Summary of Contents for Vicko LD-629E-70
- Page 1 Electric Vacuum Cleaner Cyclonic Technology Model No: LD-629E-70 Ref. No: 863-8078 INSTRUCTIONS MANUAL • High Performance and Energy Saving • Advanced Cyclone Technology • High efficiency • Low Noise • Dust Canister 2 Liters • Multi-level Filtering System with high...
- Page 2 ATTENTION! - IMPORTANT SAFEGUARDS This appliance is designed for private, domestic use only. No responsibility is accepted for damage resulting from use non-compatible with the instructions. The appliance is not intended to be used in the following applications, and the guarantee will not apply for: ...
- Page 3 25. Do not use while you are in contact with water. 26. Do not immerse the appliance in water or any other liquids. 27. Do not touch an appliance that has fallen into water. Just pull the plug off. 28. Never use the appliance to clean liquids. 29.
-
Page 4: Caution - Risk Of Electric Shock
CAUTION! Read all the instructions carefully before you use the appliance and keep them for future use. When passing on the appliance to a third person, make sure to include these instructions for use. WARNING! Never use the appliance to clean liquids. WARNING! The appliances are not intended to be operated by means of an external timer or separate remote-control system. -
Page 5: Before Use
BEFORE USE 1. Ensure the packaging of this appliance is disposed of properly as all materials are recyclable. 2. Keep plastic bags away from babies and children. 3. After you remove the device from its packing, clean it with a damp cloth. 4. -
Page 6: Appliance Details
APPLIANCE DETAILS 1. Main body 2. Handle 3. Power switch 4. Speed control regulator 5. Cord rewind button 6. Canister for dust collection 7. “_MAX_” fill indication mark 8. Canister release button 9. Air inlet 10. Hose connector 11. Hose 12. - Page 7 ASSEMBLY Please follow the instructions below in order to assembly the appliance. ATTENTION: Always make sure the appliance is unplugged from the power supply before starting to assemble or disassemble it. Fitting the canister: 1. Hold the canister (6) by the handle and place it in its position into the main unit.
- Page 8 Fitting the flexible hose: 1. Insert the hose connector (10) into air inlet (9) and lock it by clockwise rotation. Removing the flexible hose: 1. Remove the plug from the power socket. 2. Hold the hose connector (10), rotate anticlockwise and pull it firmly from the air inlet (9) to release it.
- Page 9 INSTRUCTIONS Please follow the instructions below in order to use the appliance. 1. When all parts are in installed correct in place, pull the power cord and connect the appliance to the power supply. CAUTION: The yellow point on the cable shows the ideal cable length. Never exceed the red point.
- Page 10 6. The appliance is equipped with a 2 in 1 Brush and Crevice tool accessory (20). You can use this accessory by attaching it directly on the hose or the metal extension tube instead of the floor brush. Brush tool: Crevice tool (nozzle): For cleaning curtains, For cleaning radiators, corners,...
- Page 11 Useful tips: Before using the appliance, make sure to remove from the area you will clean all large or sharp objects that can damage the hose and canister. If an object is blocking the air in the hose or floor brush nozzle, turn-off the appliance, disconnect it from the power supply and remove the object before using the appliance again.
-
Page 12: Cleaning & Maintenance
CLEANING / MAINTENANCE ATTENTION: Unplug the appliance and let it cool down before you clean it. Always make sure the appliance is unplugged from the power supply before starting any procedure of cleaning it. Clean the appliance each time after using it. Main unit cleaning: Clean the external surface of the appliance with a damp cloth. - Page 13 Cleaning the Filters: 1. Press the canister release button and take out the canister. 2. Take out the foam inlet filter and also the HEPA inlet filter. 3. Open the air outlet grid on the back side of the appliance and take out the HEPA outlet filter.
- Page 14 NOTE: Whenever you use the appliance the filters are getting dirty. This is normal and does not affect the function of the appliance. If the filters are too dirty and the appliance does not work at 100%, only then you should remove and wash the filters under running tap water.
-
Page 15: Overheat Protection
TRANSPORT At the top of the main body there is a handle with which you can easily carry the appliance. OVERHEAT PROTECTION This appliance has a built in overheat protection system, that automatically switches the appliance off in case of overheating. If this occurs, proceed as follows: 1. - Page 16 RECYCLING OF USED ELECTRICAL OR ELECTRONIC APPLIANCES This marking indicates that this product should not be disposed with other household wastes throughout EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.
-
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS Model: LD-629E-70 Ref. No: 863-8078 Energy efficiency class: Power: 700W Rating: 220-240V Frequency: 50/60Hz • High Performance and Energy Saving Features: Energy saving and high performance evaluation according to European Energy Labeling • Advanced Cyclone Technology Cyclonic technology (Double Cyclone) for perfect dust and air separation. - Page 18 Product Fiche According to Commission Delegated Regulation (EU) No 665/2013 Supplier: LD-629E-70 Model No.: Energy efficiency class: 24,7 kWh/year Annual energy Indicative annual energy consumption consumption (kWh per year), based on 50 cleaning (kWh/year): tasks. Actual annual energy consumption will depend on how the appliance is used.
