS Logical Line Command 30. LOGIC_31 VisibleString(24) Spaces S/ OS Logical Line Command 31. LOGIC_32 VisibleString(24) Spaces S/ OS Logical Line Command 32. LOGIC_33 VisibleString(24) Spaces...
  • Page 28 DC302 – Operation and Maintenance, Instruction Manual Data Type/ Valid Range/ Default Store/ Parameter Units Description (Length) Options Value Mode 0 - Logic Ok. 1 - Exceed String Length or string not valid. 2 - Non valid operand. 3 - No...
  • Page 29 Configuration Logic Operation and Command line Symbol - description & EQUAL (arg1,arg2) To define function arguments End of logic line The logic does NOT (!) work only with simple variables. Example: OUT1=!IN1; Note that it is not allowed to have, for example, OUT1=!TP01(IN1);...
  • Page 30 DC302 – Operation and Maintenance, Instruction Manual Parameter Mnemonic HW_IN.Value1 HW_IN.Value2 HW_IN.Value3 HW_IN.Value4 HW_IN.Value5 HW_IN.Value6 HW_IN.Value7 HW_IN.Value8 HW_IN.Value9 HW_IN.Value10 HW_IN.Value11 HW_IN.Value12 HW_IN.Value13 HW_IN.Value14 HW_IN.Value15 HW_IN.Value16 HW_IN.Status HW_OUT.Status HW_OUT.Value1 HW_OUT.Value2 HW_OUT.Value3 HW_OUT.Value4 HW_OUT.Value5 HW_OUT.Value6 HW_OUT.Value7 HW_OUT.Value8 IN_D1.Status IN1S IN_D2.Status IN2S IN_D3.Status IN3S IN_D4.Status...

  • Page 31: Functions

    Configuration Parameter Mnemonic OUT_D6.Status SOUT6 OUT_D7.Status SOUT7 OUT_D8.Status SOUT8 OUT_D1.Value OUT1 OUT_D2.Value OUT2 OUT_D3.Value OUT3 OUT_D4.Value OUT4 OUT_D5.Value OUT5 OUT_D6.Value OUT6 OUT_D7.Value OUT7 OUT_D8.Value OUT8 FSTATE_VAL_D1 FSTATE_VAL_D2 FSTATE_VAL_D3 FSTATE_VAL_D4 FSTATE_VAL_D5 FSTATE_VAL_D6 FSTATE_VAL_D7 FSTATE_VAL_D8 AUX_01_16 A01-A16 AUX_17_32 A17-A32 AUX_33_48 A33-A48 AUX_49_64 A49-A64 AUX_65_80 A65-A80...

  • Page 32: Ton Timer On-Delay

    DC302 – Operation and Maintenance, Instruction Manual Timer Pulse Function – timing diagrams The syntax for Timer Pulse is: TPxx(arg) Where, xx is the used resource from 01 to 16 and arg is the function argument and it must be a simple variable. Examples: O1=TP01(IN1);...

  • Page 33: Tof Timer Off-Delay

    Configuration For example, the following examples are not allowed in the logic line: O1=TON01(IN1&IN2);: note that the argument is a result of an operation, it is not allowed. O1=TON10(!IN1);: note that the argument is a result of NOT function, it is not allowed. O1=TON10(CTD01(IN1,IN2));: note that the argument is a result of a function, it is not allowed.

  • Page 34: Rs Flip-Flop

    DC302 – Operation and Maintenance, Instruction Manual CTU PULSE COUNTER UP This function is used to count rising transitions (from false to true) in the counter input(arg1). Every time it is seeing a rising transition the internal counter accumulator (CTA) increments of one. When the CTA reaches the preset value PST, the counter output will go to true.

  • Page 35: Error Code

    Configuration Error Code Some examples of error conditions: Error Code: "Exceed String Length or string not valid." a) OUT1=IN1&IN2&IN2|IN4^IN5|IN6; Note that they are 29 characters on the string and the maximum allowed is 24. b) OUT1=IN1&in2; Note that the logic is case sensitive. All characters must be in capital letters. Error Code: "Non valid operand."...

