Stack-On Security Plus PDS-505 Installation Instructions Manual

IMPORTANT
Record the serial number from the tag on the back of the safe or
from the tag on the inside of the lock cover plate on the front of
the safe. Record your combination number.
Keep keys in a secure place away from children.
For electronic safes - DO NOT STORE KEYS OR YOUR
COMBINATION INSIDE SAFE.
ELECTRONIC SAFES
When you first recieve your new electronic safe you will need to open the door with the key in order to install the
batteries. Batteries are included and are located inside the safe in the hardware bag.
To open the door with the key, first remove the small central panel from the front of the faceplate. Insert the key and turn
counterclockwise. Turn the knob to the right and open the door.
NOTE: This key has also been provided in case you lose or forget your security code or the batteries run low. If you lose
your key, you may purchase a replacement key by referencing the serial number located under the removable central panel.
See section at the bottom of this instruction regarding replacement keys.
Locate the batteries inside the safe. Open the battery compartment on the back of the door by pushing the tab in the
direction of the arrow and install the batteries.
ENTERING YOUR SECURITY CODE
To enter your own security code you will need to follow the steps listed below:
1. After installing the batteries, locate the small red button on the inside of the door near the hinge.
2. Press the red button and then release it, you will hear a beep. DO NOT SHUT THE DOOR UNTIL YOU HAVE
CONFIRMED THAT YOUR NEW SECURITY CODE HAS BEEN ENTERED CORRECTLY.
3. With the door open, enter your own personal security code, which can be 3-8 digits long, and confirm your new code by
pressing the " # " key on the electronic touch pad. Before you close the door, try the new security code to make sure the lock
releases the knob so you can turn it and retract the live action locking bolts.
If the code fails, go through steps 1-3 again. If the code works successfully, then you should lock the safe.
When you open the safe in the future enter the security code you have set followed by the "
If the incorrect security code is entered 3 times you will have an automatic lockout for 20 seconds before you can try your code
again.
If the incorrect security code is entered 3 additional times there will be a 5-minute lockout before the code can be tried again.
BATTERY REPLACEMENT
This safe uses 4 - AA batteries. Under normal use, batteries will last about 1 year.
When the battery is low, a red light will come on warning you that the battery is low.
To test the batteries, enter your security code. If the batteries are low the red light located in the middle of the top of the
keypad will start to flash.
To replace the batteries, open the battery compartment on the back of the door by pushing the tab in the direction of the
arrow and install all new batteries.
YOU MUST REPROGRAM YOUR SECURITY CODE AFTER YOU REPLACE THE BATTERIES. SEE STEPS 1-3 UNDER
"ENTERING YOUR SECURITY CODE".
R
Installation Instructions
Serial #:
Your Electronic Safe Combination
®
Home Security Safe
" key and turn the knob.
9004-0708
1
12
