qua Phone QZ Settings Manual

Setting Guide
Thank you for buying the "Qua phone QZ" (simply called the "product" from here on).
This manual describes the settings and precautions for using the product.
For explanations of basic functions, refer to "Basic Manual".
■ Basic Operation ■ au-mail
Describes the basic operations. Make initial settings for au-mail etc.
■ Initial Settings ■ Making a Call
Make initial settings when you turn Describes how to make a call.
the power on for the first time.
■ Receiving a Call
■ au Initial Settings
Describes how to make a call.
Set au ID.
■ Setting Display
■ au Basic Home Notification
Set the screen brightness and
Settings backlight time of the screen.
■ Setting Wi-Fi
Make the setting to display notifications
(badges) on icons on au Basic Home.
Describes how to connect Wi-Fi
Company names and product names referred to in this manual are trademarks
or registered trademarks of respective companies.
The TM, ® marks may be omitted in this manual.
Illustrations and screens shown in this manual may look different from
the actual illustrations and screens.
In some cases, minor details or a part of a screen may be omitted.
Basic Operation
For explanations of basic functions, refer to "Basic Manual".
《Home screen (au Basic Home)》
FPower button
Turning the Power On
Press and hold F
(Power button) until the
incoming light turns on.
[ (Chrome)] Chrome icon
Use Google Chrome to view Web pages.
Navigation bar
C (BACK):
H (HOME):
N (RECENTS): Show recently-used apps. Long-touching this button activates
Display
Touch directly with your finger to operate.
Tap/Double-tap Long-touch
Lightly touch a screen Keep touching an item,
and then immediately button, etc.
release your finger.
Tapping a screen twice
in the same position is
called double-tap.
Flick Drag
Touch the screen and While lightly touching
flick up/down/left/right. the screen, trace to the
desired position.
■ Character entry
Use the software keyboard for entering characters.
Tap the entry field in the character entry screen when registering contacts, creating mail, etc. to display the
software keyboard.
Tap a key to enter character.
Switching character input method
Character entry screen (12 keys layout) → long-touch "
Input Settings] → [Keyboard layout] → flick the keyboard to the left/right to select the desired character input
method.
《Character entry screen
(12 keys layout)》
Flick input
Tap a key to display characters like the
right screen that can be input by flick input.
Flick to the direction of the character to
enter.
• To enter same characters repeatedly
when not in flick input mode, tap " " to
shift to the right.
■
Setting Silent mode
• Slide down the status bar → [ / ] → to set the Silent mode to ON/OFF.
• To change the Silent mode type, from the home screen → [ 基本機能 (Basic Function)] → [Settings] → [Sound] → [Silent
mode] → [Silent mode type] → [Vibrate]/[Mute]/[Drive].
■ Setting the App Permissions
The first time you launch an app/function that accesses the functions or information of the product, a confirmation
screen for requesting access permission appears. If the confirmation screen appears, confirm the content and tap
"DENY"/"ALLOW".
• If you do not permit, apps/function may not be activated or use of function may be restricted.
• For some apps/functions, an explanation screen for the permission appears. A confirmation screen may appear in
several times and its content may vary. Confirm the content and follow the on-screen instructions.
• In this manual, description of such confirmation screen may be omitted.
•
■ Viewing/Playing Data
Describes how to view/play still
images or video data.
■ Transferring data from au
Settings Menu
Describes how to restore/back
up data from/to your previously
used phone to/from this product
using microSD card or the au
server.
®
® network.
March 2018, 1st Edition
Sold by: KDDI CORPORATION
OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: KYOCERA Corporation
Displaying home
screen
From the Start
screen, slide the
screen.
Return to the previous screen. When "
character entry screen, tap this button to hide the keyboard or
menu.
Display the home screen. Long-touching this button activates
the Google Assistant.
the multi-window during apps activation. When the multi-window
activates, this button is changed to " ". Long-touching this
button deactivates the multi-window.
Slide/Swipe
While lightly touching
the screen, trace to the
desired direction.
