COMPREHENSIVE USER GUIDE
FAAST XS 7100X
Fire Alarm Aspiration Sensing Technology
SPECIFICATIONS
Electrical Characteristics
External Supply Voltage
Remote Reset Time
Power Reset
Average Operating Current @24V*
Alarm Current @24V*
*Additional Current Requirements
Relay Contact Ratings
Environmental Ratings
Operating Temperature
Sampled Air Temperature
Humidity
IP Rating
Coverage Area
Ambient Air Movement

TABLE OF CONTENTS

Items Included With Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connecting to FAAST XS (7100X) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connecting to FAAST XS via USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connecting to FAAST XS via Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Pipe Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Physical Unit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Particulate Level Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Alarm Level Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Air Flow Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Fault Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
LCD User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Configuration Menu Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
LCD Menu Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Language Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Backlight Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Contrast Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Message Log Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Set Time Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Special mode screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Initialization Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Baselining Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Firmware Upgrade Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Modes of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Configuration Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Fan Speed Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
18 - 30 VDC
External monitor must be pulled low
for a minimum of 100 msec
1 sec
Fan High - 200mA, 4.8W at 24V
Fan Med - 151mA, 3.7W at 24V
Fan Low - 120mA, 2.9W at 24V
Fan High - 230mA, 5.6W at 24V
Fan Med - 172mA, 4.2W at 24V
Fan Low - 142mA, 3.5W at 24V
LCD on - 10mA, 0.24W at 24V
Ethernet enabled - 20mA, 0.48W at 24V
Serial Modbus enabled - 0.48V at 24V
Audible Indicator activated - 20mA, 0.48W at 24V
3.0A @ 30VDC, 0.5A @125VAC
32°F (0°C) to 100°F (38°C)
Factory tested to 131°F (55°C)
-4°F (-20°C) to 140°F (160°C)
10 to 95% non-condensing
IP30
5,000 sq.ft. (464 sq.m.)
0 - 4,000 ft/min (0 - 1,219.2 m/min)
®
Exterior Dimensions
Height
Width
Depth
Cable Access
Wire Gauge
Pipe Size
Max Single Pipe Length
Shipping Weight
Net Weight
Alarm and Relay Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Audible Indicator Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Failure of Configuration validation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Power glitch during configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Sounder Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Reset Airflow Baselines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Isolation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Disable Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Acclimate Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Day, Night And Weekend Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Data Trend Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Message Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
EXSernal Monitor/Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Ethernet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
USB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Pipe Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Web Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Email Notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Canned Smoke Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Laser Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1
11.0 in (279mm)
9.0 in (229mm)
6.25 in (15.9mm)
3 1-inch (2.54 cm)
cable entry holes on top
and back of the unit.
12 Ga.
½ or ¾ in Nom.
(20 or 25mm Nom.)
180 ft. (54.8 m)
* all designs must be
verified within PipeIQ
software
8.8 lbs (3.99 kg)
6.57 lbs (2.98 kg)
ASUG80001
