User Guide for Operating your
LogTag Data Logger
Setting up and configuring your Log Tag for the
first time.
1. Download the software from the LogTag website
provided by the supply company if received)
2. Plug your data logger into the computer
Once printed, this document is no longer controlled
Central and Eastern Sydney PHN is a business division of EIS Health Limited ABN 68 603 815 818
www.cesphn.org.au
www.logtag.com.au
(or upload with the CD
Last updated October 2018
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for LogTag TREX-8
Summary of Contents for LogTag TREX-8
- Page 1 LogTag Data Logger Setting up and configuring your Log Tag for the first time. 1. Download the software from the LogTag website www.logtag.com.au (or upload with the CD provided by the supply company if received) 2. Plug your data logger into the computer...
- Page 2 ‘full’. We recommend that you leave the Number of Readings to Record setting at its maximum. “Record a reading every” is the sample rate. This is how often the Logtag will Sample rate measure and store the temperature. Set this to ‘5 min intervals’ as per the NSW...
- Page 3 Push Button Start If you selected Push Button Start in your LogTag configuration, the logger will now be waiting for you to start it. Press and hold the Start (or Start/Mark) button for about a second until both the red and green LEDs on the front of the logger flash for a few seconds to show that the logger is starting.
- Page 4 3. Connect the data logger to your computer (using the Dock or using the USB depending on your model type) and Open the LogTag Analyzer software (if it doesn’t automatically launch for you). 4. Download the data. If it doesn’t do this automatically – select the ‘Download’ option from the...
- Page 5 5. A box (Figure 1) will briefly appear telling you that the Reader has found your LogTag. The Reader will read the data from your LogTag and save it to your computer to the default location. Once the data has been saved, LogTag Analyzer will automatically open your report.
- Page 6 Analysing the report There are four parts to the report: 1. Report 2. Graph 3. Data 4. Summary By default, the graph will show first. The other sections can be accessed by clicking on the tabs at the bottom of each page. What to look for The easiest way to check if everything is OK is to click on the Report Tab at the bottom of the screen.
- Page 7 Only attach a probe to a LogTag that has a brass attachment point, like the Tag on the left. If none of these is the case in your situation and you are getting error readings, call LogTag on 1300 30 33 34 for assistance. ...