  • Page 36: Example Of Applications

    DC302 – Operation and Maintenance, Instruction Manual OUT1=RS11(IN15,IN2); Note that the first argument is not allowed. Error Code: "Second Argument not valid." a) OUT1=CTD01(IN1,!IN2); Note that the arguments are necessarily simple variables and not functions. b) OUT1=RS11(IN1,IN20); Note that the second argument is not allowed.
  • Page 37 Configuration 2) In the following application we have the control of steps to operate an electro-mechanical balance, that weights phosphatic stone . The weight process is done by boat-load, the system executes one full weight cycle each interval time of 20 seconds. See the following figure: M1 e M3 - Motors for the conveyors C2 e C4 - Limit Switches LSH - High Level Sensor...
  • Page 38 DC302 – Operation and Maintenance, Instruction Manual Note: This new position will be detected by C2 and after 5 seconds, the bucket will have to return to initial position, which will be detected by C4. After the bucket returns to the initial position, a new weight cycle begins.
  • Page 39 Configuration 3.23...

  • Page 40: Section 4 - Maintenance Procedures

    Section 4 MAINTENANCE PROCEDURES General SMAR DC302 Fieldbus Remote I/O are extensively tested and inspected before delivery to the end user. Nevertheless, during their design and development, consideration was given to the possibility of repairs by the end user, if necessary.

  • Page 41: Firmware Update Procedure

    DC302- Operation and Maintenance Instruction Manual Firmware Update Procedure For firmware update of the DC302 equipment see FDI302Plus manual, visit website Smar: www.smar.com NOTA The FDI302Plus should be connected to the CN4 connector Boards Interchangeability Main and I/O boards can be changed independently.

  • Page 42: Spare Parts

    Maintenance Procedures Figure 4.1 – DC Exploded view Spare Parts SPARE PARTS NAME POSITION CODE Housing 400 - 1371 Housing Cover 400 - 1372 I/O Board (GLL 1469) 400 - 1373 Font Board (GLL 1468) 400 - 1374 Main board (GLL 1467) 400 - 1375 2-way terminal numbered 6A to 6B 400 - 1376...
  • Page 43 DC302- Operation and Maintenance Instruction Manual...

  • Page 44: Section 5 - Technical Specifications

    European accident prevention requirements. Using DIN rail (TS35-DIN EN 50022 or TS32-DIN EN50035 or TS15-DIN Mounting EN50045. DC302 Inputs Description-Inputs The input module senses the DC input voltage and converts it into a True (ON) or False (OFF) logic signal.

  • Page 45: Dc302 Open Collector Outputs

    DC302- Operation and Maintenance Instruction Manual DC302 Open Collector Outputs Description – Outputs The outputs are designed with open collector NPN transistors that are able to drive relays, solenoids and other DC loads with up to 0.5 A per output. All channels within a group share the same ground whereas groups are isolated from each other and the Fieldbus network.

  • Page 46: Appendix A - Srf - Service Request Form

    Company: _____________________________________________________________________________________________________ Contact: _______________________________________________________________________________________________________ Title: __________________________________________________________________________________________________________ Section: _______________________________________________________________________________________________________ Phone: _________ _________________________ _________ _________________________ Extension: ___________________ E-mail: ________________________________________________________________________ Date: ______/ ______/ __________ For warranty or non-warranty repair, please contact your representative. Further information about address and contacts can be found on www.smar.com/contactus.asp.

  • Page 47: Returning Materials

    DC302- Operation and Maintenance Instruction Manual Returning Materials If necessary to return the DC302 to SMAR, simply contact our office, informing the defective instrument serial number, and return it to our factory. In order to speed up analysis and solution of the problem, the defective item should be returned with a description of the failure observed, with as much details as possible.

  • Page 48: Appendix B - Smar Warranty Certificate

    Appendix B SMAR WARRANTY CERTIFICATE SMAR guarantees its products for a period of 24 (twenty four) months, starting on the day of issuance of the invoice. The guarantee is valid regardless of the day that the product was installed. SMAR products are guaranteed against any defect originating from manufacturing, mounting,...
  • Page 49 14. It is the customer’s responsibility to clean and decontaminate products and accessories prior to shipping them for repair, and SMAR and its dealer reserve themselves the right to refuse the service in cases not compliant to those conditions. It is the customer’s responsibility to tell SMAR and its dealer when the product was utilized in applications that contaminate the equipment with harmful products during its handling and repair.
