Reportage Link System packages Studio-Transmitter Links Auxiliary Link System Released February - 2005 Sao Paulo SUMMER05-SRFStrider-161004A Sinteck Calle Sotavento 3-13 Rua dos Bolivianos 578 Sistemas Valencia - España Sao Paulo - Brasil Electrónicos +34 961777172 +55 11 61438640 Sinteck Sistemas Eletrônicos Ltda.
Page 3
Gracias por la confianza depositada en nosotros por haber elegido un producto Sinteck. Strider link surge a partir de la estrategia Sinteck en llegar cada vez más cerca de las necesidades, anhelos y expectativas de nuestros clientes. Sorprender, innovar, introducir continuas mejorias en el diseño, perfección, tecnología y confiabilidad son algunos de nuestros propósitos que permedian cada etapa de la evolución y...
Page 4
In this case can be requested to user to take the necessary measures. Sinteck Next t reserves to the right to modify the design and/or the technical specifications of the product and this manual without notice. Strider Link Series P/04 SRFStrider-161004A-REV.A...
Page 5
2) If your dealer is not able to assist you, contact Sinteck Next and report the problem. If it is decided to return the unit to the factory, Sinteck Next will mail you a regular authorization with all the necessary instructions to send back the goods.
(in the Strider Multiplexx - all cards installed) The lightweight universal mains input design ensures a high reliability efficient design compatabile with any mains system in the world. Strider Link Series 01/P/06 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 7
Signal-to-noise ratio: 70dB or better (Typically 75dB) Referenced to 100% modulation Operating temperature: -10 C to +70 C Emission: 110F3 (no subcarrier) 110F9 (with 26kHz control subcarrier) 230F9 (with 67kHz program subcarrier) Strider Link Series 01/P/07 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 8
85 to 265VAC 47-63Hz switched power supply system, full-range 48W. 12VDC input socket for mobile operation (Minimum 10,8V and maximum 14V) Dimensions: 1 rack unit (44,45mm) high 483mm wide 12,5 cm deep Shipping Weight: 3,5kg Strider Link Series 01/P/08 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 9
85 to 265VAC 47-63Hz switched power supply system, full-range 48W. 12VDC input socket for mobile operation (Minimum 10,8V and maximum 14V) Dimensions: 1 rack unit (44,45mm) high 483mm wide 12,5 cm deep Shipping Weight: 3,5kg Strider Link Series 01/P/09 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 10
85 to 265VAC 47-63Hz switched power supply system, full-range 48W. 12VDC input socket for mobile operation (Minimum 10,8V and maximum 14V) Dimensions: 1 rack unit (44,45mm) high 483mm wide 12,5 cm deep Shipping Weight: 3,5kg Strider Link Series 01/P/10 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 11
85 to 265VAC 47-63Hz switched power supply system, full-range 48W. 12VDC input socket for mobile operation (Minimum 10,8V and maximum 14V) Dimensions: 1 rack unit (44,45mm) high 483mm wide 12,5 cm deep Shipping Weight: 3,5kg Strider Link Series 01/P/11 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 12
(2 XLR Connector, 1 Left Signal out, 1 Right Signal out) Stereo demodulated separation: 40dB or better. Power Source: 100/120/220/240VAC 50Hz - 60Hz 15W Max Dimensions: 1 rack unit (44,45mm) 483mm wide 125mm deep Shipping Weight: 2,5kg domestic Strider Link Series 01/P/12 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 13
The main RF output power module contains Beryllium Oxide. 1.4.7 Other Safety Considerations Do not operate this equipment in the presence of flammable gases, fumes or liquids Do not expose this equipment to rain or water. Strider Link Series 01/P/13 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 14
2-1 Front and rear panels - Strider Transmitter Link Strider Link Series 02/P/14 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 15
2-2 Front and rear panels - Strider Receiver Link Strider Link Series 02/P/15 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 16
2-2 Block Diagram - Strider Transmitter Link Strider Link Series 02/P/16 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 17
2-2 Block Diagram - Strider Receiver Link Strider Link Series 02/P/17 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 18
10 - AC socket - input AC 11 - Power supply board - Fuse 2 amps. 12 - Switch ON-OFF 13 - Status Leds 14 - Liquid Crystal Display 15 - Select Buttons Strider Link Series 02/P/18 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 19
115V / 15-0-15V / 1amp.) 12 - AC Power switch 13 - Status Leds 14 - Liquid Crystal Display 15 - Select Buttons 16 - Cavity Filter and Preselector RF Filter Strider Link Series 02/P/19 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 20
The Metering and Status circuitry on the audio, Power Supply and RF sections conditions the various system parameter samples for accurate meter indications, and drives the status LEDs on the front panel. Strider Link Series 03/P/20 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 21
15kHz. Is most important to place this card when is installed the stereo generator card, because the high frequencies is not important to transmit in this case. Strider Link Series 03/P/21 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 22
The Triple-C exhibits superior front end performance in the presence of extremely strong RF fields, as it uses modules from the time-proven Sinteck Next. Both systems are selectable to support mono or composite operation. The receivers are single in construction and operation, just one PC board, and the system description given below follows the signal flow in the block diagrams referenced above.