Zoom-in/Zoom-out
While touching the screen
with two fingers, move the
fingers away and closer
to each other.
" → drag to the direction of " " → [Google Japanese
《Character entry screen 《Character entry screen
(QWERTY)》 (Godan Keyboard)》
Displaying input candidates for flick
input
To enter "B", flick to the left.
* To enter "A", release the finger.
Character entry mode switch key
《Character entry screen
(12 keys layout)》
Tap to switch character type.
Initial Settings
When you turn on the product for the first time after purchasing the product, follow the on-screen instructions to
set language, functions and services.
Introduction
■ Setting up Google account
Set up Google account to use Google apps such as "Gmail", "Play Store", "Duo".
Setting items are as below (besides the items below, register "First name" and "Last name").
User name
Password
1
Tap "日本語 （日本） "
to select "English"
→"United States"
6
《Start screen》
Enter "First
name" and "Last
name" → [NEXT] → Enter
the date of birth and
gender → [NEXT]
" appears in the
11
Check the
contents, then
[NEXT]
16
Set up other
settings as required
→ [ALL SET]
au Initial Settings
By setting au ID, you can use various services provided by au such as "au Kantan Kessai" which allows you to
purchase apps from the auスマートパス (au Smart Pass) or Google Play. Main setting items are as follows.
• If you skip the operation of "au Initial Setting" at the time of purchase, you can set au ID later. In that case, operate
from the home screen → [ 基本機能 (Basic Function)] → [Settings] → [au Settings] → [au Settings Menu] → [au Initial
Setting].
1
Check / Uncheck
[Update] → [GET
STARTED]
6
[ 次へ (Next)]
*1 If you registered au ID in the past, step 3 and 4 are not displayed. Go to step 5.
*2 The security code is a four-digit number written at subscription.
*3 A confirmation screen for requesting access permission will be displayed several times. In this case, do the same as step 7.
*4 When "Select apps" is displayed on "Backed up" field, tap to check the app.
*5 If you stored your data to au server using "Data Storage App", tap "Restore from backup now" to restore the data.
*6 Confirmation screens will be displayed several times, follow the on-screen instructions.
Register your Google account (user ID) and a character string for mail address. You can
register a desired name, but a name already registered by another user cannot be set.
Register password for the Google account.
2 3
Tap [LET'S GO] [Set up as new]
* If you restore a
backup or copy from
a device, select [Copy
your data] and follow
the on-screen instruc-
tions.
7 8
Enter a user Enter a password
name → [NEXT] and reenter the
Checking password for
registration of user
confirmation →
name starts.
[NEXT]
12 13
Select protection Confirm the Google
features → Follow service settings,
the on-screen then [AGREE] →
instructions to [NEXT]
set security and
notification
* If you do not set up,
tap [Not now] →
[SKIP ANYWAY].
17
Check the contents
and mark the check
box, then [NEXT]
* If you do not set up,
tap "NEXT".
2 3
[Sign in] *1 Enter the security
code *2 → [ 次へ (Next)]
7 8
[ALLOW] *3 Check apps to
install *4 → [Next]
4 5
Set up the Wi-Fi ® [Create account]
network to connect
* If you have a Google
as required
account, enter a mail
address or phone
* If you do not set
number → [NEXT].
up, tap [Use mobile
network for setup] →
[CONTINUE].
* If you select [SKIP]
→ [CONTINUE], the
name input screen is
displayed and enter
your name, and then
proceed to step 11.
And follow the on-
screen instructions.
9 10
Confirm the note on Check the
adding the phone
contents, then
number → [YES, I'M
[I AGREE]
IN]
14 15
Confirm the On the Assistant
permission of the setting screen, tap
Google Assistant [GET STARTED]
→ [YES I'M IN] → follow the
* If you do not set up, on-screen
tap [NO THANKS].
instructions →
[DONE]
* If you do not set up,
tap "SKIP".
4 5
Enter the password [ 次へ (Next)]
→ [ 同意して次へ
(Agree)]
9 10
Check items to [Finish] *5*6
configure → [Next]
