Doheny's Economical Above Ground Suction Cleaner Manual

Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Inground # 7824
FAST START-UP, SAFELY OPERATE AND EFFICIENTLY CLEAN!
To prevent potential injury and to avoid unnecessary service calls, read this manual carefully and completely.
SAVE THIS INSTRUCTION MANUAL
ATTENTION INSTALLER – THIS MANUAL CONTAINS IMPORTANT INFORMATION ABOUT
THE INSTALLATION, OPERATION, AND SAFE USE OF THESE CLEANERS THAT MUST
BE PROVIDED TO THE END USER OF THIS PRODUCT. FAILURE TO READ AND FOLLOW
ALL INSTRUCTIONS COULD RESULT IN SERIOUS INJURY.
WARNING
SAFETY INSTRUCTIONS - READ PRIOR TO USE.
SUCTION HAZARD - When using the pool cleaner, keep it away from body parts when the cleaner is connected
to suction.
CHILD DROWNING RISK - Adult use only. Never allow children to use the pool cleaner. Do not allow swimmers
in the pool during cleaner operation. Store out of reach of children.
10411 80th Avenue Pleasant Prairie, WI 53158 | Orders and Customer Care: 1-800-574-7665 | Fax: 1-800-323-5932 | Doheny.com
Economical
®
Use of unauthorized replacement parts voids warranty.
Cleaners
Item # 7824 & 7825
Above Ground # 7825

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Economical Above Ground Suction Cleaner and is the answer not in the manual?

Questions and answers

Summary of Contents for Doheny's Economical Above Ground Suction Cleaner

  • Page 1 Economical ® Cleaners Item # 7824 & 7825 Inground # 7824 Above Ground # 7825 FAST START-UP, SAFELY OPERATE AND EFFICIENTLY CLEAN! To prevent potential injury and to avoid unnecessary service calls, read this manual carefully and completely. SAVE THIS INSTRUCTION MANUAL Use of unauthorized replacement parts voids warranty.
  • Page 2 Above Ground and Inground Economical Pool Cleaners Item #’s 7824 & 7825 DESCRIPTION Main Body Outer Extension Pipe Handnut Inner Extension Pipe Thrust Washer Deflector Wheel Footpad Disc IEP Locator Retaining Ring Diaphragm 10411 80th Avenue Pleasant Prairie, WI 53158 | Orders and Customer Care: 1-800-574-7665 | Fax: 1-800-323-5932 | Doheny.com...

  • Page 3: Preparing Your Pool

    Preparing your pool: Assembling & Installing Your Pool Cleaner: Step 1: Check Contents Before you assemble and install your pool cleaner, we strongly recommend you carry out the following steps Remove the cleaner body and all the parts from the to ensure your pool is ready for your cleaner to operate.
  • Page 4 Step 3: Use of the Deflector Wheel Step 4a: Connect Hose Use the deflector wheel if your pool has tight corners Connect sufficient lengths of hose to cover the distance and/or a ladder. The deflector wheel helps guide your from the pool skimmer to the farthest point of your pool, pool cleaner around these obstacles. To fit the deflec- plus one length. See Figure 4. The female (large) hose tor wheel, simply push it over the handnut, until it has cuff is fitted to the pool cleaner. The male (small) hose engaged correctly and rotates freely.

  • Page 5: Step 5: Flow Control Valve

    Step 5: Flow Control Valve The flow control valve is preset between position 3-4. This provides the ideal operating flow in most pools. The flow control valve ensures your pool cleaner re- But if necessary, the flow can be adjusted by using ceives the flow required to ensure optimum perfor- any setting from position 1 through 6 (1=minimum flow, mance.

  • Page 6: Troubleshooting

    TROUBLESHOOTING Due to the individual characteristics of your pool, some adjustment may be required to get the best possible performance from your pool cleaner. The following tips will help you to optimize the performance from your pool cleaner. The following tips will help you to optimize the performance of your cleaner. Problem Solution Pool cleaner does not move...

  • Page 7: Replacing The Diaphragm

    REPLACING THE DIAPHRAGM The diaphragm of your pool cleaner operates at the rate of approximately 360 beats per minute. In the event that it does become worn or damaged and needs to be replaced, somply follow these easy steps: 1. Unscrew the handnut and remove it. Place the extension pipe and the thrust washer off to the side. 2.
  • Page 8 4. Push the inner extension pipe away from you so the tabs go through the holes in the IEP locator. 5. Grasp the other end of the diaphragm (the end furthest away from the inner extension pipe) and pull it away from the pool cleaner body.
  • Page 9 To Install a new diaphragm, simply reverse the process: a. Fit the retaining ring onto the new diaphragm. b. Push the diaphragm onto the inner extension pipe. Make sure it is correctly located and fully engaged. c. Pull the inner extension pipe up through the d.
