- Page 1 Data Capture for Workforce in Motion BaracodaPencil2 - Programming Guide ©Baracoda – July 2010...
-
Page 2: Table Of Contents
SUMMARY SUMMARY ... 2 REVISION HISTORY ... 3 INTRODUCTION ... 4 1/ GENERAL CONFIGURATION ... 5 1.1/ R : ... 5 ESET ALL PARAMETERS 1.2/ E RASE ALL BARCODES IN MEMORY 1.3/ B ARACODA ADVANCED FEATURES 1.4/ R ... 8 EADING 1.5/ O PERATING... -
Page 3: Revision History
Data Capture for Workforce in Motion Revision History... -
Page 4: Introduction
Data Capture for Workforce in Motion Introduction... -
Page 5: 1/ General Configuration
1/ General Configuration 1.1/ Reset all parameters: 1.2/ Erase all barcodes in memory 1.3/ Baracoda advanced features Switch on delay : 2 seconds Reset to factory defaults Empty memory Switch on delay : 0 second (*) Set shutdown timers to infinity... - Page 6 Set shutdown timers to defaults Enable Baracoda header + “No Data loss mode” ON Disable Baracoda header + “No data loss mode” OFF Enable Baracoda header + “No Data loss mode” OFF (*) Timestamp off (*) Timestamp on Data Capture...
- Page 7 Data Capture for Workforce in Motion Set Timestamp End of configuration...
-
Page 8: Reading Mode
Data Capture for Workforce in Motion 1.4/ Reading Mode Trigger (*) -
Page 9: Operating Mode
Data Capture for Workforce in Motion 1.5/ Operating Mode 1.5.1/ Real time mode Enable REAL TIME mode Erases all codes in memory and forces the BaracodaPencil2 in Real time mode. No other setting is changed. Enable Real Time with « No Data Loss » mode Enable Real Time without «... -
Page 10: Real Time - Buffered Data Option
Data Capture for Workforce in Motion Real Time - Buffered data option... - Page 11 Data Capture for Workforce in Motion 1.5.2/ Batch mode BATCH MODE Forces the BaracodaPencil2 in Batch mode. Erases all codes in memory. Upload batch data Upload batch data (with No Data Loss on) Restore last batch data Restore last batch + launch upload...
-
Page 12: The Different Connection Methods
1.6/ The different connection methods Data Capture for Workforce in Motion... -
Page 13: Buzzer And Led Settings
Data Capture for Workforce in Motion 1.7/ Buzzer and Led Settings LED ON (*) LED OFF Good read beep on (*) Good read beep off ACK beep on (*) ACK beep off Beep level volume = HIGH (*) Beep level Volume = LOW... -
Page 14: Bluetooth Commands
Data Capture for Workforce in Motion 1.8/ Bluetooth commands 1.8.1/ Bluetooth name Set BT Name End of config... - Page 15 1.8.2/ Sniff settings Sniff period = 150ms (*) Sniff period = 100ms Sniff period = 200ms Sniff period = 300ms Sniff period = 500ms 1.8.3/ Security (code PIN) settings Disable BT security code Enable BT security code (*) Data Capture for Workforce in Motion...
-
Page 16: Prefix And Suffix
1.9/ Prefix and suffix 1.9.1/ Prefix/suffix Prefix on Suffix on Set prefix Prefix off (*) Suffix off (*) Set suffix End of configuration Data Capture for Workforce in Motion... - Page 17 1.9.2/ Postrefix/postsuffix POST Prefix on POST Suffix on Set postprefix POST Prefix off (*) POST Suffix off (*) Set postsuffix End of configuration Data Capture for Workforce in Motion...
-
Page 18: 2/ Decoder Settings
2/ Decoder settings 2.1/ Symbology default settings 2.2/ Symbology identifier Symbology identifier - AIM - not transmitted (*) Symbology identifier - AIM - transmitted 2.3/ Disable All Symbologies Set Decoder Default Settings Disable all symbologies Enable all symbologies Data Capture for Workforce in Motion... -
Page 19: Set Decoder Barcode Length
2.4/ Set decoder barcode length (Feature enabled for CPU firmware version ≥ 1.09 Set barcode length END of config Data Capture for Workforce in Motion... -
Page 20: Codabar Settings
2.5/ Codabar settings Codabar - not active Codabar - start/stop - not transmitted (*) Codabar - check digit (AIM recommendation) - not used (*) Codabar - check digit (AIM recommendation) - checked and transmitted Codabar - check digit (AIM recommendation) - checked but not transmitted Codabar - barcode length - any length 2.6/ Code 11 Settings Code 11 - not active (*) -
Page 21: Code 39 Settings
Data Capture for Workforce in Motion Code 11 - check digits - checked and transmitted (*) Code 11 - check digits - checked but not transmitted Code 11 - barcode length - any length Code 11 – barcode length – Min = 6 (*) 2.7/ Code 39 settings Code 39 - active (*) Code 39 - not active... -
Page 22: Code 93 Settings
Code 39 - check digit - modulo 43 - checked and transmitted Code 39 - check digit - modulo 43 - checked but not transmitted Code 39 - barcode length - any length (*) 2.8/ Code 93 Settings Code 93 - not active Code 93 - barcode length - any length 2.9/ Code 128 Settings 2.9.1/ General... - Page 23 Data Capture for Workforce in Motion 2.9.2/ EAN 128: Group Separator Enable GS transmission (*) Disable GS transmission Define | as GS...