Page 23
This function is possible to connect auxiliary systems in the receiver, that will change the state when the RF signal in the antenna is more than 10% of the maximum signal. This parameter can be viewed through the LCD on the front panel. Strider Link Series 03/P/23 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 24
Strider Transmitter Link. 3-2-2 Using Switch on the Strider Transmitter Link by putting the power switch on the position “ON’. The following message must be viewed: SINTECK SINTECK UHF TRANSMITTER UHF TRANSMITTER Strider Link Series 03/P/24 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 25
Now, the Strider Transmitter Link will find if is installed or not the Digital 15kHz Lowpass Filter Card and the next message will be: FILTER 8TH 15KHZ FILTER 8TH 15KHZ FILTER 8TH 15KHZ FILTER 8TH 15KHZ INSTALLED INSTALLED NOT INSTALLED NOT INSTALLED Strider Link Series 03/P/25 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 26
Strider Link Series 03/P/26 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 27
First, the button " SEL " should be pressed, until that the message in LCD is " CONTRAST ADJUST ". Note that every time that any button is pressed a beep sounds, this is the feedback that the button was worked. Strider Link Series 03/P/27 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 28
“UP” or “DOWN”on the front panel, once the message “CONTRASTADJUST” is shown. CONTRAST ADJUST CONTRAST ADJUST LEVEL~ 05 LEVEL~ 05 CONTRAST ADJUST CONTRAST ADJUST LEVEL~ 05 LEVEL~ 05 CONTRAST ADJUST CONTRAST ADJUST LEVEL~ 05 LEVEL~ 05 Strider Link Series 03/P/28 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 29
100mW for touch, through the buttons " UP " and " DOWN " is possible to adjust the power from 0 up to 8W and vice-versa, from 8W to 0W. The following illustrations exemplify this power adjustment: F~ÛÛÛÛÛÛÛÛ F~ÛÛÛÛÛÛ F~ÛÛÛÛ F~ÛÛ Strider Link Series 03/P/29 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 30
110% of modulation, but note that in others channels must not have any other users. The “CLP” corresponds to “CLIPPER”. REMARK: NEVER let the transmitter modules more than “MAX” in any case. Strider Link Series 03/P/30 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 31
REMARK: NEVER let the transmitter modules more than “MAX” in any case. When installed the AUDIO PROCESSOR CARD the maximum modulation will be 75%. If this card is disabled, then the modulation level can pass of this limit like shows the illustration. Strider Link Series 03/P/31 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 32
MPX external and the view will be like the following illustration: INT. ~EXT. To return to the original position or “INT” the button “DOWN” must to be pressed, like the shown the illustration: ~INT. EXT. Strider Link Series 03/P/32 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 33
Note that in the front panel there is 4 Status Leds. The last led corresponds to the Stereo ON-OFF. Turning the button “UP” and “DOWN” to stereo “ON” or “OFF” this LED indicates if the Internal MPX is operating or not, like shown in this illustration: Strider Link Series 03/P/33 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 34
CARD is bypassed (DISABLE). Note that audio level in this moment is not controlled by the audio processor and must be accompanied for the user. The previous menu “CHANNELS LEFT&RIGHT” will to show non-controlled audio level measures. Strider Link Series 03/P/34 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 35
“CONFIG HOLD” is enabled. VBIAS: VBIAS: 3,44V 3,44V This function is most important for who needs a CONFIG HOLD: CONFIG HOLD: system that nobody has access to change the parameters (channels, RF power, etc.) Strider Link Series 03/P/35 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 36
Note that in the front panel exists a led to show if the RF power is operating, in this safety mode, this led will be turned off. This view, like the “PLL UNLOCK” are only “readings”and therefore cannot be modified. Strider Link Series 03/P/36 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 37
100% like explained in this section. STATUS LEDS: 1- Power “ON” 2- PLL locked “OK” 3- RF power out “OK” 4- Stereo actived FREQ: 454,25 MHZ FREQ: 454,25 MHZ CHANNEL 17 CHANNEL 17 Strider Link Series 03/P/37 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 38
The following message must be viewed: SINTECK SINTECK UHF RECEIVER UHF RECEIVER Note that this moment the first LED is turned on, indicating the Strider Receiver link has ” all supplies voltages “OK Strider Link Series 03/P/38 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 39
RF-in is less than “MAX” if the Strider Transmitter link is operating near from this receiver. Strider Link Series 03/P/39 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
Page 40
First, the button " SEL " should be pressed, until that the message in LCD is " CONTRAST ADJUST ". Note that every time that any button is pressed a beep sounds, this is the feedback that the button was worked. Strider Link Series 03/P/40 SRFStrider-161004A-REV.A Sinteck Sistemas Eletrônicos Ltda.
