  • Page 1 db ServerRack V2 (Zero-U) Installation Manual...
  • Page 2: Table Of Contents

    BioLock (Option I) ....................21 Install the 2   Install the Electro-Mechanical Lock (Option II) ................... 21   Connecting Power to the Control Unit .................... 23   Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 2 of 24...
  • Page 3: Determining Which Lock Pawl To Use

    Southco Global Corporate Headquarters Customer Service & Technical Support Ctr. Concordville, PA – USA Tel: (610) 459-4000 Email: info@southco.com Figure 1 Figure 2 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 3 of 24...
  • Page 4 It is preferable to mount the Control Unit near the top of the rack, to ease the running of cables, however this isn't absolutely necessary. Figure 3 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 4 of 24...
  • Page 5: Mounting The Door Interface Box

    (Using neat alcohol to clean the surface is highly recommended. Allow drying time before proceeding.) • Remove the protective cover from the double-sided high bond tape located along the edge of the Door Interface Box. Figure 4 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 5 of 24...
  • Page 6: Mounting The Door Interface Box - Step 2

    * Open slot for lock. 25mm x 150mm (typical) Figure 5 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 6 of 24...
  • Page 7: Mounting The Door Interface Box - Step 3

    Attach the finger-sensor assembly into the back of the door lock as show in Figure 7. Ensure that the angle of the finger-sensor assembly and the angle of the door lock are as shown in Figure 7. Figure 6 Figure 7 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 7 of 24...
  • Page 8: Mounting The Door Interface Box - Step 4

    Situate the lock on the outside of the cabinet door, so that the ribbon cable attached to the finger-sensor assembly is at the top of the locking opening. (See Figure 8) Figure 8 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 8 of 24...
  • Page 9: Mounting The Door Interface Box - Step 5

    Attach the lock wire coming out of the Door Interface Box to the back of the lock as shown in Figure 8. The wire will only plug in one way. Figure 9 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 9 of 24...
  • Page 10: Mount The Tie Down Pads To The Door And Cabinet

    Ensure that the door surface is clean and free from any debris. (Using neat alcohol to clean the surface is highly recommended. Allow drying time before proceeding.) • Remove the protective cover from each Tie Down Pad and situate as shown in Figure 10. Figure 10 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 10 of 24...
  • Page 11: Digitus Biometrics, Inc. 2011

    Route the supplied CAT5 cable as show in Figure 11. Secure the CAT5 cable to the Tie Down Pads using the supplied cable-ties. • Connect the CAT5 cable to the Door Interface Box Figure 11 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 11 of 24...
  • Page 12: Connect The Cat5 Cable To The Control Unit

    Connect the CAT5 cable to the port labeled "DOOR 1" on the back of the Control Unit as shown in Figure 12. DO NOT CONNECT THE "DOOR INTERFACE BOX" CABLE TO THE PORT LABELED "NETWORK" Figure 12 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 12 of 24...
  • Page 13: Digitus Biometrics, Inc. 2011

    "NETWORK" on the back of the Control Unit as shown in Figure 13. DO NOT CONNECT THE "NETWORK" CABLE TO THE PORTS LABELED "DOOR 1" OR "DOOR 2" Figure 13 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 13 of 24...
  • Page 14: Installing The Pawl On The Door Lock

    The pawl is installed as shown in Figure 14. Pay particular attention to the Rotation Limiter. This is installed as shown depending on whether you have a right on left hand opening door. Figure 14 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 14 of 24...
  • Page 15: Using The Tamper Switch Inputs

    To use one of the Tamper Switched follow the example show in Figure 16. The example connects to pins 1 & 2, additional Tamper connected Switched can be to any of the remaining pairs of pins. Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 15 of 24...
  • Page 16: Digitus Biometrics, Inc. 2011

    Figure 16 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 16 of 24...
  • Page 17: Using The Door Contact Inputs

    To use one of the Door Contacts follow the example show in Figure 18. The example connects to pins 9 & 10, an additional Door Contact can be connected to pins 11 & 12. Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 17 of 24...
  • Page 18: Digitus Biometrics, Inc. 2011

    Figure 18 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 18 of 24...
  • Page 19: Using The Alarm Output

    • NO is the Normally Open relay contact • GND can be used in conjunction with 12V to provide a 12 Volt supply to an external device. Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 19 of 24...
  • Page 20: Using The Wiegand Output

    Figure 20a Figure 20b • D1 is Data 1 of the Wiegand Output. • D0 is Data 0 of the Wiegand Output. • GND is the Wiegand Ground Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 20 of 24...
  • Page 21: Using The Door 2 Output

    Mount the lock as shown in Figure 9, then attached the supplied cable, Figure 23 DO NOT CONNECT THE "DOOR INTERFACE BOX" CABLE TO THE PORT LABELED "NETWORK" Figure 22 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 21 of 24...
  • Page 22: Digitus Biometrics, Inc. 2011

    Figure 23 Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 22 of 24...
  • Page 23: Connecting Power To The Control Unit

    IF THE POWER SUPPLY IS WIRED BACKWARDS, THE CONTROL UNIT WILL NOT POWER UP. THE UNIT HAS PROTECTION TO PREVENT IT FROM BEING DAMAGED IF WIRED INCORRECTLY. Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 23 of 24...
  • Page 24: Model: Db Serverrack V2 Zero-U Digitus Biometrics, Inc

    Digitus Biometrics, Inc. 2 East Bryan Street, Ste 502 Savannah, GA 31401 USA Phone: 912-231-8175 Fax: 912.629.9478 www.digitus-biometrics.com support@digitus-biometrics.com Specifications subject to change without notice. Model: db ServerRack V2 Zero-U Digitus Biometrics, Inc. 2011 Page 24 of 24...