-
Page 24: Interleaved 2 Of 5 Settings
Enable AIM ID transmission for EAN128 2.10/ Interleaved 2 of 5 Settings Interleaved 2 of 5 - not active Interleaved 2 of 5 - check digit - not used (*) Interleaved 2 of 5 - check digit - mod 10 - checked and transmitted Interleaved 2 of 5 - check digit - mod 10 - checked but not transmitted Interleaved 2 of 5 - barcode length - minimum length = 6 (*) Interleaved 2 of 5 –... -
Page 25: Standard 2 Of 5 Settings
Data Capture for Workforce in Motion MSI Code - check digit - mod 10 - checked but not transmitted MSI Code - check digit - double mod 10 - checked and transmitted MSI Code - check digit - double mod 10 - checked but not transmitted MSI Code - barcode length - any length MSI Code - barcode length - minimum length = 6 (*) 2.12/ Standard 2 of 5 Settings... -
Page 26: Upc/ Ean Settings
Data Capture for Workforce in Motion 3.13/ UPC/ EAN Settings UPC / EAN - active (*) UPC / EAN - not active UPC / EAN - UPC-A and EAN 13 desactivated UPC / EAN - UPC-E desactivated UPC / EAN - EAN-8 desactivated UPC / EAN - check digit - UPC-A and EAN13 - transmitted (*) UPC / EAN - check digit - UPC-A/EAN 13 - not transmitted UPC / EAN - check digit - UPC-E - transmitted (*) - Page 27 UPC / EAN - UPC number system - UPC-E - transmitted (*) UPC / EAN - UPC number system - UPC-E - not transmitted UPC / EAN - re-encoding UPC-A, UPC-E, EAN-8 - UPC-A transmitted as EAN-13 UPC / EAN - re-encoding UPC-A, UPC-E, EAN-8 - UPC-A transmitted as UPC-A (*) UPC / EAN - re-encoding UPC-A, UPC-E, EAN-8 - UPC-E transmitted as UPC-E (*) UPC / EAN - re-encoding UPC-A, UPC-E, EAN-8 - UPC-E transmitted as UPC-A UPC / EAN - re-encoding UPC-A, UPC-E, EAN-8 - EAN-8 transmitted as EAN 8 (*)
-
Page 28: Set Min Or Max Length Option
Data Capture for Workforce in Motion 3.14/ Set min or Max length option... - Page 29 Data Capture for Workforce in Motion Symbology table Header Selected Symbology Start – set min length Start – Set Max length End of config...
-
Page 30: Appendix 1: Ascii Table (A-Z, A-Z, 0-9, Ponctuation, Control Characters)
APPENDIX 1: ASCII Table (A-Z, a-z, 0-9, ponctuation, Control characters) Data Capture for Workforce in Motion... - Page 31 Data Capture for Workforce in Motion...
- Page 32 Data Capture for Workforce in Motion...
- Page 33 Data Capture for Workforce in Motion...
- Page 34 Data Capture for Workforce in Motion...
- Page 35 Data Capture for Workforce in Motion...
- Page 36 Data Capture for Workforce in Motion...
- Page 37 Data Capture for Workforce in Motion...
-
Page 38: Appendix 2
APPENDIX 2 Code 39 Telepen Code 128 Code One EAN/UPC Codabar Code 93 Code 11 ITF 25 Code 16K PDF417 MSI code Anker Code Codablock Plessey Code Straight 2 of 5 (two bar start/stop codes) Straight 2 of 5 (three bar start/stop codes) Code 49 Other Bar code Non Barcode data... - Page 39 No check character or Full ASCII Reader has performed mod 43 check Reader has performed mod 43 check and stripped the check character Reader has performed Full ASCII conversion Full ASCII mode Double density numeric mode Double density numeric followed by full ASCII Full ASCII followed by double density numeric Standard Function code 1 in first character position...
