SRK6AFX, SRK6FIX

52081377 REV 3

OPERATION MANUAL

Battery-powered

Crimping Tool

Read and understand all of the instructions and

safety information in this manual before operating

or servicing this tool.

Serial Number

Español ............... 13

Français .............. 25

8/18

Table of Contents

Need help?

Do you have a question about the SRK6AFX and is the answer not in the manual?

Questions and answers

Summary of Contents for Sherman + Reilly SRK6AFX

Page 1 Español ....13 Français ....25 SRK6AFX, SRK6FIX Battery-powered Crimping Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 52081377 REV 3 © 2018 Sherman + Reilly, Inc. 8/18...
Page 2: Table Of Contents
All specifications are nominal and may change as design munications. Operation of this equipment in a residential improvements occur. Sherman + Reilly, Inc. shall not be liable for area is likely to cause harmful interference in which case damages resulting from misapplication or misuse of its products.
Page 3: Important Safety Information
SRK6AFX and SRK6FIX Battery-powered Crimping Tools IMPORTANT SAFETY INFORMATION SAFETY Wear eye protection when operating ALERT or servicing this tool. SYMBOL Failure to wear eye protection could result in serious eye injury from flying debris or hydraulic oil. This symbol is used to call your attention to hazards or unsafe practices which could result in an injury or property damage.
Page 4 SRK6AFX and SRK6FIX Battery-powered Crimping Tools IMPORTANT SAFETY INFORMATION Do not dispose of batteries in a fire. They will vent Do not allow anything to contact the battery fumes and may explode. terminals. Failure to observe this warning could result in severe •...
Page 5: Identification
SRK6AFX and SRK6FIX Battery-powered Crimping Tools Identification 1. LED Work Light (white) 2. Crimping Head 3. Lanyard Ring 4. Housing 5. Retract Button 6. LED Indictor (red) 7. LCD Screen 8. Battery 9. Trigger SRK6AFX SRK6FIX Specifications SRK6AFX Crimping Tool Length ..........................14.9"...
Page 6: Operation
SRK6AFX and SRK6FIX Battery-powered Crimping Tools Operation • Inspect tool and dies before use. Replace any • Do not use this tool for continuous use. After 30 to worn or damaged parts. A damaged or improp- 40 cycles, allow the tool to cool for 15 minutes.
Page 7: Operation
SRK6AFX and SRK6FIX Battery-powered Crimping Tools Operation (cont’d) Pressure Sensor Crimping Procedure This tool is equipped with a pressure sensor that alerts 1. Insert cable fully into connector. Center the connec- the user of an incomplete crimp. tor between the nibs.
Page 8: Connector Selection
SRK6AFX and SRK6FIX Battery-powered Crimping Tools Connector Selection Tool Range: Copper — 4 AWG to 750 kcmil (except as noted ∆ Aluminum — 6 AWG to 750 kcmil (except as noted This tool is cUL and UL classified for use with the following connector brands:...
Page 9: Lcd Screen
SRK6AFX and SRK6FIX Battery-powered Crimping Tools LCD Screen This tool has an LCD screen, which displays informa- If there is no error code, cycle through the various tion about the tool. Turn on the screen by inserting the displays using the left and right buttons on either side of battery and jogging the tool.
Page 10: Maintenance
SRK6AFX and SRK6FIX Battery-powered Crimping Tools Maintenance Daily Before use: 1. Inspect the tool for wear or damage, such as cracks, Wear eye protection when operating gouges, or chips. or servicing this tool. 2. Inspect the tool for damage or leaks.
Page 11: Troubleshooting
SRK6AFX and SRK6FIX Battery-powered Crimping Tools Troubleshooting Before You Begin 2. Use a nonflammable contact cleaner or pencil 1. Make sure that the battery is charged. Recheck eraser to clean the electrical contacts on the battery the battery after several minutes to make sure the and tool.
Page 12 400 West 33rd Street • Chattanooga, TN 37410 USA Phone 800-251-7780 • 423-756-5300 423-756-2948 www.sherman-reilly.com...
