P162A Wired PIR Motion Detector
User/Installer Handbook
Models covered by this handbook
P162A
Wired Motion Sensor
One of a range of Alert-it Care
:
Alarms available from
UH1118
Alert-it Care Alarms, Atherstone House, Merry Lees
Industrial Estate, LE9 9FE
Made in the
0845 2179951, www.alert-it.co.uk, sales@alert-it.co.uk
UK
Advertisement
Table of Contents
Related Manuals for Alert-it Care Systems P162A
Summary of Contents for Alert-it Care Systems P162A
- Page 1 P162A Wired PIR Motion Detector User/Installer Handbook Models covered by this handbook P162A Wired Motion Sensor One of a range of Alert-it Care Alarms available from UH1118 Alert-it Care Alarms, Atherstone House, Merry Lees Industrial Estate, LE9 9FE Made in the...
- Page 2 Nurse Call system. Nurse Call Connectivity The P162A is supplied with a lead configured for use with any Nurse Call or Remote Annunciator or Telecare (including P117B telephone autodiallers).
- Page 3 Installation Location: Ÿ The unit has a horizontal window covering approximately 1.5 meters (the length of a bed) from a distance of 1.5 meters. It also has a narrow vertical win- dow (±20 cm from the base) at this point. Hence if positioned on the floor pointing at a bedside, at a distance of 1.5-2.5m, it will detect feet descending to the floor, while being immune to body movement in bed.
- Page 4 Operation Arming the unit: Point the key-fob at the unit and press ARM. The red led will flash. You now have 30 seconds to leave the area without triggering the alarm Disarming: Point the key-fob at the unit and press DISARM within 4 seconds of entering the room.
- Page 5 Maintenance Cleaning Use Alert-iT procedure Technique B Wiping with cotton wool pads moistened (compressed until dripping stops) with a mild detergent (0.5% washing up liquid) solution. Battery Remove the bottom screw from the rear panel and gently lever up and slide out to reveal the battery compartment.
- Page 6 UH118 P162 PIR Mobility Detector Wired page 6 of 8...
- Page 7 Safety Instructions and Warnings This symbol indicates there are warnings and precautions associated with the use of this equipment that should be carefully read and understood before using the equipment Ensure that the output cable is routed and secured to avoid the risk of entanglement or strangulation.
- Page 8 This system is certified to the following European Standards 73/23/EEC Low Voltage Safety Directive 89/336/EEC Radio Interference Immunity Permitted radio transmission EN 300 220-1 V2.1.1 (2006-04) EN 50081-1:1992 Domestic Radio Emissions EN 50082-1:1995 Industrial Radio Immunity EN12182 Assistive Technology Also complies with 2002/95/ECRoHS Permitted Materials Additional Documents...
