Summary of Contents for Paul Cocksedge Studio The Vamp
- Page 1 The Vamp Brand Name: Paul Cocksedge Studio Model Name: The Vamp FCC ID: 2AAU4THEVAMP...
- Page 2 ® QUICK GUIDE...
- Page 3 Use an old speaker in a way you've never used it before. Transform it into a portable Bluetooth® speaker using The Vamp®. You can position The Vamp® anywhere on your speaker. Stick the metal disc provided onto your speaker and The Vamp® will be held magnetically in place.
- Page 4 Micro USB charge port Audio input Speaker connector On/off button LED STATUS Flashing RED Low battery Solid RED Charging LED off Fully charged Flashing RED and BLUE Pairing mode Play (streaming) LED flashes BLUE...
-
Page 5: Get Started
Make sure The Vamp® is fully charged before using. Charge The Vamp® using the USB charge cable provided. Plug the micro USB into The Vamp® and the USB into the USB port of your computer or phone charger. When charging the LED will be a solid red. The LED will go off when fully charged. - Page 6 FIND ANY SPEAKER Any passive speaker can connect to The Vamp®. Some backs of speakers are like this...with speaker or like this...with a wire terminals...
- Page 7 CONNECT THE VAMP® Using the audio cable provided, put the two wires in the speaker terminal holes and put the jack into The Vamp®.
- Page 8 Put the cables from the speaker into the speaker connectors of The Vamp®.
-
Page 9: Play Via Bluetooth
PLAY VIA BLUETOOTH® Make sure The Vamp® is connected to the speaker. Turn The Vamp® on. Wait for a beep. If there is no sound the speaker is not connected properly. Turn off The Vamp® and reconnect the speaker. The Vamp® automatically goes into pairing mode and will search for a device for approx. -
Page 10: Via Cable
PAIR TO A DIFFERENT DEVICE Turn off the Bluetooth® on the previously connected device. The Vamp® will enter pairing mode and repeat steps 1 - 3 using the new device. Please see the Troubleshooting section or visit our website if the Bluetooth®... - Page 11 Car speakers Use a cassette adaptor with 3.5mm jack and plug into The Vamp®. Or directly connect The Vamp® to the car hi-fi with a jack to jack 3.5mm audio cable. Please note: The Vamp® will make these speakers into Bluetooth®...
- Page 12 BE LOUDER CONNECT TWO SPEAKERS Put wires from both speakers into the speaker connectors of The Vamp®.*...
- Page 13 Please note: • This option will reduce the play time. • Connecting two speakers to The Vamp® will not give stereo sound. The output is mono. • Connecting speakers in series is not recommended. • Do not allow the wires to touch.
-
Page 14: Troubleshooting
It will search for a device for 10 mins and automatically reconnect if your device re- enters the Bluetooth® range. If necessary, turn off The Vamp® and your device. Switch both on and reconnect. If there is sound distortion: •... - Page 15 To ensure your personal safety and damage to the product please read the following safety warnings. Do not expose The Vamp® to extreme conditions i.e: extreme hot or cold weather, humid or wet conditions. Do not attempt to disassemble The Vamp® or remove the battery.
- Page 16 Important Regulatory Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
