Restek Click-On Inline Super Clean Purifier Instructions For Use

PHYSICAL SPECIFICATIONS:
• Max. inlet pressure: 160 psi (11 bar).
• Maximum flow: 25 L/min.
• Operating temperature: -40° C to 65° C.
• Dimensions: 270 (L) x 32 mm (OD).
• Gas outlet purity: > 6.0 grade (purity level > 99.9999 %);
rest impurities < 0.1 ppm at flow of 2 L/min.

Ordering Information

Click-On Inline Super Clean® Purifier
Click-On Inline Super Clean® Traps and Connector Kits
22456 Carrier Gas Purification Kit, 1 / " Stainless Steel
8
22457
Carrier Gas Purification Kit, 1 / " Brass
8
22458 Carrier Gas Purification Kit, 1 / " Stainless Steel
4
22459 1
Carrier Gas Purification Kit, / " Brass
4
22460 Fuel Gas Purification Kit, 1 / " Stainless Steel
8
22461 Fuel Gas Purification Kit, 1 / " Brass
8
22462 1
Fuel Gas Purification Kit, / " Stainless Steel
4
22463 Fuel Gas Purification Kit, 1 / " Brass
4
Click-On Inline Super Clean® Replacement Traps
22464 Click-On Super Clean® Replacement Triple Trap
22465 Click-On Super Clean® Replacement Fuel Gas Trap
Click-On Inline Super Clean® Ultra-High Capacity Traps
22466
Ultra-High Capacity Hydrocarbon Trap
22467 Ultra-High Capacity Moisture Trap
22468 Ultra-High Capacity Oxygen Trap
Helium-Specific Click-On Inline Super Clean® Traps and Kits
22469 Helium-Specific Carrier Gas Cleaning Kit, 1 / " Stainless Steel
8
22470
Helium-Specific Carrier Gas Cleaning Kit, 1 / " Brass
8
22471 Helium-Specific Carrier Gas Cleaning Kit, 1 / " Stainless Steel
4
22472 Helium-Specific Carrier Gas Cleaning Kit, 1 / " Brass
4
22473
Helium-Specific Replacement Triple Trap
Click-On Inline Super Clean® Indicating Cartridge
22474 Click-On Inline Super Clean® Indicating Cartridge
Click-On Inline Super-Clean® Connectors
22475 1 / " Brass Click-On Inline Super Clean® Connectors (2-pk.)
8
22476 1 / " Stainless Steel Click-On Inline Super Clean® Connectors (2-pk.)
8
22477
1 / " Brass Click-On Inline Super Clean® Connectors (2-pk.)
4
22478 1 / " Stainless Steel Click-On Inline Super Clean® Connectors (2-pk.)
4
Click-On Inline Super Clean® Double Connector
22479 Click-On Inline Super Clean® Double Connector
Wall-Mounting Clamps for Click-On Inline Super Clean® Traps
22480 Wall-Mounting Clamps for Click-On Inline Super Clean® Traps
Replacement O-Rings for Click-On Inline Connectors
22481 Replacement O-Rings for Click-On Connectors
Questions about this or any other Restek® product?
Contact us or your local Restek® representative
(www.restek.com/contact-us).
Restek® patents and trademarks are the property of Restek Corporation. (See www.restek.com/
Patents-Trademarks for full list.) Other trademarks in Restek® literature or on its website are the
property of their respective owners. Restek® registered trademarksare registered in the U.S. and
may also be registered in other countries.
© 2016 Restek Corporation.
All rights reserved.
www.restek.com
#204-08-021 Rev. date: 02/16
Click-On Inline
Super Clean® Purifier
Instructions for Use
Patent pending
1024083
